Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
The environment of the
conductor rail may be
exposed to electrical
current!
Danger of sensitization,
mucous membrane irritation
and respiratory disease due
to dust!
2.9.5

Unexpected start, unexpected overrun in combination with a conductor rail

Failure/fault of the control
system, software error!
Restore the energy feed
after failure of the power
feed!
External influences on
electrical equipment due to
external sources of
interference!
MAL0515-0001c-EN
www.conductix.com
The environment of the conductor rail may be exposed to electrical current under the following
circumstances:
If the conductor rail is severely contaminated or wet.

 If electrically live parts are exposed (insulating profile or the insulation of the connection cable
are damaged)
When the hanger clamps or the insulating profile fail, or if the conductor bar falls down and

touches a conductive material.
 Secure the electrical system according to specifications.
 Install the conductor rail in accordance with the relevant documentation (see section11), follow
environmental conditions requirements and inspect, carefully service and clean the system
 Regularly clean the conductor rail and repair if necessary
Abrasion from the sliding contacts collects in the conductor rails, the ProfiDAT
and the support structure (substructure). This dust is very fine and is a health hazard. Possible
consequences:
 Irritations of the mucous membranes
Respiratory diseases

 Cancer
 For protective measures, see section 2.9.3.
The failure of the data transmission system or a software error can lead to uncontrolled
movement of the vehicle.
 A plausibility check of the signals must be carried out through the customer's superordinate
control system.
 Fill out the Test and Commissioning List; see section 6.
Failure of the power feed can lead to uncontrolled movements of the system.
 Initialization of the RAM memory (carried out automatically).
External sources of interference, such as radio or radar, can cause malfunctions of the
components and the WiFi network.
 Only use the manufacturer's ProfiDAT
 A plausibility check of the signals must be carried out through the customer's superordinate
control system.
translated document
compact Rail (*slotted waveguide).
®
compact Rail
®
page 19 of 105
