Chapter 2: Jumpers and Connectors
Reset Pin Header
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP9
1
2
Pin
Definition
1
PM_RESET#_J
2
GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
PWR_LED/HDD_LED/SMB_BUS/S3/SW_ON/RESET
Connector type: 2x7 14-pin header, 2.0mm pitch
Connector location: JP8
2
14
1
13
Pin
Definition
1
PWR_LED_N
3
HDD_LED_N
5
SMB_CLK
7
3VSB
9
SLP_S3#
11
PBT_SW
13
PM_RESET#_J
24
Pin
Definition
2
POWER_LED_PWR
4
HDD_LED_PWR
6
SMB_DATA
8
GND
10
PSON
12
GND
14
GND
NISE 105U User Manual
