Chapter 2: Jumpers and Connectors

M.2 Key Connector

Connector location: CN9
1 2
75 74
Pin Definition
1 GND
3 GND
5 GND
7 HUBUSB_DP2
9 HUBUSB_DM2
11 N36291047
21 NA
23 NA
25 NA
27 GND
29 NA
31 NA
33 GND
35 NA
37 NA
39 GND
41 SATA_RXP1_C
43 SATA_RXN1_C
45 GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 3VSB
4 3VSB
6 NA
8 N36291448
10 NA
20 NA
22 NA
24 NA
26 NA
28 NA
30 NA
32 NA
34 NA
36 NA
38 NA
40 NA
42 NA
44 NA
46 NA
Pin Definition
47 SATA_TXN1_C
49 SATA_TXP1_C
51 GND
53 NA
55 NA
57 GND
59 NA
61 NA
63 NA
65 NA
67 M.2_RESET
69 PCIE_mSATA_SEL
71 GND
73 GND
75 USB3_OTHER_SEL
MH1 GND
NH1 NA
28
Pin Definition
48 NA
50 PLTRST_3P3#
52 NA
54
56 NA
58 NA
60 NA
62 NA
64 NA
66 NA
68 M2_SUSCLK
70 3VSB
72 3VSB
74 3VSB
MH2 GND
NH2 NA
