2 - 6
Solution:
Cause
st
1 Part feed out after
top-cut positioning too
short/long
Part feed out to short
Part feeds out too long
QUICK LOAD SERVO S3
• Verify that the top-cut position is programmed correctly
• If performing a cut-off or facing operation on the barstock during top-cut,
verify that the end of the barstock is in the same location as if a part was
cut-off after the cut-off or facing operation is complete.
• Verify that the correct value is entered into the "Input overall part length"
parameter
• If using a pull-to close type clamping system ensure that the time entered
into the "Time for clamping device to close" parameter is correct.
• Make sure that the clamping device is not forcing the barstock back when
closing
• Verify that the lathe program is correct
• Verify that the barstock is concentric and clean of debris
• Verify that the correct value is entered into the "Input overall part length"
parameter
• If using a push-to-close type clamping system ensure the turret is being
used to locate the part and that the turret is in the correct location
• Verify that the barstock is concentric and clean of debris
Chapter 2: Common Issues
Solution
