User Guide
Ultrastar® Serv60+8
Regulatory Model: H4060-S
December 2019
Rev. 1.8
1ET1110

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultrastar Serv60+8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Western Digital Ultrastar Serv60+8

Summary of Contents for Western Digital Ultrastar Serv60+8

  • Page 1 User Guide Ultrastar® Serv60+8 Regulatory Model: H4060-S December 2019 Rev. 1.8 1ET1110...

  • Page 2: Table Of Contents

    List of Customer Replaceable Units (CRUs)..........................9 LEDs......................................11 Front and Rear IO LEDs..............................11 IOM LEDs....................................12 PSU LED..................................... 13 Drive Assembly LED................................14 Ultrastar Serv60+8 Rack Requirements..........................15 Compatible Rack Hardware Configuration........................16 Power Requirements................................18 ESD......................................18 Enclosure Cooling..................................19 List of Compatible Drives................................ 19 List of Supported Server Components..........................39...
  • Page 3 User Guide Table of Contents IOM Specifications................................48 IOM Layout..................................48 IOM Blank Description..............................49 PSU Description..................................50 PSU Specifications................................50 PSU Layout..................................50 System Fan Description................................51 Rails Description..................................52 Rails Specifications................................52 Rails Layout..................................53 Rear Cover Alignment Bracket Description........................53 CMA Description..................................54 CMA Specifications................................
  • Page 4 User Guide Table of Contents Add-in Card Replacement..............................193 CMA Replacement..................................212 Rails Replacement..................................233 Chassis Replacement................................259 Cabling for CMA Standard and CMA Lite..........................311 Before You Begin................................312 Cabling CMA Standard..............................312 Cable Configuration for CMA Lite..........................313 Chapter 5. System Management..............................315 Storage Subsystem Firmware Upgrade..........................316 Downloading Firmware from the Support Portal......................
  • Page 5 User Guide Table of Contents Partially Populated Enclosures...............................381 Partial Population Configurations...........................381 Installing Drives................................384 Chapter 6. Safety..................................388 Electrostatic Discharge................................. 389 Optimizing Location................................389 Power Connections................................389 Power Cords..................................389 Rackmountable Systems............................... 390 Safety and Service.................................390 Safety Warnings and Cautions.............................. 391 Chapter 7.

  • Page 6: Revision History

    System MAC Address (page 336) July 2019 Revision 1.5 Moved the following topics to the Overview (page 1) section: • Ultrastar Serv60+8 Rack Requirements (page 15) • Power Requirements (page 18) • ESD (page 18) • Enclosure Cooling (page 19) •...
  • Page 7 User Guide Revision History Date Revision Comment Moved the Supported Operating Systems (page 43) topic to the System Management Overview (page 42) section. Corrected LED identification tables for IOMs, PSUs, and drives in LEDs (page 11) section. Updated the following for CMA Lite: •...

  • Page 8: Copyright

    5601 Great Oaks Parkway San Jose, CA 95119 Long Live Data™ is a trademark of Western Digital, Inc. and its affiliates in the United States and/or other countries. Western Digital trademarks are authorized for use in countries and jurisdictions in which Western Digital has the right to use, market and advertise the brands.

  • Page 9: Points Of Contact

    Points of Contact Points of Contact For further assistance with a Western Digital product, contact Western Digital Datacenter Platforms technical support. Please be prepared to provide the following information: part number (P/N), serial number (S/N), product name and/or model number, and a brief description of the issue.

  • Page 10: Chapter 1. Overview

    - Ultrastar Serv60+8 Specification Summary............5 - Ultrastar Serv60+8 Layout......7 - List of Customer Replaceable Units (CRUs)............... 9 - LEDs..............11 - Ultrastar Serv60+8 Rack Requirements..15 - Power Requirements........18 - ESD..............18 - ................19 - ................19 - ................. 39...

  • Page 11: Serv60+8 Description

    The Ultrastar® Serv60+8 is a 4U form factor, high density, rack-mounted storage enclosure that is capable of hosting up to 60 HDD SAS or SATA drives. The maximum data storage capacity of the Ultrastar Serv60+8 is 901TB using 14TB Ultrastar® HC530 drives plus an additional 61.44 TB using Ultrastar® SS300 SSDs in the system SSD slots.

  • Page 12: System Level Block Diagram

    1.2   System Architecture Overview Storage Subsystem Overview The Ultrastar Serv60+8 IOM uses a cascaded expander design to allow for connection to all 60 HDD drives. The minimum configuration comes with two of the six PCIe slots pre-populated with a combination of internal SAS HBAs and RAID adapters that act as an interconnect between the server subsystem and the storage subsystem by connecting to the system SSDs and the IOM.
  • Page 13 1. Overview User Guide 1.3 System Level Block Diagram Figure 3: System Block Diagram for the Server Subsystem...

  • Page 14: Ultrastar Serv60+8 Specification Summary

    1. Overview User Guide 1.4 Ultrastar Serv60+8 Specification Summary Figure 4: System Block Diagram for the Storage Subsystem 1.4   Ultrastar Serv60+8 Specification Summary Table 1: Environmental Specifications Specification Non-Operational Operational Temperature -40°C to 70°C 5°C to 35°C Temperature Gradient 30°C per hour maximum...
  • Page 15 IPC-9592B(L) Appendix C-4.1. Typical Inrush Current (per PSU) Caution: The Ultrastar Serv60+8 can only be plugged into high line (220-240 VAC). If the unit is plugged into low line (110-127 VAC), the PSU will report a "Critical" state when status pages are queried using SES.

  • Page 16: Ultrastar Serv60+8 Layout

    60 HDD / 8 SSD Data Transfer Rates 12Gbps SAS / 6Gbps SATA Max Raw Data Storage Capacity 901TB using 14TB Ultrastar® HC530 drives / 61.44 TB using Ultrastar® SS300 SSDs 1.5   Ultrastar Serv60+8 Layout Figure 5: Front and Rear Product Layout...
  • Page 17 Table 5: Front and Rear Component Identification Number Component Enclosure Handles PSUs Rear IO Ports Chassis Cover Rails (contains rear cover alignment brackets, not pictured) The following is an image of the layout of the major system components inside the Ultrastar Serv60+8. Figure 6: Component Layout...

  • Page 18: List Of Customer Replaceable Units (Crus)

    1.6   List of Customer Replaceable Units (CRUs) The following table lists the replaceable components and their part numbers. Table 6: List of Replaceable Components Component Part Number Ultrastar Serv60+8 Chassis with Single IOM and PSUs 1EX1801 1EX1828 IOM Blank 1EX0431...
  • Page 19 1. Overview User Guide 1.6 List of Customer Replaceable Units (CRUs) Component Part Number Bracket PCIe Cache Vault Mount 1EX1800 Heat Sink 1EX1464 Intel® Xeon® Silver 4110 CPU w/ Heat Sink 1EX1563 Intel® Xeon® Silver 4114 CPU w/ Heat Sink 1EX1322 Intel®...

  • Page 20: Leds

    1.7.1   Front and Rear IO LEDs The Ultrastar Serv60+8 has three LEDs on the front and three on the rear that mirror each other and provide general status. This allows the status of the enclosure to be visible from either side of the rack.

  • Page 21: Iom Leds

    1. Overview User Guide 1.7 LEDs Figure 9: Rear IO LEDs Table 7: Front and Rear LED Identification Number LED Name Color Behavior Blink @ 1 Hz (50% duty cycle) – Blinks only 1 Identification Blue when Identification has been activated. Will blink when any component is identified.

  • Page 22: Psu Led

    1. Overview User Guide 1.7 LEDs Table 8: IOM LED Identification LED Name Color Behavior Blink @ 0.5 Hz (75% duty cycle) – Blinks only IOM Identification Blue when IOM Identification has been activated. Off - Not being identified Blink @ 0.5 Hz (75% duty cycle) – IOM has Fault IOM Fault Amber Off - IOM is functioning normally Solid - IOM is on...

  • Page 23: Drive Assembly Led

    1. Overview User Guide 1.7 LEDs LED Name Color Behavior Note: LEDs have a 50% duty cycle (On for 2 seconds, off for less than a second). 1.7.4   Drive Assembly LED The HDD drive assemblies themselves do not contain an LED. However, there is an amber multi- function LED located on the drive carrier that has three distinct states, one for a fault condition, one for identification, and off.

  • Page 24: Ultrastar Serv60+8 Rack Requirements

    1.8   Ultrastar Serv60+8 Rack Requirements The Ultrastar Serv60+8 is designed to be installed into a rack that meets the EIA-310 standard at a minimum 1200 mm (47.24in.) of usable rack space, frame to frame. The vertical rack rails must be set between 812.8mm - 914.4mm / 32 in.

  • Page 25: Compatible Rack Hardware Configuration

    The following section provides specific information necessary to install, service, and remove the Ultrastar Serv60+8. The installation of the Ultrastar Serv60+8 requires two people and a space of 1524mm / 60in. in front of the installation space. The servicing of the enclosure requires one person and a minimum of 1219.2mm / 48in.
  • Page 26 1. Overview User Guide 1.8 Ultrastar Serv60+8 Rack Requirements PDU Mounting Additional Mounting Parameter Rack PDU (Vertical) Bracket Bracket Hardware AS-160099-03 KIT-MBVPT-1B 412-0761-11_STV-4501 4 x M6 x 16 Hex (Drawing (one kit per PDU) Cap Screws 412-0761-20_STV-4502 Number EMCOR Part...

  • Page 27: Power Requirements

    IPC-9592B(L) Appendix C-4.1. Caution: The Ultrastar Serv60+8 can only be plugged into high line (220-240 VAC). If the unit is plugged into low line (110-127 VAC), the PSU will report a "Critical" state when status pages are queried using SES.

