6.2 Preparation

Required tools:
 Crosscut saw
Open-end wrench SW7 (M4)

 Open-end wrench SW8 (M5)
Open-end wrench SW13 (M8)

 Hexagon screwdriver (Allen key) SW 2.5
 Cordless drill - screwdriver
Bit attachment hexagon socket (Torx) TX8

 Bit attachment hexagon socket plus (Torx Plus) TP10
Round file with cut number ≥ 3

Flat file with cut number ≥ 3

 Step drill M3 90°
Drilling jig (Order-No.: 05-V015-0005)

 Torque screwdriver (e.g., Wiha TorqueVario-S 0.1 - 0.6 Nm)
Blade for torque screwdriver, hexagon socket (Torx) T8

Torque shut-off screwdriver (e.g., TorqBee from HS-Technik)

Tools required for exchanging sliding contacts:
Torx attachment TX5

 Flat-head screwdriver ≤ 3.0
Torque screwdriver (e.g., Wiha TorqueVario-S 0.1 - 0.6 Nm)

Required tools for replacing collector heads:
 Torx attachment TX5
Flat-head screwdriver ≤ 3.0

Material required:
 Cable ties
