Mounting Instructions
ProfiDAT compact
®
Data Transmission System
Program 0515
No.
1.
The distance between the ProfiDAT
1.1.
according to section 6.4.1.
The collector is correctly aligned with the ProfiDAT
1.2.
90 mm was observed, see Fig. 73.
1.3.
No blocking objects are in the movement area of the collector.
®
The ProfiDAT compact connectors are correctly installed.
1.4.
Maximum gap between the rails is 0.5 mm in the X direction (direction of travel) and Y direction
(see Fig. 49 and Fig. 50).
1.5.
The power feed components are correctly mounted.
The PE cable and ground conductor rail are correctly mounted on the PE connectors.
1.6.
The grounding symbol is glued to the PE connector.
1.7.
The sliding contacts are free of grease.
1.8.
All screws are tightened with their respective tightening torque.
®
1.9.
The ProfiDAT compact Transceivers have been installed correctly (see section 6.5.3 and 0).
1.10. All electrical connections were correctly completed by specialist personnel.
1.11. All data cables (HF cables) have been correctly installed.
1.12. The operating personnel are trained.
2.
The stationary ProfiDAT
Turn on the 24 V power supply to the ProfiDAT
for the ProfiDAT compact Transceiver to load.
®
Requirement:
2.1.
LED "L1" or "L2" or "PoE" lights up green
LED "R1" lights up green or flashes green orange.
LEDs "P1" and / or "P2" light up green or flash green orange
LED "F" does not light up
MAL0515-0001c-EN
www.conductix.com
Description
Installation
compact hanger clamps (suspension distance) is correct
®
compact Rail. An installation dimension of
®
®
ProfiDAT compact Connection
®
compact Transceiver is turned on and the LAN is connected
compact Transceiver and allow at least 1 minute
®
translated document
Remark: o.k./n.o.k