  • Page 28: Enclosure Cooling

    IOM SXP temperture, from the BMC itself to react to changing thermal conditions and adjust the speed of the two server subsystem fan as necessary. The rack that the Ultrastar Serv60+8 is installed in must not restrict airflow to the enclosure. Racks with doors should be tested to ensure they do not constrict airflow to the enclosure.
  • Page 29 1. Overview User Guide 1.12 List of Compatible Drives Table 18: HDD w/ 3.5 in drive carrier Drive Type Interface Sector Size Encryption Volume Part Number Western Digital® Ultrastar® DC SAS 12Gb/s 1EX1993 HC310 w/ 3.5 in. drive carrier Western Digital®...
  • Page 30 1. Overview User Guide 1.12 List of Compatible Drives Drive Type Interface Sector Size Encryption Volume Part Number w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SAS 12Gb/s 512e TCG-FIPS 1EX1853 HC310 w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SATA 6Gb/s 1EX1187 HC310...
  • Page 31 1. Overview User Guide 1.12 List of Compatible Drives Drive Type Interface Sector Size Encryption Volume Part Number Western Digital® Ultrastar® DC SATA 6Gb/s 1EX1225 HC320 w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SATA 6Gb/s 1EX1224 HC320 w/ 3.5 in. drive carrier Western Digital®...
  • Page 32 1. Overview User Guide 1.12 List of Compatible Drives Drive Type Interface Sector Size Encryption Volume Part Number Western Digital® Ultrastar® DC SAS 12Gb/s 512e TCG-FIPS 10TB 1EX1341 HC510 w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SATA 6Gb/s 10TB 1EX0494 HC510...
  • Page 33 1. Overview User Guide 1.12 List of Compatible Drives Drive Type Interface Sector Size Encryption Volume Part Number Western Digital® Ultrastar® DC SAS 12Gb/s 512e 12TB 1EX1007 HC520 w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SAS 12Gb/s 512e 12TB 1EX1009 HC520...
  • Page 34 1. Overview User Guide 1.12 List of Compatible Drives Drive Type Interface Sector Size Encryption Volume Part Number Western Digital® Ultrastar® DC SAS 12Gb/s 14TB 1EX1789 HC530 w/ 3.5 in. drive carrier Western Digital® Ultrastar® DC SAS 12Gb/s TCG-FIPS 14TB 1EX1854 HC530 w/ 3.5 in.
  • Page 35 Drive Writes Encryption Volume Number Western Digital® SAS 12Gb/s RI-3DW/D 400GB 1EX1276 Ultrastar® SS200 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS200 SAS 12Gb/s RI-3DW/D 400GB 1EX1278 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS200 SAS 12Gb/s RI-3DW/D 400GB 1EX1353 w/ 2.5 in.
  • Page 36 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS300 SAS 12Gb/s ME-10DW/D 400GB 1EX1159 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS300 SAS 12Gb/s ME-10DW/D...
  • Page 37 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D 480GB 1EX2006 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D...
  • Page 38 1. Overview User Guide 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D 800GB 1EX2002 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D 800GB 1EX2003 w/ 2.5 in.
  • Page 39 1. Overview User Guide 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number Western Digital® Ultrastar® SS200 SAS 12Gb/s ME-10DW/D 1.6TB 1EX1776 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS200 SAS 12Gb/s ME-10DW/D 1.6TB 1EX1777 w/ 2.5 in.
  • Page 40 1. Overview User Guide 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D 1.92TB 1EX2011 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D 1.92TB 1EX2082 w/ 2.5 in.
  • Page 41 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number Ultrastar® SS530 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D ISE 7.68TB 1EX1819 w/ 2.5 in. drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D ISE 7.68TB...
  • Page 42 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS300 SAS 12Gb/s ME-10DW/D TCG-FIPS 400GB 1EX1479 w/ 3.5 in to 2.5 in drive carrier Western Digital®...
  • Page 43 Cloudspeed Ultra Gen. II SATA 6Gb/s RI-1.8DW/D 800GB 1EX1305 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D 800GB 1EX2022 w/ 3.5 in to 2.5 in drive carrier Western Digital® SSD SAS 12Gb/s RI-3DW/D 800GB 1EX2023...
  • Page 44 Part Drive Type Interface Drive Writes Encryption Volume Number Ultrastar® SS530 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-3DW/D 800GB 1EX2088 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530...
  • Page 45 1.12 List of Compatible Drives Part Drive Type Interface Drive Writes Encryption Volume Number w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS300 SAS 12Gb/s RI-3DW/D TCG-FIPS 1.6TB 1EX1787 w/ 3.5 in to 2.5 in drive carrier Western Digital®...
  • Page 46 Ultrastar® SS200 SAS 12Gb/s RI-1DW/D 3.84TB 1EX0579 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D 3.84TB 1EX2036 w/ 3.5 in to 2.5 in drive carrier Western Digital® SSD SAS 12Gb/s RI-1DW/D 3.84TB 1EX2037...
  • Page 47 Part Drive Type Interface Drive Writes Encryption Volume Number Ultrastar® SS530 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530 SAS 12Gb/s RI-1DW/D 3.84TB 1EX2095 w/ 3.5 in to 2.5 in drive carrier Western Digital® Ultrastar® SS530...

  • Page 48: List Of Supported Server Components

    1.13 List of Supported Server Components Drive Type Form Factor Interface Encryption Volume Part Number Sandisk® M.2 2280 SATA 6Gb/s 128GB 1EX1574 X600 Western Digital® M.2 2280 SATA 6Gb/s 240GB 1EX1354 Ultrastar® SA210 Sandisk® M.2 2280 SATA 6Gb/s 256GB 1EX1570 X600 Sandisk®...
  • Page 49 1. Overview User Guide 1.13 List of Supported Server Components Brand Model Number Size Type Form Factor Rank Speed Samsung M386AAK40B40-CWD 128GB DDR4 LRDIMM 8 Rank 2666 MHz Samsung M393A1G40EB2-CTD DDR4 RDIMM 2 Rank 2666 MHz Samsung M393A1G43EB1-CTD DDR4 RDIMM 2 Rank 2666 MHz Samsung...
  • Page 50 1. Overview User Guide 1.13 List of Supported Server Components Brand Model Type Connection Speed Intel X550-T2 10G-BaseT Intel X540-T2 10G-BaseT Chelsio T6225-CR Mellanox ConnectX-4 Lx (MCX4121A-ACAT)

  • Page 51: Chapter 2. System Management Overview

    There are also two out-of-band interfaces that can be accessed through BMC that are integrated into the system via the RJ45 port on the Ultrastar Serv60+8. The interface is a GUI that is accessible via the BMC management port on the rear of the enclosure.

  • Page 52: Storage Subsystem Firmware Features Overview

    2. System Management Overview User Guide 2.1 Storage Subsystem Firmware Features Overview 2.1   Storage Subsystem Firmware Features Overview The enclosure services functionality is compatible with the SES-3 (SES3r14) standard. The enclosure implements the Standalone Enclosure Services Process model described in the SES standard. The logical enclosure services process is called the SEP.

  • Page 53: Oobm Management Overview

    8.10 2.3   OOBM Management Overview The Ultrastar Serv60+8 uses an implementation of DMTF Redfish for out-of-band system management. All the SES enclosure information can be obtained through the out-of-band management port using RESTful API calls to the management port over HTTPS. The OOBM ports are configured for DHCP by default.

  • Page 54: Chapter 3. Component Overviews

    Western Digital Component Overviews This section is intended to give an overview of all of the major components contained within the Ultrastar Serv60+8. Each section includes specifications, descriptions, and images that explain the features of each component. In This Chapter: - Chassis Description........46...

  • Page 55: Chassis Description

    The chassis is the primary housing that contains and connects all of the system components that comprise the Ultrastar Serv60+8. The chassis is comprised of the drive bay that contains all of the system data storage drives and a number of other bays that contain the major system components such as the PSUs and IOM.

  • Page 56: Iom Description

    3. Component Overviews User Guide 3.2 IOM Description Figure 16: Layout Table 27: Exterior Components Number Feature PSU Bays • Top bay: PSU A • Bottom bay: PSU B Server IO Chassis Handles IOM Bay SSD Drive Bays HDD Drive Bays System Fan Slots System Fan Slots (center channel) The chassis has a removable cover that encloses the internal system components and ensures proper...

  • Page 57: Iom Specifications

    3. Component Overviews User Guide 3.2 IOM Description Figure 17: Overview Image The IOM provides system data connectivity through 4 Mini-SAS HD ports each capable of four 12Gbps SAS connections. The IOM is installed into the central bay from the top of the Chassis and connect to the drive board.

  • Page 58: Iom Blank Description

    3. Component Overviews User Guide 3.2 IOM Description Figure 18: Layout Table 28: Exterior Components Number Feature IOM Handle Latch Release Internal IO Connector Card Edge Power Receptacle Internal IO Connector 3.2.3   IOM Blank Description Figure 19: Overview Image...

  • Page 59: Psu Description

    3.3   PSU Description Figure 20: Overview Image Ultrastar Serv60+8 contains redundant 2000W Power Supply Units (PSU). Each PSU requires an input voltage of between 200 - 240 VAC. The PSUs are 80 PLUS Platinum certified, and utilize C14 power cable receptacles.

  • Page 60: System Fan Description

    3. Component Overviews User Guide 3.4 System Fan Description Figure 21: Layout Table 29: Exterior Components Number Feature Internal Connector C14 Power Receptacle Latch Release Lever Handle 3.4   System Fan Description...

  • Page 61: Rails Description

    Figure 23: Overview Image The Ultrastar Serv60+8 is installed into a rack using a toolless-attach rail system. The rails are a two-piece system with one rail that attaches directly to the chassis called the inner rail and the other that attaches to the rack.

  • Page 62: Rails Layout

    3. Component Overviews User Guide 3.5 Rails Description Specification Value Length 1028.7 mm/40.5 in. Part Number 1EX0435 Hot Swappable? FRU or CRU? Weight 7.89 kg total, 3.95 kg/rail / 17.4 lbs. total, 8.7/rail 3.5.2   Rails Layout Figure 24: Layout Table 30: Exterior Components Number Features...

  • Page 63: Cma Description

    The rear cover alignment brackets are designed to keep the top cover of the chassis in the rack while extending the Ultrastar Serv60+8 out of the rack for servicing. The rear cover alignment brackets will attach to the rear vertical rack rails and rest on top of the toolless rail system.

  • Page 64: Cma Specifications

    3.6 CMA Description The design of the Ultrastar Serv60+8 CMA is a single-arm design that supports all of the cabling used in the enclosure. The cables are secured to the arm by plastic clips called baskets that can be opened at the top to adjust, add, or remove cables.

  • Page 65: Cma Lite Description

    3. Component Overviews User Guide 3.7 CMA Lite Description Table 31: Exterior Components Number Feature Rail and Rack Connectors Baskets (retains cables) Elbow 3.7   CMA Lite Description Figure 28: Overview Image The lite version of cable management assembly (CMA Lite) provides the same cable management and protection benefits as the standard CMA for a lighter cable load (2 SAS, 2 power, 2 Ethernet).

  • Page 66: Cma Lite Layout

    3. Component Overviews User Guide 3.7 CMA Lite Description Specification Value Part Number 1EX1834 2 SAS Cables Maximum Number of Cables 2 Power Cords 2 Ethernet Hot Swappable? FRU or CRU? Weight 0.9 kg / 1.9 lbs 3.7.2   CMA Lite Layout Figure 29: Layout Table 32: Exterior Components Number...

  • Page 67: Drive Assembly Description

    3. Component Overviews User Guide 3.8 Drive Assembly Description Number Feature Basket Clips (retain cables) 3.8   Drive Assembly Description Figure 30: Overview Image The Drive Assembly is comprised of two parts: the storage drive and the drive carrier. The carrier attaches to the exterior of the data storage drive and caddies the drive into the enclosure.

  • Page 68: Drive Carrier Description

    3. Component Overviews User Guide 3.8 Drive Assembly Description Figure 31: Layout Table 33: Exterior Components Number Feature Latches Latch Release IO and Power Connectors Drive Carrier Disk Drive 3.8.3   2.5" Drive Carrier Description...
  • Page 69 The 2.5" carrier assembly is used to adapt a 2.5" form factor data storage drive to the 3.5" drive slots in the Ultrastar Serv60+8 drive bays. This allows the enclosure to accommodate high speed SSD drives as its primary data storage medium. The carrier operates by utilizing an innovative clamping mechanism.
  • Page 70 3. Component Overviews User Guide 3.8 Drive Assembly Description Figure 33: Clamp Release (clamp shown in blue for visual clarity) Step 2 : Slide the clamp in the direction shown in the following image to loosen it from the drive. Be sure not to slide too far as this will allow the clamp to fall from the carrier body and it will have to be reinstalled.

