Chapter 4: BIOS Setup
CPU Configuration
This section is used to configure the CPU.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
CPU Configuration
Socket 0 CPU Information

CPU Speed 2001 MHz
64-bit Supported
Active Processor Cores [All]
Limit CPUID Maximum [Disabled]
Execute Disable Bit [Enabled]
Intel Virtualization Technology [Enabled]
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Active Processor Cores
Select the number of cores to enable in each processor package.
Limit CPUID Maximum
The CPUID instruction of some newer CPUs will return a value greater
than 3. The default is Disabled because this problem does not exist in the
Windows series operating systems. If you are using an operating system
other than Windows, this problem may occur. To avoid this problem, enable
this field to limit the return value to 3 or lesser than 3.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Execute Disable Bit
When this field is set to Disabled, it will force the XD feature flag to always
return to 0. XD can prevent certain classes of malicious buffer overflow
attacks when combined with a supporting OS (Windows Server 2003 SP1,
Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3).
Socket specific CPU Information
Intel
Enables or disables Intel
Socket 0 CPU Information
This section displays the information of the CPU installed in Socket 0.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
52
®
Virtualization Technology
® Virtualization technology.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Socket 0 CPU Configuration
Intel(R) Celeron(R) CPU J1900 @ 1.99Ghz
CPU Signature 30679
Microcode Patch 90a
Max CPU Speed 1990 MHz
Min CPU Speed 1334 MHz
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-x Technology Supported
L1 Data Cache 24 kB x 4
L1 Code Cache 32 kB x 4
L2 Cache 1024 kB x 2
L3 Cache Not Present
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
