3 - 2
End of Bar Adjustment
Procedure:
Conditions:
Bar feed power on.
Air pressure set at 5 bar (75psi.).
No bar stock in spindle.
V-channel in the lower position.
Bar feed in STOP mode.
Step 1:
Press the MENU key on the remote control station.
Step 2:
Press the #3 (Position/Torque) key on the remote control station.
Step 3:
Press the F3 (SET) key on the remote control station.
Step 4:
Press the F2 (TEACH IN) key on the remote control station.
Step 5:
Press and hold the F-key corresponding to the pusher forward icon, until the pusher is ¼" behind the clamping system.
Step 6:
Press and hold the F3 (ENTER) key on the remote control station. The End Of Bar is now set.
Step 7:
Press the F2 (ESC) key on the remote control station.
Procedure complete.
QUICK LOAD SERVO S3
Chapter 3: Procedures