  • Page 71: Drive Blank Description

    The drive blank is a placeholder component that is used to fill empty drive slots in the chassis when a Ultrastar Serv60+8 enclosure is partially populated with drives. The purpose of the drive blank is to maintain proper airflow and cooling of the enclosure and the components within the enclosure. For more...

  • Page 72: System Ssd Description

    3. Component Overviews User Guide 3.9 System SSD Description Figure 36: 3.5" Drive Blank Overview Image Empty drive slots in the center channel must be populated with 2.5" drive blanks. Figure 37: 2.5" Drive Blank Overview Image 3.9   System SSD Description...

  • Page 73: System Ssd Specifications

    The system SSD drives are located in the center channel inside the enclosure. These drives can be used in the same fashion as the 3.5" drives populating the major data storage bays in the Ultrastar Serv60+8. They are accessible via the storage subsystem architecture through SES or through the Redfish OOBM.

  • Page 74: Chapter 4. Part Replacement

    Western Digital Part Replacement In This Chapter: - Part Replacement Service Window....66 - IOM Replacement......... 66 - PSU Replacement.........70 - System Fan Replacement......74 - Drive Assembly Replacement......77 - System SSD Replacement......82 - DIMM Replacement........85 - CPU and Heat Sink Module Replacement..........113...

  • Page 75: Part Replacement Service Window

    4. Part Replacement User Guide 4.1 Part Replacement Service Window 4.1   Part Replacement Service Window The following table contains a time required and a replacement window related to each hot swappable replacement part within the enclosure. The time required for replacement is the expected amount of time it requires to replace the part.
  • Page 76 4. Part Replacement User Guide 4.2 IOM Replacement Figure 39: Chassis Handle Operation Step 2 : Locate the faulty IOM by the amber LED that will be lit on top if there is a fault or by activating the identify LED on the IOM being replaced. Step 3 : Uninstall the IOM.
  • Page 77 4. Part Replacement User Guide 4.2 IOM Replacement Figure 41: Removing IOM Step 4 : Remove the new IOM from its packaging. Step 5 : Install the IOM. Caution: If a pin on the IOM’s internal connectors is bent or damaged, the IOM will have to be replaced.
  • Page 78 4. Part Replacement User Guide 4.2 IOM Replacement Figure 42: Unlatching IOM Handles c. Align the IOM with the empty slot on the top of the chassis so that the arrow on the IOM latch release is facing toward the side shown in the following image. d.

  • Page 79: Psu Replacement

    4. Part Replacement User Guide 4.3 PSU Replacement e. When the IOM is lowered fully, apply light pressure with both hands evenly on the IOM body, not the handles, to seat the IOM in the connector. If the IOM won’t seat correctly, DO NOT FORCE IT.
  • Page 80 4. Part Replacement User Guide 4.3 PSU Replacement Figure 45: CMAs in service position (Cables not shown) Step 2 : Locate the faulty PSU by finding the amber LED lit at the rear of the enclosure. Step 3 : Detach the retention clip from the PSU cable. Figure 46: Cable Retention Mechanism Step 4 : Remove the power cable from the faulty PSU.
  • Page 81 4. Part Replacement User Guide 4.3 PSU Replacement a. Grasp the release lever and the metal handle in a downward pinching motion to release the latching mechanism. Figure 47: Uninstalling PSU b. Pull the PSU straight out with even pressure. Step 6 : Remove the new PSU from its packaging.
  • Page 82 4. Part Replacement User Guide 4.3 PSU Replacement Figure 48: Installing the PSU c. Plug the power cable into the receptacle at the back of the PSU. d. Loop the retention clip on the PSU cables around the cable and pinch it until the clip catches and locks in place.

  • Page 83: System Fan Replacement

    4. Part Replacement User Guide 4.4 System Fan Replacement Figure 50: Cinching Cable Retention Clip Step 8 : Make sure the CMA(s) is in operational position by folding the arm(s) in toward the enclosure and attaching the elbow end(s) to the connector(s) attached to the rail. Verify that all of the cabling is in functional order and does not bind or catch.
  • Page 84 4. Part Replacement User Guide 4.4 System Fan Replacement Step 2 : Locate the faulty System Fan by the flashing amber LED near the rear of the drive bay and the center channel that will be lit on top if there is a fault or by activating the identify LED on the System Fan being replaced.
  • Page 85 4. Part Replacement User Guide 4.4 System Fan Replacement Figure 54: Removing System Fans Step 5 : Remove the new System Fan from its packaging. Step 6 : Install the System Fan. a. Lift the System Fan flap and look inside the empty slot that will receive the System Fan and orient the System Fan so that the connector on the bottom of the fan is on the proper side.

  • Page 86: Drive Assembly Replacement

    4. Part Replacement User Guide 4.4 System Fan Replacement Figure 56: Installing a System Fan c. When the fan is fully inserted and the connectors are mated properly, close the housing cover clip as shown in the following image. Figure 57: Latching the Fan Housing Closed Step 7 : Push the chassis back into the rack.

  • Page 87: Drive Assembly Replacement

    4. Part Replacement User Guide 4.5 Drive Assembly Replacement 4.5   Drive Assembly Replacement Table 40: Replacement Procedure Info Required Tools # of People Required Time Required Replacement Window None 5 Minutes Step 1 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches.
  • Page 88 4. Part Replacement User Guide 4.5 Drive Assembly Replacement a. Find the latch release mechanism on the Drive Assembly being removed. b. Insert a finger and a thumb into the latch release and pinch to unlatch the Drive Assembly. Figure 60: Unlatch Drive Carrier (IOM Not Shown) c.
  • Page 89 4. Part Replacement User Guide 4.5 Drive Assembly Replacement Figure 61: Removing Drive Assembly Step 4 : Remove the new Drive Assembly from its packaging. Step 5 : Install the Drive Assembly. a. Ensure that the enclosure has been pulled out of the rack until the rail latches engage. b.
  • Page 90 4. Part Replacement User Guide 4.5 Drive Assembly Replacement Figure 62: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.

  • Page 91: System Ssd Replacement

    4. Part Replacement User Guide 4.6 System SSD Replacement Figure 63: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 6 : Push the enclosure back into the rack to ensure proper cooling. 4.6  ...
  • Page 92 4. Part Replacement User Guide 4.6 System SSD Replacement Figure 64: Chassis Handle Operation Step 2 : Identify the faulty System SSD by looking for the illuminated fault LED. Step 3 : Uninstall the System SSD. a. Lift the center channel flap and press the latch release as shown in the following image. Figure 65: Lift the Center Channel Flap Figure 66: Latch Release b.
  • Page 93 4. Part Replacement User Guide 4.6 System SSD Replacement Figure 67: System SSD Removal Step 4 : Remove the new System SSD from its packaging. Step 5 : Install the System SSD. a. Lift the center channel flap and orient the assembly so that the latch release button is facing toward the rear of the system.

  • Page 94: Dimm Replacement

    4. Part Replacement User Guide 4.7 DIMM Replacement Figure 69: System SSD Install a. Once the SSD will not lower any further, press the handle down until it clicks into place. Figure 70: System SSD Carrier Latching Closed Step 6 : Push the chassis back into the rack. Verify that the fan have slowed to their regular RPM. This ensures that the enclosure is back to its proper cooling settings.
  • Page 95 4. Part Replacement User Guide 4.7 DIMM Replacement Note: The DIMMs are not hot swappable. The enclosure must be powered-down, disconnected from all cabling, and removed from the rack before replacing the DIMMs. Table 42: Procedure Info Required Tools Required Parts # of People Required Time Required •...
  • Page 96 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 72: Unlatching a CMA Connector Step 3 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches. The safety latches will prevent the enclosure from coming out of the rack completely and the cover will remain in the rack attached to the rear alignment brackets.
  • Page 97 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 74: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 75: Removing Drive Assembly...
  • Page 98 4. Part Replacement User Guide 4.7 DIMM Replacement Step 6 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 99 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 77: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e.
  • Page 100 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 78: Lift the System Fan Flap Figure 79: Unlatching System Fan b. Use the handle to pull evenly on the component to remove it from the enclosure.
  • Page 101 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 80: Removing System Fans Step 12 : Uninstall the rest of the system fans in the same manner as the first. Step 13 : Uninstall server cover panel on the side of the enclosure that contains the failed DIMM. Note: Uninstall the server cover panel on the side that requires the DIMM replacement.
  • Page 102 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 81: Removing the Server Cover Panel Screws b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 82: Removing the Server Cover Panel Step 14 : Uninstall the fan bay.
  • Page 103 4. Part Replacement User Guide 4.7 DIMM Replacement Note: The Fan Bays must be uninstalled to gain access to the DIMMs located closest to the front of the enclosure. The DIMMs located closest to the rear of the enclosure may be replaced without removing the Fan Bays as indicated by the red boxes in the following image.
  • Page 104 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 84: Removing the Fan Bay Screw b. Locate the pin that secures the outside of the fan bay to the chassis and pull the pin out and pull up on the fan bay until the cage is clear of the chassis. Note: The fan bay is connected to the baseboard with a cable and does not need to be disconnected.
  • Page 105 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 85: Fan Bay Pin Figure 86: Removing the Fan Bay c. Remove the screws that secure the plenum in place and lift the plenum off of the chassis.
  • Page 106 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 87: Removing the Plenum Step 15 : Uninstall the DIMMs. a. Locate the DIMM in need of replacement. Note: If the DIMM being removed is in the slot closest to the System Fan Bay, take special care while removing the DIMM.
  • Page 107 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 88: DIMMs near the System Fan Bay b. Carefully push apart on the DIMM ejector tabs located on either side of the DIMM slots.
  • Page 108 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 89: DIMM Ejector Tabs c. Slide the DIMM out of the of DIMM slot and set it aside. Figure 90: DIMM Removal Step 16 : Install the DIMMs. a. Remove the new DIMM from the packaging and hold it by the corners to avoid damaging the DIMM.
  • Page 109 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 91: Installing the DIMM into the DIMM Slot c. Firmly press the DIMM into the slot until the ejector tabs snap into place over the notches on either side of the DIMM. Figure 92: DIMM Notches Step 17 : Install the fan bay.
  • Page 110 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 93: Installing the Plenum b. Align the fan bay within the location that in which it was uninstalled. c. Slide the fan bay into the chassis taking care not to pinch or damage any cables. Figure 94: Installing the Fan Bay d.
  • Page 111 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 95: Fan Bay Pin Engaged e. Install the screw that secures the fan bay to the chassis.
  • Page 112 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 96: Fan Bay Screw Step 18 : Install server cover panels. a. Align and press the server panel cover into place over the server bay. Note: The Formex material that the panel is made from is flexible and will allow for the panel to be flexed to fit back into its original placement.
  • Page 113 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 98: Server Cover Panel Screws Step 19 : Install the System Fan. a. Lift the System Fan flap and look inside the empty slot that will receive the System Fan and orient the System Fan so that the connector on the bottom of the fan is on the proper side.
  • Page 114 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 100: Installing a System Fan c. When the fan is fully inserted and the connectors are mated properly, close the housing cover clip as shown in the following image. Figure 101: Latching the Fan Housing Closed Step 20 : Install the remaining system fans in the same manner as the first.
  • Page 115 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 102: Extend Mid-Rails Step 22 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 103: Bearing Plate...
  • Page 116 4. Part Replacement User Guide 4.7 DIMM Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way. Ensure that the appropriate measures are taken to safely support the enclosure during installation.
  • Page 117 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 105: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 118 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 106: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 119 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 107: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 120 4. Part Replacement User Guide 4.7 DIMM Replacement Figure 108: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 26 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 121 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 122: Cpu And Heat Sink Module Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 123: Cpu And Heat Sink Module Replacement

