Magazine and Loading Finger Adjustment

The slope of the magazine rack needs to be adjusted when the shape of the material being loaded changes from round to profiled or
vise versa.
When loading round stock, if the slope of the magazine is too much it is possible for the material to stack up and cause double loading
if the weight of the material is great enough (especially when loading smaller diameter stock). Therefore, the slope must be reduced.
When loading profiled (ex. square/hex) stock, if the slope of the magazine is not great enough it can prohibit the ability of the material
to slide down the rack. Therefore, the slope must be increased.
Procedure: Round
Conditions:
No stock on the magazine.
Bare feed in STOP mode.
Step 1: Rotate the loader rack adjustment axle CCW to increase the slope of the magazine until the indicator on the side of the
magazine references the profiled material. Note: if there is not enough adjustment on the threaded rod, remove the pin and
lift the magazine up to the next hole and reinsert the pin. Caution when removing the pin, the magazine rack will drop if not
supported properly.
Procedure complete.
The following is a video clip of the Magazine and Loading Finger Adjustment from Round to Profiled procedure. Must have the
electronic file to play. Movie may take several seconds to begin.
Procedure: Profiled
Conditions:
No stock on the magazine.
Bare feed in STOP mode.
Step 1: Rotate the loader rack adjustment axle CW to decrease the slope of the magazine until the indicator on the side of the
magazine references the round material. Note: if there is not enough adjustment on the threaded rod, remove the pin and
drop the magazine down to the next hole and reinsert the pin. Caution when removing the pin, the magazine rack will drop if
not supported properly.
Procedure complete.
The following is a video clip of the Magazine and Loading Finger Adjustment from Profiled to Round procedure. Must have the
electronic file to play. Movie may take several seconds to begin.
QUICK LOAD SERVO S3
Profiled
Round
