3 - 1 0
Carriage Unit Belt Tension Adjustment
Procedure:
Conditions:
Bar feed power on.
Bar feed in STOP mode.
Step 1:
Open the main access cover.
Step 2:
Pull the carriage unit forward towards the middle of the linear rail.
Step 3:
On each end of the carriage unit are black plastic end caps. In the
is an opening with a 3mm allen head tensioning screw inside. Turn the screw CW to add tension to the belt and CCW to
release tension.
3mm allen head screw
in
side. Also, one
other side (not show
QUICK LO AD SERVO S3
on
n).
Chapter 3: Procedures
center of the end cap on either side, right above the belt
