3.
Collector test — low speed
Test: Travel the entire guideway at 10% of the maximum speed. Observe the activity of the
collector on the ProfiDAT
3.1.
other transfers.
Required result: The connections and transfers along the entire length of the ProfiDAT
Rail are smooth and the activity of the collector is trouble-free at all times.
Collector test — increased speed
3.2.
Test: Increase the speed to 30 %, 50 %, 80 %, and finally 100 % of the full speed.
Required result: The collector's activity is trouble-free at all times.
Additional functional tests
3.3. Required result:
All other functions are carried out in accordance with the customer's requirements.
MAL0515-0001c-EN
www.conductix.com
Commissioning
compact Rail, particularly at the rail joints, switches, lifters, joints and
®