    4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement 4.8   CPU and Heat Sink Module Replacement Note: The CPU and Heat Sink module are not hot swappable. The enclosure must be powered- down, disconnected from all cabling, and removed from the rack before replacing the CPU and Heat Sink module.
  • Page 124 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement a. Release all of the connectors that attach the CMA(s) to the enclosure and the rail. There are three total connections that need to be released, one at the elbow and two at the opposite end.
  • Page 125 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 114: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 115: Removing Drive Assembly...
  • Page 126 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Step 6 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 127 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 117: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e.
  • Page 128 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 118: Lift the System Fan Flap Figure 119: Unlatching System Fan b. Use the handle to pull evenly on the component to remove it from the enclosure.
  • Page 129 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 120: Removing System Fans Step 12 : Uninstall the rest of the system fans in the same manner as the first. Step 13 : Uninstall server cover panel on both sides of the enclosure that contains the failed CPU and Heat Sink module.
  • Page 130 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 121: Removing the Server Cover Panel Screws b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 122: Removing the Server Cover Panel Step 14 : Uninstall the fan bays.
  • Page 131 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 123: Removing the Fan Bay Screws b. Locate the pin that secures the outside of the fan bay to the chassis and pull the pin out and pull up on the fan bay until the cage is clear of the chassis. Note: The fan bay is connected to the baseboard with a cable and does not need to be disconnected.
  • Page 132 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 124: Fan Bay Pin Step 15 : Uninstall the remaining fan bay in the same manner as the first. Step 16 : Uninstall the System Fan Bay. a. Loosen the captive screws that secure the system fan bay to the chassis using a T15 Torx Screwdriver until the cover comes loose.
  • Page 133 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 125: Loosening the System Fan Bay Captive Screws b. Slide the system fan bay out of the chassis and set it aside.
  • Page 134 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 126: Removing the System Fan Bay Step 17 : Uninstall the System Fan base. a. Slide the system fan base up and over the CPUs until clear of the CPUs. Set the system fan base to the side with cables still attached.
  • Page 135 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 128: Uninstalling the CPU LED Brackets Step 18 : Uninstall the CPU and Heat Sink module. a. Locate the failed CPU and Heat Sink module. b. The Heat Sink must be removed by loosening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order.
  • Page 136 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement b. Carefully place the CPU and Heat Sink module in position on the socket alignment pins. Figure 130: Heat Sink Alignment Pins c. The Heat Sink must be installed by tightening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order.
  • Page 137 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 131: Heat Sink Installation Order Step 20 : Install the System Fan base. a. Slide the system fan base down over the CPUs until the base rests on the baseboard. b.
  • Page 138 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement b. Lift the system fan flap and push in and tighten the captive screws until the system fan bay is secure. Figure 133: Lift the System Fan Flap Figure 134: Installing the System Fan Bay Captive Screws Step 22 : Install the fan bay.
  • Page 139 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement a. Align the first fan bay within the location that in which it was uninstalled. b. Slide the fan bay into the chassis taking care not to pinch or damage any cables. Figure 135: Installing the Fan Bay c.
  • Page 140 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 136: Fan Bay Pin Engaged d. Install the screw that secures the mid-bulkhead fan cage to the chassis.
  • Page 141 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 137: Fan Bay Screw Step 23 : Install the remaining fan bay in the same manner as the first. Step 24 : Install server cover panels. a. Align and press the server panel cover into place over the server bay. Note: The Formex material that the panel is made from is flexible and will allow for the panel to be flexed to fit back into its original placement.
  • Page 142 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement b. Secure the server cover panel using the original screws and a T7 Torx screwdriver. Figure 139: Server Cover Panel Screws Step 25 : Install the System Fan. a. Lift the System Fan flap and look inside the empty slot that will receive the System Fan and orient the System Fan so that the connector on the bottom of the fan is on the proper side.
  • Page 143 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 141: Installing a System Fan c. When the fan is fully inserted and the connectors are mated properly, close the housing cover clip as shown in the following image. Figure 142: Latching the Fan Housing Closed Step 26 : Install the remaining system fans in the same manner as the first.
  • Page 144 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 143: Extend Mid-Rails Step 28 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged).
  • Page 145 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way.
  • Page 146 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 146: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 147 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 147: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 148 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 148: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 149 4. Part Replacement User Guide 4.8 CPU and Heat Sink Module Replacement Figure 149: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 32 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 150 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 151: Heat Sink Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 152 4. Part Replacement User Guide 4.9 Heat Sink Replacement 4.9   Heat Sink Replacement Note: The Heat Sink is not hot swappable. The enclosure must be powered-down, disconnected from all cabling, and removed from the rack before replacing the Heat Sink. Table 44: Procedure Info Required Tools Required Parts...
  • Page 153 4. Part Replacement User Guide 4.9 Heat Sink Replacement b. Remove one cable at a time from the arm, making sure not to put too much strain on the arm. Step 2 : Remove the CMA(s). a. Release all of the connectors that attach the CMA(s) to the enclosure and the rail. There are three total connections that need to be released, one at the elbow and two at the opposite end.
  • Page 154 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 155: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 156: Removing Drive Assembly...
  • Page 155 4. Part Replacement User Guide 4.9 Heat Sink Replacement Step 6 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 156 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 158: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e.
  • Page 157 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 159: Lift the System Fan Flap Figure 160: Unlatching System Fan b. Use the handle to pull evenly on the component to remove it from the enclosure.
  • Page 158 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 161: Removing System Fans Step 12 : Uninstall the rest of the system fans in the same manner as the first. Step 13 : Uninstall server cover panel on both sides of the enclosure that contains the failed Heat Sink. Note: Uninstall the server cover panel on the side that requires the CPU replacement.
  • Page 159 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 162: Removing the Server Cover Panel Screws b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 163: Removing the Server Cover Panel Step 14 : Uninstall the fan bays.
  • Page 160 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 164: Removing the Fan Bay Screws b. Locate the pin that secures the outside of the fan bay to the chassis and pull the pin out and pull up on the fan bay until the cage is clear of the chassis. Note: The fan bay is connected to the baseboard with a cable and does not need to be disconnected.
  • Page 161 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 165: Fan Bay Pin Step 15 : Uninstall the remaining fan bay in the same manner as the first. Step 16 : Uninstall the System Fan Bay. a. Lift the system fan flap and loosen the captive screws that secure the system fan bay to the chassis until the cover comes loose.
  • Page 162 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 166: Lift the System Fan Flap Figure 167: Loosening the System Fan Bay Captive Screws b. Slide the system fan bay out of the chassis and set it aside.
  • Page 163 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 168: Removing the System Fan Bay Step 17 : Uninstall the System Fan base. a. Slide the system fan base up and over the CPUs until clear of the CPUs. Set the system fan base to the side with cables still attached.
  • Page 164 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 170: Uninstalling the CPU LED Brackets Step 18 : Uninstall the Heat Sink. a. Locate the failed Heat Sink. b. The Heat Sink must be removed by loosening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order.
  • Page 165 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 172: Removing the CPU from the Heat Sink with a Spudger b. Insert the edge of a plastic spudger in between the CPU and Heat Sink and carefully pry the two components apart. The plastic spudger may need to be worked around the edges of the entire CPU and Heat Sink to separate the two parts.
  • Page 166 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 173: CPU and CPR Retainer Triangles c. Unpack and remove the protective plastic tray that is attached to the bottom of the Heat Sink. The protective plastic tray protects the thermal compound until it is ready to be installed.
  • Page 167 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 174: Heat Sink Chamfer e. Press the CPU retainer firmly into the Heat Sink to ensure the thermal compound is evenly spread out across the CPU.
  • Page 168 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 175: Attaching the CPU to the Heat Sink Step 21 : Install the Heat Sink onto the CPU socket. a. Locate the socket alignment pin on the baseboard and the alignment hole on the Heat Sink.
  • Page 169 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 176: Heat Sink Alignment Pins c. The Heat Sink must be installed by tightening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order. Note: The Heat Sink screws must be tightened to a torque setting of 12in.-lbs.
  • Page 170 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 177: Heat Sink Installation Order Step 22 : Install the System Fan base. a. Slide the system fan base down over the CPUs until the base rests on the baseboard. b. Slide the LED cable and LED bracket into the Heat Sink channel and snap it into place at the top of the Heat Sink.
  • Page 171 4. Part Replacement User Guide 4.9 Heat Sink Replacement b. Lift the system fan flap and push in and tighten the captive screws until the system fan bay is secure. Figure 179: Lift the System Fan Flap Figure 180: Installing the System Fan Bay Captive Screws (highlighted in red) Step 24 : Install the fan bay.
  • Page 172 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 181: Installing the Fan Bay c. Ensure that the pin located on the inside of the fan bay is latched onto the chassis during the process of seating the fan bay. If the pin did not engage, use a Flathead screwdriver to disengage the pin by pulling it out and repositioning the fan bay until the pin engages with the chassis.
  • Page 173 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 182: Fan Bay Pin Engaged d. Install the screw that secures the mid-bulkhead fan cage to the chassis.
  • Page 174 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 183: Fan Bay Screw Step 25 : Install the remaining fan bay in the same manner as the first. Step 26 : Install server cover panels. a. Align and press the server panel cover into place over the server bay. Note: The Formex material that the panel is made from is flexible and will allow for the panel to be flexed to fit back into its original placement.
  • Page 175 4. Part Replacement User Guide 4.9 Heat Sink Replacement b. Secure the server cover panel using the original screws and a T7 Torx screwdriver. Figure 185: Server Cover Panel Screws Step 27 : Install the System Fan. a. Lift the System Fan flap and look inside the empty slot that will receive the System Fan and orient the System Fan so that the connector on the bottom of the fan is on the proper side.
  • Page 176 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 187: Installing a System Fan c. When the fan is fully inserted and the connectors are mated properly, close the housing cover clip as shown in the following image. Figure 188: Latching the Fan Housing Closed Step 28 : Install the remaining system fans in the same manner as the first.
  • Page 177 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 189: Extend Mid-Rails Step 30 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 190: Bearing Plate...
  • Page 178 4. Part Replacement User Guide 4.9 Heat Sink Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way. Ensure that the appropriate measures are taken to safely support the enclosure during installation.
  • Page 179 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 192: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 180 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 193: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 181 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 194: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 182 4. Part Replacement User Guide 4.9 Heat Sink Replacement Figure 195: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 34 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 183 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 184: Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 185: Replacement

