ODU MOUNTING
No.1 ODU
(S)
No.2 ODU
ODU (6-11 GHz)
1+1 SD System
Note
Installation
Submission Prohibited
NEC Internal Use Only
Member of tower
Pole
No.1 ODU
(S)
No.2 ODU
ODU (13-38 GHz)
1+1 SD System
Antenna separation (S) is given by path calculation depending on the
system parameter.
ODU
Pole
ODU (6-11 GHz)
Member of tower
ODU
Member of tower
1+0 System
ODU (13-38 GHz)
5-11
Member of tower
Pole
1+0 System
Pole
NWD-107460-02E
