Chapter 1: Product Introduction

Rear Panel

Line-out Mic-in
Remote Switch DVI-I
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
COM2 & COM3 & COM4
Optional I/F
Remote Switch
Used to connect a remote to power on/off the system.
DVI-I
Used to connect a DVI-I interface monitor.
Line-out
Used to connect a headphone or a speaker.
Mic-in
Used to connect an external microphone.
COM2
DB9 port used to connect RS232/422/485 compatible devices.
COM3 & COM4
Two DB9 ports used to connect RS232 compatible devices.
Optional I/F
Expansion slot for optional function output or module interface use.