    4. Part Replacement User Guide 4.10 M.2 Replacement 4.10   M.2 Replacement Table 45: Procedure Info Required Tools Required Parts # of People Required Time Required • • T7 Torx Screwdriver T7 Torx screws 1h 30m Step 1 : Uncable the CMA(s). a.
  • Page 186 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 199: Unlatching a CMA Connector Step 3 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches. The safety latches will prevent the enclosure from coming out of the rack completely and the cover will remain in the rack attached to the rear alignment brackets.
  • Page 187 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 201: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 202: Removing Drive Assembly...
  • Page 188 4. Part Replacement User Guide 4.10 M.2 Replacement Step 6 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 189 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 204: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e.
  • Page 190 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 205: Removing the Server Cover Panel Screws b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 206: Removing the Server Cover Panel Step 12 : Uninstall the M.2.
  • Page 191 4. Part Replacement User Guide 4.10 M.2 Replacement a. Locate the M.2 installed on the baseboard. b. Remove the Philips head screw that secures the M.2 to the baseboard. Figure 207: M.2 Screw c. Pull the top M.2 out of the connector. Figure 208: Uninstalling the M.2s d.
  • Page 192 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 209: M.2 Connectors b. Slide the card edge of the bottom M.2 into the M.2 connector on the baseboard. c. Slide the card edge of the top M.2 into the M.2 connector on the baseboard. Figure 210: M.2 Install (Top) d.
  • Page 193 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 211: M.2 Screw Step 14 : Install server cover panels. a. Align and press the server panel cover into place over the server bay. Note: The Formex material that the panel is made from is flexible and will allow for the panel to be flexed to fit back into its original placement.
  • Page 194 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 212: Installing the Server Cover Panel b. Secure the server cover panel using the original screws and a T7 Torx screwdriver. Figure 213: Server Cover Panel Screws Step 15 : Extend the mid-rails out of the rack so that they are protruding from the front of the rack and the safety latches engage.
  • Page 195 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 214: Extend Mid-Rails Step 16 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 215: Bearing Plate...
  • Page 196 4. Part Replacement User Guide 4.10 M.2 Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way. Ensure that the appropriate measures are taken to safely support the enclosure during installation.
  • Page 197 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 217: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 198 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 218: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 199 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 219: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 200 4. Part Replacement User Guide 4.10 M.2 Replacement Figure 220: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 20 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 201 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 202: Add-In Card Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 203 4. Part Replacement User Guide 4.11 Add-in Card Replacement 4.11   Add-in Card Replacement Note: The Add-in cars is not hot swappable. The enclosure must be powered-down, disconnected from all cabling, and removed from the rack before replacing the Add-in card. Table 46: Procedure Info Required Tools Required Parts...
  • Page 204 4. Part Replacement User Guide 4.11 Add-in Card Replacement There are three total connections that need to be released, one at the elbow and two at the opposite end. b. To release a connector, press the blue latch release button and pull the connector free. Figure 224: Unlatching a CMA Connector Step 3 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches.
  • Page 205 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 226: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 227: Removing Drive Assembly...
  • Page 206 4. Part Replacement User Guide 4.11 Add-in Card Replacement Step 6 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 207 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 229: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e.
  • Page 208 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 230: Removing the Server Cover Panel Screws b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 231: Removing the Server Cover Panel Step 11 : Uninstall the add-in card bracket.
  • Page 209 4. Part Replacement User Guide 4.11 Add-in Card Replacement a. From the rear of the enclosure, remove the eight screws that secure the add-in cards to the enclosure using a T10 Torx Screwdriver. Figure 232: Add-In Card Screws b. Remove the bracket from the end of the chassis. Figure 233: Add-In Card Bracket...
  • Page 210 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 234: Add-In Card Bracket Removed Step 12 : Uninstall the add-in cards. a. Locate the first add-in card. b. Remove all cabling from the add-in card. Figure 235: Add-In Card Remove Cabling and Uninstall c.
  • Page 211 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 236: Add-In Card Install and Connect Cabling Step 14 : Install the add-in card bracket. a. From the rear of in the enclosure, line the add-in card bracket up with the holes on the add-in cards.
  • Page 212 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 238: Add-In Card Bracket Installed b. Secure the bracket to the chassis with the eight T10 Torx screws that held the bracket in originally. Figure 239: Add-In Card Screws Step 15 : Install server cover panels. a.
  • Page 213 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 240: Installing the Server Cover Panel b. Secure the server cover panel using the original screws and a T7 Torx screwdriver. Figure 241: Server Cover Panel Screws Step 16 : Extend the mid-rails out of the rack so that they are protruding from the front of the rack and the safety latches engage.
  • Page 214 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 242: Extend Mid-Rails Step 17 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 243: Bearing Plate...
  • Page 215 4. Part Replacement User Guide 4.11 Add-in Card Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way. Ensure that the appropriate measures are taken to safely support the enclosure during installation.
  • Page 216 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 245: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 217 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 246: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 218 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 247: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 219 4. Part Replacement User Guide 4.11 Add-in Card Replacement Figure 248: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 21 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 220 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 221: Cma Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 222 4. Part Replacement User Guide 4.12 CMA Replacement 4.12   CMA Replacement Attention: The CMA Lite replacement package includes a CMA arm and spacer brackets. Replacing the CMA arm can be done with the enclosure in place in the rack. To replace the spacer brackets, the enclosure must be removed from the rack.
  • Page 223 4. Part Replacement User Guide 4.12 CMA Replacement Figure 252: Cable Retention Mechanism c. Power down the enclosure by disconnecting both power cables, one from each PSU. Step 3 : Disconnect the remaining cables from the enclosure. Step 4 : Uncable the CMA(s). CMA Standard: a.
  • Page 224 4. Part Replacement User Guide 4.12 CMA Replacement Figure 253: Open Baskets b. Remove one cable from the CMA at a time making sure not to put too much strain on the arm. c. Repeat these steps to remove the cables from the second arm. CMA Lite: a.
  • Page 225 4. Part Replacement User Guide 4.12 CMA Replacement Figure 254: Open Baskets b. Remove one cable from the CMA at a time making sure not to put too much strain on the arm. Step 5 : Unlatch all of the connectors that attach the CMA(s) to the enclosure and the rail by locating the latch release button and pressing it from either side of the latch.
  • Page 226 4. Part Replacement User Guide 4.12 CMA Replacement Figure 256: Chassis Handle Operation Step 7 : Follow these steps to remove a Drive Assembly. a. Find the latch release mechanism on the Drive Assembly being removed. b. Insert a finger and a thumb into the latch release and pinch to unlatch the Drive Assembly. Figure 257: Unlatch Drive Carrier (IOM Not Shown) c.
  • Page 227 4. Part Replacement User Guide 4.12 CMA Replacement Figure 258: Removing Drive Assembly Step 8 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 228 4. Part Replacement User Guide 4.12 CMA Replacement a. Be prepared to support the enclosure once it is free of the rails by having a second person or a lift to support the enclosure b. Grasp both handles at the front of the enclosure and pull with even pressure until the enclosure will not extend further.
  • Page 229 4. Part Replacement User Guide 4.12 CMA Replacement Figure 261: Captive Screws Removal b. Remove the nut plate from the mounting pin on the back of the spacer bracket. Figure 262: Rack Spacer Nut Plate Removal c. Remove the spacer brackets from the rack.
  • Page 230 4. Part Replacement User Guide 4.12 CMA Replacement Figure 263: Spacer Bracket Removal Step 12 : CMA Lite: Install the new spacer brackets. a. Line the spacer bracket up with the bottom of rack unit location of the installed outer rails. The bottom of the spacer bracket will rest on top of the bottom outer rail pin.
  • Page 231 4. Part Replacement User Guide 4.12 CMA Replacement Figure 264: Spacer Bracket Orientation Figure 265: Spacer Bracket Placement...
  • Page 232 4. Part Replacement User Guide 4.12 CMA Replacement b. Slide the nut plate down over the mounting pin on the back of the spacer bracket. Figure 266: Rack Spacer Nut Plate Installation c. Using a T15 Torx screwdriver, tighten the top captive screw to secure the mounting plate in place.
  • Page 233 4. Part Replacement User Guide 4.12 CMA Replacement a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 268: Bearing Plate Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way.
  • Page 234 4. Part Replacement User Guide 4.12 CMA Replacement Figure 269: Installing the Chassis d. Once the rails are mated properly, slide the enclosure into the rack until it is stopped by the safety catch on the rails. Push the release lever on the safety latch (located on the side of each of the rails), and push the enclosure the rest of the way into the rack.
  • Page 235 4. Part Replacement User Guide 4.12 CMA Replacement Step 14 : Install the CMA(s). Note: CMA has one arm, to be installed at the lower position. This arm should have the elbow on the left side. a. Orient the CMA so that the elbow is on the left hand side. b.
  • Page 236 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 237 Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 238 4. Part Replacement User Guide 4.12 CMA Replacement Step 18 : Secure the chassis top cover to the rack using the captive M5 thumb-screws as shown in the following image. Use a T15 Torx screwdriver, and tighten the screws to 3.38-3.61 Nm / 30-32 in- lbf.
  • Page 239 4. Part Replacement User Guide 4.12 CMA Replacement a. Ensure that the enclosure has been pulled out of the rack until the rail latches engage. b. Find the LED pointer on the top of the drive carrier. This pointer should point toward the front of the unit as shown in the following image.
  • Page 240 4. Part Replacement User Guide 4.12 CMA Replacement Figure 277: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 23 : Install each drive in the same way the first was installed. Make sure to follow the drive layout in numerical sequence as shown in the following image.
  • Page 241 4. Part Replacement User Guide 4.12 CMA Replacement Figure 278: Drive Layout Step 24 : Now that the drives are installed into the chassis, test the installation by sliding the enclosure in and out of the rack a minimum of three times. If the enclosure binds, catches, or displays any incorrect motion or behavior retry the installation of the drives and chassis.

