3 - 8
Step 4:
Loosen up the setscrews to release the pusher.
Step 5:
Pull out the guide bushing from the front ring.
Step 6:
Remove the pusher from the bar feed.
Step 7:
Put the new pusher in the bar feed.
Step 8:
Push the guide bushing in the front ring.
Step 9:
Place the rear end of the pusher in the carrier and tighten the setscrews.
QUICK LOAD SERVO S3
Chapter 3: Procedures
