Appendix A: Power Consumption

a a: P
PPendIx
Power Consumption Measurement Test
Purpose
The purpose of the power consumption test is to verify the power dissipation
of system, and the loading of power supply.
Test Equipment/Software
Chroma 62006P-100-25
Device Under Test
DUT: NISE 105U
CPU: Intel Celeron processor J1900 quad core, 2.00GHz
® ®
Memory: Innodisk 8GB DDR3L SODIMM
HDD: Innodisk 2.5" SATA SSD M3E4
M.2: Innodisk M.2 128GB
Power Supply: LABORATORY DC POWER SUPPLY GWINSTEK GPC-60300
CPU Cooler: NISE 105U CPU Heatsink
Keyboard: Microsoft Wired Keyboard 600
Mouse: Microsoft Basic Optical Mouse
Test Procedure
1. Power up the DUT, boot into Windows 10 x64 Pro.
2. Entering standby mode (SSD power down).
3. Measure the power consumption and record it.
4. Run Burn-in test program to apply 100% full loading.
5. Measure the power consumption and record it.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower onsumPtIon
Test Result
Full-Loading Mode
Total
Standby S3 Mode
Total
62
Sys #1 Sys #1
+30V +9V
1.1A 3.1A
33W 27.9W
0.17A 0.2A
5.1W 1.8W