  • Page 242: Rails Replacement

    4. Part Replacement User Guide 4.13 Rails Replacement Figure 279: Shipping Bracket Screw Locations Figure 280: Shipping Bracket Screw Locations (CMA Lite) Step 26 : Plug the enclosure power cords into a PDU to power the enclosure. Step 27 : Press the power button at the back of the enclosure to power it up. Step 28 : Double check the power indicators and other LEDs to ensure that the system is booting.
  • Page 243 4. Part Replacement User Guide 4.13 Rails Replacement Table 48: Procedure Info Required Tools Required Parts # of People Required Time Required • • Long T15 Torx Reuse: M5 x 12mm T15 Screwdriver Flat Head Torx screws • • # 2 Philips Screwdriver Reuse:Included Washers •...
  • Page 244 4. Part Replacement User Guide 4.13 Rails Replacement Figure 282: CMAs in service position (Cables not shown) Step 2 : Disconnect the Enclosure from power. a. Locate the redundant PSUs at the rear of the enclosure. b. Detach the cable retention clip from both power cords. Figure 283: Cable Retention Mechanism c.
  • Page 245 4. Part Replacement User Guide 4.13 Rails Replacement a. Open all of the basket clips on the CMA(s). Figure 284: Open Baskets b. Remove one cable at a time from the arm, making sure not to put too much strain on the arm.
  • Page 246 4. Part Replacement User Guide 4.13 Rails Replacement Figure 285: Unlatching a CMA Connector Step 5 : Complete the previous step for the second CMA. Warning: The following steps regarding uninstalling drives from the enclosure should be followed in order to reduce the weight enough to remove the chassis during the rails replacement process.
  • Page 247 4. Part Replacement User Guide 4.13 Rails Replacement Figure 287: Unlatch Drive Carrier (IOM Not Shown) c. Lift the Drive Assembly free from the enclosure. Figure 288: Removing Drive Assembly...
  • Page 248 4. Part Replacement User Guide 4.13 Rails Replacement Step 8 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 249 4. Part Replacement User Guide 4.13 Rails Replacement c. Locate the safety catches on the inner rails attached to the enclosure. Figure 291: Safety Latch Release d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward.
  • Page 250 4. Part Replacement User Guide 4.13 Rails Replacement Figure 292: Remove Inner Rail b. Locate and unlatch the springlock on the side of the inner rail. Figure 293: Inner Rail Spring Latch c. Slide the inner rail toward the front of the enclosure to unlock it from the pegs that secure it to the sidewall and pull it free.
  • Page 251 4. Part Replacement User Guide 4.13 Rails Replacement a. Uninstall the alignment bracket by removing the screws that secure it to the rack posts using the screw locations in the following image. Be careful, the alignment bracket will be free once the screws are removed. Make sure you have a solid grip on it before removing the final screw.
  • Page 252 4. Part Replacement User Guide 4.13 Rails Replacement Figure 295: Rack Latch Bracket Installed Step 15 : Uninstall the rack rails from the rack. a. From the front of the rack, locate the release clip as shown in the following image. Figure 296: Front Rail Release Clip Operation...
  • Page 253 4. Part Replacement User Guide 4.13 Rails Replacement b. Press the release clip and press lightly toward the rear of the rack to compress the rail clear of the rack post. c. Let go of the rail and move to the rear of the rack. d.
  • Page 254 4. Part Replacement User Guide 4.13 Rails Replacement Step 18 : Install the inner rail onto the chassis making sure they are installed on the correct side. Each inner rail will read "R" for the right or "L" for the left embossed on the side that faces away from the chassis.
  • Page 255 4. Part Replacement User Guide 4.13 Rails Replacement Install the three special low-profile M4 x 3.2mm Philips screws provided to secure the inner rail to the chassis. e. Follow these steps for the second inner rail on the opposite side of the enclosure. Step 19 : Install the outer rails into the rack.
  • Page 256 4. Part Replacement User Guide 4.13 Rails Replacement Figure 302: Front Rail Release Clip Operation g. Use a level to make sure that the rails are aligned properly. h. Follow these steps for the other outer rail. Step 20 : Install the rear cover alignment brackets. a.
  • Page 257 4. Part Replacement User Guide 4.13 Rails Replacement b. Use five of the M5 x 12mm T15 Flat Head Torx screws and five of the included washers and attach the rear cover alignment bracket to the vertical rail with the Long T15 Torx Screwdriver.
  • Page 258 4. Part Replacement User Guide 4.13 Rails Replacement Figure 305: Screw Installation Location Step 21 : CMA Standard: Install the two rack latch brackets at the front of the rack. a. Orient the brackets so that the screw holes are between the two pins supporting the outer rails as shown in the following image.
  • Page 259 4. Part Replacement User Guide 4.13 Rails Replacement Figure 306: Rack Latch Bracket Installed b. Use 6 of the included M5 x 12mm screws and the T15 Torx screwdriver to install each bracket, 3 screws per bracket. Caution: Always install the top cover onto the enclosure before installing the chassis into a rack.
  • Page 260 4. Part Replacement User Guide 4.13 Rails Replacement Figure 307: Bearing Plate Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way.
  • Page 261 4. Part Replacement User Guide 4.13 Rails Replacement Figure 308: Installing the Chassis d. Once the rails are mated properly, slide the enclosure into the rack until it is stopped by the safety catch on the rails. Push the release lever on the safety latch (located on the side of each of the rails), and push the enclosure the rest of the way into the rack.
  • Page 262 4. Part Replacement User Guide 4.13 Rails Replacement Step 23 : Secure the chassis top cover to the rack using the captive M5 thumb-screws as shown in the following image. Use a T15 Torx screwdriver, and tighten the screws to 3.38-3.61 Nm / 30-32 in- lbf.
  • Page 263 4. Part Replacement User Guide 4.13 Rails Replacement Figure 312: Shipping Bracket Screw Locations (CMA Lite) Step 25 : Install the Drive Assembly. a. Ensure that the enclosure has been pulled out of the rack until the rail latches engage. b. Find the LED pointer on the top of the drive carrier. This pointer should point toward the front of the unit as shown in the following image.
  • Page 264 4. Part Replacement User Guide 4.13 Rails Replacement Figure 313: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 265 4. Part Replacement User Guide 4.13 Rails Replacement Figure 314: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 26 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 266 4. Part Replacement User Guide 4.13 Rails Replacement Figure 315: CMA Orientation c. Slowly slide the enclosure forward to ensure the arm is operating properly, then slide it back into the rack. a. CMA Standard: Repeat these steps to install the upper arm with the elbow facing to the right.
  • Page 267 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 268: Chassis Replacement

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.
  • Page 269 4. Part Replacement User Guide 4.14 Chassis Replacement 4.14   Chassis Replacement Table 49: Procedure Info Required Tools Required Parts # of People Required Time Required • Long T15 Torx • M5 x 12mm T15 Flat Screwdriver Head Torx screws •...
  • Page 270 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 319: CMAs in service position (Cables not shown) Step 2 : Disconnect the Enclosure from power. a. Locate the redundant PSUs at the rear of the enclosure. b. Detach the cable retention clip from both power cords. Figure 320: Cable Retention Mechanism c.
  • Page 271 4. Part Replacement User Guide 4.14 Chassis Replacement Step 3 : Disconnect any other cabling that is connected to the rest of the rear IO ports. Step 4 : Uncable the CMA(s). a. Open all of the basket clips on the CMA(s). Figure 321: Open Baskets b.
  • Page 272 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 322: Unlatching a CMA Connector Step 6 : Uninstall the PSU. a. Grasp the release lever and the metal handle in a downward pinching motion to release the latching mechanism. Figure 323: Uninstalling PSU b.
  • Page 273 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 324: Chassis Handle Operation Step 8 : Remove all of the drives from the chassis before uninstalling the chassis. Be prepared to label the drives as they are removed so they can be reinstalled in the same location in the new chassis. Step 9 : Follow these steps to remove a Drive Assembly.
  • Page 274 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 326: Removing Drive Assembly Step 10 : Follow the previous step for each drive in the enclosure. Attach a label or mark the drives with the drive slot they were removed from in order to add them to the same slot in the future. Store the drives in an ESD safe location until the drives are ready to be installed back into an enclosure.
  • Page 275 4. Part Replacement User Guide 4.14 Chassis Replacement b. Grasp both handles, one handle in each hand, and lift evenly with both hands to ensure the IOM comes out straight. This will prevent any damage to the pins on the internal connectors.
  • Page 276 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 330: Latch Release b. Grasp the handle that pops up and pull evenly to remove the component. Figure 331: System SSD Removal Step 14 : Uninstall the rest of the System SSD assemblies in the same way as the first. Step 15 : Uninstall the internal System Fan.
  • Page 277 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 332: Lift the System Fan Flap Figure 333: Unlatching System Fan b. Use the handle to pull evenly on the component to remove it from the enclosure.
  • Page 278 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 334: Removing System Fans Step 16 : Uninstall the rest of the system fans in the same manner as the first. Step 17 : Release the safety latch on the inner rails on each side of the chassis as shown in the following image.
  • Page 279 4. Part Replacement User Guide 4.14 Chassis Replacement Step 20 : Grasp both handles at the front of the enclosure and pull with even pressure to extend the chassis out of the rack until it is stopped by the safety latches. Make sure that the top cover comes with the chassis as it is extended out of the rack.
  • Page 280 4. Part Replacement User Guide 4.14 Chassis Replacement d. Depress the latch release lever for the safety latches on the rail and push the chassis very slightly forward. The chassis is now unsecured from the rack. e. Ensure that you have the proper support mechanism to hold the chassis in position, whether that be a team lifting partner or an appropriate lift.
  • Page 281 4. Part Replacement User Guide 4.14 Chassis Replacement b. Remove the server cover panel by carefully pulling on the edge where the screws were removed. Figure 339: Removing the Server Cover Panel Step 23 : Uninstall the server cover panel in the same manner as the first. Step 24 : Uninstall the fan bay.
  • Page 282 4. Part Replacement User Guide 4.14 Chassis Replacement Note: The fan bay is connected to the baseboard with a cable and does not need to be disconnected. When removing the fan bay to replace DIMMs, lay the assembly on the drive cage. Figure 341: Fan Bay Pin...
  • Page 283 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 342: Removing the Fan Bay Step 25 : Uninstall the remaining fan bay in the same manner as the first. Step 26 : Uninstall the DIMMs. a. Locate the DIMMs on both sides of the server. b.
  • Page 284 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 344: DIMM Removal Step 27 : Uninstall the System Fan Bay. a. Loosen the captive screws that secure the system fan bay to the chassis using a T15 Torx Screwdriver until the cover comes loose. The screws will be retained within the System Fan Bay while uninstalling the part.
  • Page 285 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 345: Loosening the System Fan Bay Captive Screws b. Slide the system fan bay out of the chassis and set it aside.
  • Page 286 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 346: Removing the System Fan Bay Step 28 : Uninstall the System Fan base. a. Slide the system fan base up and over the CPUs until clear of the CPUs. Set the system fan base to the side with cables still attached.
  • Page 287 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 348: Uninstalling the CPU LED Brackets Step 29 : Uninstall the CPU and Heat Sink module. a. Locate the CPU and Heat Sink modules. b. The Heat Sink must be removed by loosening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order.
  • Page 288 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 350: M.2 Screw c. Pull the top M.2 out of the connector. Figure 351: Uninstalling the M.2s d. Repeat the previous substep to remove the bottom M.2. Step 31 : Uninstall the add-in card bracket. a.
  • Page 289 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 352: Add-In Card Screws b. Remove the bracket from the end of the chassis. Figure 353: Add-In Card Bracket...
  • Page 290 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 354: Add-In Card Bracket Removed Step 32 : Uninstall the add-in cards. a. Locate the first add-in card. b. Remove all cabling from the add-in card. Figure 355: Add-In Card Remove Cabling and Uninstall c.
  • Page 291 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 356: Installing the DIMM into the DIMM Slot c. Firmly press the DIMM into the slot until the ejector tabs snap into place over the notches on either side of the DIMM. Figure 357: DIMM Notches Step 34 : Install the CPU and Heat Sink module.
  • Page 292 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 358: Heat Sink Alignment Pins c. The Heat Sink must be installed by tightening the Torx T30 screws in a specific order. Use the following diagram to determine the specific order. Note: The Heat Sink screws must be tightened to a torque setting of 12in.-lbs.
  • Page 293 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 359: Heat Sink Installation Order Step 35 : Install the System Fan base. a. Slide the system fan base down over the CPUs until the base rests on the baseboard. b. Slide the LED cable and LED bracket into the Heat Sink channel and snap it into place at the top of the Heat Sink.
  • Page 294 4. Part Replacement User Guide 4.14 Chassis Replacement b. Lift the system fan flap and push in and tighten the captive screws until the system fan bay is secure. Figure 361: Lift the System Fan Flap Figure 362: Installing the System Fan Bay Captive Screws Step 37 : Install the fan bay.
  • Page 295 4. Part Replacement User Guide 4.14 Chassis Replacement a. Align the first fan bay within the location that in which it was uninstalled. b. Slide the fan bay into the chassis taking care not to pinch or damage any cables. Figure 363: Installing the Fan Bay c.
  • Page 296 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 364: Fan Bay Pin Engaged d. Install the screw that secures the mid-bulkhead fan cage to the chassis.
  • Page 297 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 365: Fan Bay Screw Step 38 : Install the remaining fan bay in the same manner as the first. Step 39 : Install the M.2. a. Locate the M.2 connectors on the baseboard. Figure 366: M.2 Connectors b.
  • Page 298 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 367: M.2 Install (Top) d. Secure both M.2s with the Philips head screw that held the failed M.2s. Figure 368: M.2 Screw Step 40 : Install the add-in cards. a. Locate the connector for the add-in card being installed. b.
  • Page 299 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 369: Add-In Card Install and Connect Cabling Step 41 : Install the add-in card bracket. a. From the rear of in the enclosure, line the add-in card bracket up with the holes on the add-in cards.
  • Page 300 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 371: Add-In Card Bracket Installed b. Secure the bracket to the chassis with the eight T10 Torx screws that held the bracket in originally. Figure 372: Add-In Card Screws Step 42 : Install server cover panels. a.
  • Page 301 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 373: Removing the Server Cover Panel b. Secure the server cover panel using the original screws and a T7 Torx screwdriver. Figure 374: Server Cover Panel Screws Step 43 : Install the remaining server cover panel in the same manner as the first. Step 44 : Uninstall the inner rails from the sides of the chassis.
  • Page 302 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 375: Remove Inner Rail b. Locate and unlatch the springlock on the side of the inner rail. Figure 376: Inner Rail Spring Latch c. Slide the inner rail toward the front of the enclosure to unlock it from the pegs that secure it to the sidewall and pull it free.
  • Page 303 4. Part Replacement User Guide 4.14 Chassis Replacement Caution: Always install the top cover onto the enclosure before installing the chassis into a rack. Not having the top cover installed may damage the alignment brackets. Step 45 : Ensure the top cover is installed. a.
  • Page 304 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 378: Slide Inner Rail Caution: When installing the inner rail onto the chassis, make sure to only use the special Low-Profile M4 x 3.2mm Philips screws provided in the accessory kit with the CMA. These screws should be tightened to .90-1.12 Nm / 8-10 in-lbf using a # 2 Philips Screwdriver.
  • Page 305 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 380: Extend Mid-Rails Step 49 : Install the chassis into the rails. a. Extend the bearing plates on the inside of the mid-rails until they are fully forward (detent has engaged). This prevents potential damage due to improper mating of the rails. Figure 381: Bearing Plate...
  • Page 306 4. Part Replacement User Guide 4.14 Chassis Replacement Caution: This step in the installation requires a minimum of 3 individuals to install safely, two to lift and one to guide the others who may have difficulty seeing because the enclosure is in the way. Ensure that the appropriate measures are taken to safely support the enclosure during installation.
  • Page 307 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 383: Safety Latch Release e. As the chassis is slid into the rack, position one installer at the rear of the rack to ensure that the pegs on the sides of the cover will slide correctly into the rear cover alignment brackets on both sides of the rack.
  • Page 308 4. Part Replacement User Guide 4.14 Chassis Replacement Note: Adjustments of the vertical rack rails may be required to fix any issues that may occur. Step 52 : Install the CMA(s). Note: CMA has one arm, to be installed at the lower position. This arm should have the elbow on the left side.
  • Page 309 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 386: Chassis Handle Operation Step 54 : Install the IOM. Caution: If a pin on the IOM’s internal connectors is bent or damaged, the IOM will have to be replaced. For this reason it is imperative that the IOM is not forced into position, that it is inserted straight, and that the directions for installing the IOM are followed exactly.
  • Page 310 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 388: Installing the IOM e. When the IOM is lowered fully, apply light pressure with both hands evenly on the IOM body, not the handles, to seat the IOM in the connector. If the IOM won’t seat correctly, DO NOT FORCE IT.
  • Page 311 4. Part Replacement User Guide 4.14 Chassis Replacement a. Align the System SSD with the empty drive slot and lower it slowly into the slot. Do not force it. Figure 390: System SSD Install a. Once the SSD will not lower any further, press the handle down until it clicks into place. Figure 391: System SSD Carrier Latching Closed Step 57 : Install the rest of the System SSDs in the same manner as the first.
  • Page 312 4. Part Replacement User Guide 4.14 Chassis Replacement a. Lift the System Fan flap and look inside the empty slot that will receive the System Fan and orient the System Fan so that the connector on the bottom of the fan is on the proper side.
  • Page 313 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 394: Latching the Fan Housing Closed Step 59 : Install the remaining system fans in the same manner as the first. Step 60 : Install the Drive Assembly. a. Ensure that the enclosure has been pulled out of the rack until the rail latches engage. b.
  • Page 314 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 395: LED Pointer Orientation c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag.
  • Page 315 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 396: Installing a Drive Assembly d. Pinch the latch release and carefully press downward to seat the Drive Assembly the rest of the way. Step 61 : Install each drive in the place it was removed from by following the labels or marks that were added earlier.
  • Page 316 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 397: Shipping Bracket Screw Locations Figure 398: Shipping Bracket Screw Locations (CMA Lite) Step 63 : Install the PSU. a. Align the PSU in the orientation shown in the following image. b. Slide the PSU into the slot until it seats fully into the chassis.
  • Page 317 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 399: Installing the PSU c. Plug the power cable into the receptacle at the back of the PSU. d. Loop the retention clip on the PSU cables around the cable and pinch it until the clip catches and locks in place.
  • Page 318 4. Part Replacement User Guide 4.14 Chassis Replacement Figure 401: Cinching Cable Retention Clip Step 64 : Install the second PSU. Step 65 : Install the crossbar onto the CMA mounting bracket. a. Align the crossbar with the mounting peg facing down and pointing toward the CMA mounting bracket.
  • Page 319 Route all of the cables being connected to the enclosure through the open baskets. d. Close all of the baskets. e. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 320: Cabling For Cma Standard And Cma Lite

