Appendix B: GPI/O Programming Guide

a B: GPI/o P
PPendIx
GPI/O (General Purpose Input/Output) pins are provided for custom system design. This appendix provides
definitions and its default setting for the ten GPI/O pins in NISE 105U. The pin definition is shown in the
following table:
PowerOn
Pin GPI/O mode
Default
1 VCC -
3 GPO0 Low
5 GPO1 Low
7 GPO2 Low
9 GPO3 Low
Control the GPO 0/1/2/3 level from I/O port A03h bit6/ A02h bit5/ A07h bit0/ A07h bit1.
The bit is Set/Clear, which indicates output High/Low.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
roGrammInG
Address Pin GPI/O mode
- 2 GND
A03h (Bit6) 4 GPI0
A02h (Bit5) 6 GPI1
A07h (Bit0) 8 GPI2
A07h (Bit1) 10 GPI3
G
uIde
PowerOn
Address
Default
- -
High A03h (Bit1)
High A05h (Bit5)
High A05h (Bit4)
High A00h (Bit1)
63
