Chapter 3: System Setup
Wall Mounting Instructions
To mount the system on to a wall or some other surface using the two
mounting brackets, please follow the steps below.
1. Turn the system over. Align the two retention screw holes in each bracket
with the retention screw holes on the sides of the bottom surface.
2. Secure the brackets to the system by inserting two retention screws into
each bracket.
Specification of the wall mount screw:
Round Head Screw Long Fei:P6#32Tx 1/4/SW7*0.8 w/Spring+Flat Washer
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
3. Drill holes in the intended installation surface.
4. Align the mounting holes on the sides of the mounting brackets with the
predrilled holes on the mounting surface.
5. Insert four retention screws, two in each bracket, to secure the system
to the wall.
Wall Mount Bracket
Fasten screws to mount
the system to the wall
42
NISE 105U User Manual