    Route all of the cables being connected to the enclosure through the open baskets. e. Close all of the baskets. f. If the Ultrastar Serv60+8 is being installed in a rack and will subsequently be transported inside that rack, it is important to use the included cable tie to wrap the CMA bundle to ensure it does not get damaged during transport.

  • Page 321: Before You Begin

    4. Part Replacement User Guide 4.15 Cabling for CMA Standard and CMA Lite 4.15   Cabling for CMA Standard and CMA Lite 4.15.1   Before You Begin The cable configurations detailed in this section are intended to provide the optimal setup for your specific configuration.

  • Page 322: Cable Configuration For Cma Lite

    4. Part Replacement User Guide 4.15 Cabling for CMA Standard and CMA Lite 4.15.2   Cabling CMA Standard 4.15.2.1   SFP+ and HD Mini-SAS Cable Configuration This configuration includes the use of up to four SFP+ and two HD Mini-SAS cables installed into a CMA arm.
  • Page 323 4. Part Replacement User Guide 4.15 Cabling for CMA Standard and CMA Lite Figure 406: Service Loop Diagram Table 52: Service Loop Lengths Cable Identifier Length to First Basket Clip 16 in / 406 mm 18 in / 457 mm 19 in / 483 mm 22 in / 559 mm 23 in / 584 mm...

  • Page 324: Chapter 5. System Management

    Western Digital System Management In This Chapter: - Storage Subsystem Firmware Upgrade..316 - Configuring OOBM Network Settings..327 - BIOS Firmware Update......329 - BMC Web GUI..........334 - Zoning............376 - Subenclosure Nickname......379 - Partially Populated Enclosures....381...

  • Page 325: Storage Subsystem Firmware Upgrade

    This section provides information on actions that should be taken before starting a firmware upgrade on the Ultrastar Serv60+8. SAS and SATA Configurations: The Ultrastar Serv60+8 will need to be taken offline for the firmware upgrade. Ensure that all user activity has been paused during the upgrade procedure. Failing to do so could result in loss of data.
  • Page 326 5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade Figure 408: Identify Product section b. From the Select Files for Download section, expand the Firmware section and select the check box for the firmware file(s). Figure 409: Select Files for Download section c.

  • Page 327: Linux Upgrade Preparation

    5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade Figure 411: Download Files Step 5 : Extract the file by unzipping the downloaded file to the desktop. 5.1.2   Linux Upgrade Preparation To prepare the firmware package for download, do the following: Step 1 : Login to the on board server host.

  • Page 328: Linux Upgrade To New Firmware

    5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade Figure 412: Ethernet Ports b. After connecting both Ethernet interfaces and obtaining IP addresses via DHCP, locate the <dev> device name from the sg_scan -i output from step 2. c. Verify that both OOBMs have IP addresses by issuing the command sg_ses <dev> -p0x7 d.
  • Page 329 5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade Important: Due to the firmware image being a .tar.gz file, the enclosure has to unpack and load the firmware onto the respective ICs which may take up to 15 minutes. Once the sg_ses_microcode command is issued wait 20 minutes to ensure the enclosure has time to perform this process.

  • Page 330: Non-Automatic Firmware Activation In Linux

    5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade Step 6 : Verify the installation is correct by repeating the sg_scan -i again. 5.1.4   Non-Automatic Firmware Activation in Linux Step 1 : Locate the <dev> device name from the sg_scan -i. Step 2 : Execute the following command to upgrade the enclosure firmware using sg_ses_microcode.

  • Page 331: Windows Upgrade Preparation

    Step 3 : Input the sg_scan -s command to find the IOM devices to ensure that they can be accessed. Note: If the Ultrastar Serv60+8 is connected to an HBA that does not present the Enclosure Services Processor to the host for management...

  • Page 332: Windows Upgrade To New Firmware

    Step 1 : Input the sg_scan -s command to find the IOM devices to ensure that they can be accessed. Note: If the Ultrastar Serv60+8 is connected to an HBA that does not present the Enclosure Services Processor to the host for management...

  • Page 333: Non-Automatic Firmware Activation In Windows

    5. System Management User Guide 5.1 Storage Subsystem Firmware Upgrade The firmware begins loading onto the IOM. The upgrade can take up to 20 minutes to complete. Important: Due to the firmware image being a .tar.gz file, the enclosure has to unpack and load the firmware onto the respective ICs which may take up to 15 minutes.

  • Page 334: Upgrading Firmware With Oobm

    Step 3 : Issue the following command to activate IOM A: sg_ses <dev> -p4 -c -d 02,00,01,00 5.1.8   Upgrading Firmware with OOBM The following procedure should be followed to upgrade the firmware of the Ultrastar Serv60+8 using the OOBM API.
  • Page 335 Step 1 : Open a web browser, go to: https:/ /portal.wdc.com/Support/s/, and download the firmware package for the Ultrastar Serv60+8. Step 2 : Extract the downloaded zip file and place file in a location that is accessible to the Ultrastar Serv60+8. Step 3 : Make a POST call to the UpdateService object using the action.

