Mounting Instructions
ProfiDAT
compact
®
Data Transmission System
Program 0515
ATTENTION!
Fig. 73: Installation dimensions of the collector: From the installation base plate to the bottom edge of the rail
6.4.10 Mount the positioning system
The positioning system consists of the code tape (2), which is attached to the ProfiDAT
the reading head (1), which is located on the vehicle.
The reading head is mounted according to the operating instructions of the manufacturer.
Fig. 74: Positioning system in detail
The code tape is glued directly onto the ProfiDAT
The height of the code tape may not exceed 20 mm. Please observe the operating instructions of the manufacturer for this.
MAL0515-0001c-EN
www.conductix.com
It must be ensured that the center axis of the ProfiDAT
on the center axis of the collector (B) and that the specified mounting distance between the
installation base plate and the rail is observed (see installation plan and Fig. 73).
1
compact Rail (only possible when using the rail with an additional positioning strip).
®
translated document
compact Rail (A) is mounted exactly
®
compact Rail with the positioning strip, and
®
2
page 65 of 105