  • Page 336: Configuring Oobm Network Settings

    5. System Management User Guide 5.2 Configuring OOBM Network Settings {"ImageURI" : "tftp://<tftp IP address>/"} Windows Example: {\"ImageURI\":\"https://<https IP address>/\"} • For a non-automatic activation, send the POST request to the UpdateService object using the command: FWActivate Note: This command will perform a rolling reset of the IOMs. curl -X POST -k -u admin:admin -H "Content-type: application/ json"...
  • Page 337 5. System Management User Guide 5.2 Configuring OOBM Network Settings FF,FF,FF,00,C0,A8,00,01,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00 • Device = /dev/sg3 • IOM = 01 (IOM A) • Setting = 00 (static) • IP Address = 192.168.0.10 • Netmask = 255.255.255.0 • Gateway = 192.168.0.1 To change the OOBM network configuration on IOM B to static: sg_wr_mode /dev/sg3 --dbd --page=0x23,0x01 -- contents=e3,01,00,1A,02,00,00,00,00,00,00,00,C0,A8,00,0B, FF,FF,FF,00,C0,A8,00,01,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00...

  • Page 338: Bios Firmware Update

    5. System Management User Guide 5.3 BIOS Firmware Update This returns: e3,01,00,30,03,00,00,00,<IOM A Setting>,00,00,00,<IOM A IPaddr>,<IOM A Netmask>,<IOM A Gateway>,00,00,00,<IOM B Setting>,00,00,00,<IOM B IPaddr>,<IOM B Netmask>,<IOM B Gateway> • <IOM> = 03 (IOMA & IOMB) • <IOM A Setting> = 00 (static) or 01 (DHCP) •...

  • Page 339: Updating Bios Firmware Using Efi Boot Mode

    5. System Management User Guide 5.3 BIOS Firmware Update Before executing the BIOS update, you will need to determine what the current version of the BIOS. This version verification is required to ensure the current version of the BIOS is not incrementally larger than the BIOS update.
  • Page 340 5. System Management User Guide 5.3 BIOS Firmware Update efibootmgr The efibootmgr will display a list of boot manager options. efibootmgr Options root@root: /home/hgst/Downloads/BIOS Update# efibootmgr BootCurrent: 0014 Timeout: 1 seconds BootOrder: 0014, 0005, 0007, 0009, 000B, 000D, 000F, 0011, 0013, 0004, 0006, 0008, 000A, 000C, 0000, 0001, 0002, 000E, 0010, 0012, 0003 Boot0000* Enter Setup...

  • Page 341: Updating Bios Firmware Using The Legacy Boot Mode

    5. System Management User Guide 5.3 BIOS Firmware Update Step 5 : Verify that the BIOS has been updated using Dmidecode. a. Check the current BIOS version by issuing the command: sudo dmidecode -t 0 | grep Version A BIOS ID number will be displayed with the BIOS version number contained in it. To learn how to read the BIOS ID see: BIOS Firmware Update (page 329).
  • Page 342 5. System Management User Guide 5.3 BIOS Firmware Update d. Verify that the version of the BIOS is an earlier version than the BIOS update that you are going load. Figure 415: Example of Current BIOS Firmware Version Note: To learn how to read the BIOS ID see: BIOS Firmware Update (page 329).

  • Page 343: Bmc Web Gui

    5. System Management User Guide 5.4 BMC Web GUI a. From the Menu Bar, select System > System Information. Figure 417: System Menu — System Information b. In the System Firmware Version section, locate the BIOS ID. c. Verify that the version of the BIOS is the latest version. Figure 418: Example of Updated BIOS Firmware Version Note: To learn how to read the BIOS ID see: BIOS Firmware Update...
  • Page 344 5. System Management User Guide 5.4 BMC Web GUI Figure 419: BMC Web GUI Overview 1. Action Menu 2. Menu Bar 3. Sidebar Menu 4. Dashboard The following section provides a list of the supported browsers that can be used to access the BMC Web GUI: Table 53: Web Browser...

  • Page 345: System Mac Address

    5. System Management User Guide 5.4 BMC Web GUI The dashboard is located in the center of the webpage and acts as the main view when the BMC Web GUI loads. The dashboard contains several different views that allow the user to get a top level view of alerts, settings, general system information, and logs.
  • Page 346 5. System Management User Guide 5.4 BMC Web GUI The MAC address from the BMC and host NICs that are built into the motherboard can be calculated based on the chassis MAC address label that is affixed to the rear of the enclosure. Figure 422: MAC Address Label Location Table 54: Example MAC Address Offsets Offset...

  • Page 347: User Management

    5. System Management User Guide 5.4 BMC Web GUI Figure 423: Physical Ports Figure 424: Example of MAC Address Related to Ports 5.4.3   User Management This section provides information related to configuring user credentials, creating a user, deleting an existing user, modifying an existing user, and ending user sessions.
  • Page 348 5. System Management User Guide 5.4 BMC Web GUI Figure 425: User List 1. User List Table: The User List table contains a list of the current users that have access to the enclosure through the BMC Web GUI. The user ID, user name, user status, and network privilege can be viewed in the User List table.
  • Page 349 5. System Management User Guide 5.4 BMC Web GUI • Administrator: This user role allows the user to have full access of the BMC Web GUI. The administrator role allows for full access to BMC Web GUI configurations, features, and views. The BMC Web GUI Administrator privileges contains the following available options: Menu Bar: ◦...
  • Page 350 5. System Management User Guide 5.4 BMC Web GUI ◦ Configuration ◦ Remote Control ◦ Diagnostics Dashboard: ◦ Summary ◦ Web Session Timeout ◦ System Firmware Version • Callback: This user role is the lowest privilege level with IPMI read-only access and no access to the BMC Web GUI.
  • Page 351 5. System Management User Guide 5.4 BMC Web GUI Figure 428: Management Dashboard Step 2 : From the Menu Bar, select Configuration > Users. The User List window will appear.
  • Page 352 5. System Management User Guide 5.4 BMC Web GUI Figure 429: Configuration Menu — Users Figure 430: User List Step 3 : Modify the default Administrator credentials. a. Select root from the User List and click Modify User. The Modify User window will appear.
  • Page 353 5. System Management User Guide 5.4 BMC Web GUI Figure 431: Select Root Figure 432: Modify User — Root b. Complete the following required fields: Figure 433: Add New User • Password: Create a new password • Confirm Password: Confirm the newly created password •...
  • Page 354 5. System Management User Guide 5.4 BMC Web GUI Figure 434: User was Modified successfully Note: If it is preferred to create a completely new administrator, disable root as the Administrator. Select disable from the User Enable drop- down list and save the new configuration. Create a new administrator by following the instructions in Creating a New User (page 347) set the User Enable drop-down list value to Administrator.
  • Page 355 5. System Management User Guide 5.4 BMC Web GUI Figure 436: BMC Login • Open a browser window and navigate to the BMC Web GUI IP address. • Type a username and password. • Choose a language from the drop-down list. •...
  • Page 356 5. System Management User Guide 5.4 BMC Web GUI Step 1 : Log in to the BMC Web GUI. Figure 438: BMC Login a. Open a browser window and navigate to the BMC Web GUI IP address. b. Type a username and password c.
  • Page 357 5. System Management User Guide 5.4 BMC Web GUI 5.4.3.4   Creating a New User Note: The user is required to log in with a user that has administrator privileges to create a new user. For more information on how to log into the BMC Web GUI, see: Logging into the BMC Web GUI (page 346).
  • Page 358 5. System Management User Guide 5.4 BMC Web GUI The Add New User window will appear. Figure 442: Empty User Slot Figure 443: Add New User Fields b. Complete the following required fields: Figure 444: Add New User • User Name: Create a user name with no spaces •...
  • Page 359 5. System Management User Guide 5.4 BMC Web GUI Figure 445: User was added successfully d. Verify the user has been added to the User List. Figure 446: User added to the User List 5.4.3.5   Modifying a User Note: The user is required to log in with a user that has administrator privileges to modify a user.
  • Page 360 5. System Management User Guide 5.4 BMC Web GUI Figure 447: Configuration Menu — Users Figure 448: User List Step 2 : Modify a user. a. Select an existing user from the User List and click Modify User. The Modify User window will appear.
  • Page 361 5. System Management User Guide 5.4 BMC Web GUI Figure 449: Select a User Figure 450: Modify User b. Complete the following required fields: Figure 451: Add New User • User Name: This field cannot be edited • Change Password: Select the checkbox (this will allow the user to change the existing password) •...
  • Page 362 5. System Management User Guide 5.4 BMC Web GUI Figure 452: User was Modified successfully d. Verify the user modifications appear in the User List. The User Status and Network Privilege changes can be viewed from the user list. Figure 453: User Modified in the User List 5.4.3.6  ...
  • Page 363 5. System Management User Guide 5.4 BMC Web GUI Figure 454: Configuration Menu — Users Figure 455: User List Step 2 : Delete a user. a. Select an existing user from the User List and click Delete User. A delete user confirm message will appear.
  • Page 364 5. System Management User Guide 5.4 BMC Web GUI Figure 456: Select a User Figure 457: Delete User? b. Click OK. A user has been deleted message will appear. 5.4.3.7   Ending a User Session Note: The user is required to log in with a user that has administrator privileges to end a user session.

  • Page 365: Security Features

    5. System Management User Guide 5.4 BMC Web GUI Figure 458: System Menu — Current Users Figure 459: Current User Step 2 : Click Kill me next to the user session that needs to be ended. A delete session confirm message will appear. Figure 460: Ending a User Session Step 3 : Click OK and verify that the user session has been ended.
  • Page 366 5. System Management User Guide 5.4 BMC Web GUI Note: The user is required to log in with a user that has administrator privileges to enable security settings. For more information on how to log into the BMC Web GUI, see: Logging into the BMC Web GUI (page 346).
  • Page 367 5. System Management User Guide 5.4 BMC Web GUI Figure 462: Security Settings Step 2 : The Security settings default to a standard set of settings. If the standard settings are sufficient, exit the Security Settings section. If a new or updated settings are preferred, complete the information as shown in section below: a.
  • Page 368 5. System Management User Guide 5.4 BMC Web GUI • Failed Login Interval Time (sec): The value of 20 seconds between failed login attempts is set by default. Input a different number of seconds to change the amount of time between being locked out due to failed login attempts. The number of failed login attempts is defined by the Failed Login Attempts field.

  • Page 369: Network Settings

    5. System Management User Guide 5.4 BMC Web GUI Figure 466: Security Settings Set 5.4.5   Network Settings This section provides information related to the network settings for the BMC Web GUI. The Administrator may enable, disable, or configuring the network settings for the IPv4 Network, IPv6 Network, and VLAN. When changing any settings related to networking, it is important to notify any users of upcoming changes to avoid conflicts.
  • Page 370 5. System Management User Guide 5.4 BMC Web GUI Figure 467: Configuration Menu — IPv4 Network Figure 468: IPv4 Network Settings Step 2 : Enable and configure the IPv4 Network Settings by completing the following steps:...
  • Page 371 5. System Management User Guide 5.4 BMC Web GUI Note: No changes are needed to this section if DHCP is the preferred method. The BMC Web GUI is set to DHCP by default. Figure 469: IPv4 Network Settings — Enabled a.
  • Page 372 5. System Management User Guide 5.4 BMC Web GUI k. Secondary DNS Server: The Secondary DNS Server is obtained by DHCP by default. The Use the following IP address option must be selected to input the secondary DNS server. Step 3 : Save the new settings. A message notifying that the parameters of the IPv4 Network Settings section have been set will appear.
  • Page 373 5. System Management User Guide 5.4 BMC Web GUI Figure 471: IPv6 Network Settings Step 2 : Enable and configure the IPv6 Network Settings by completing the following steps: Figure 472: IPv6 Network Settings — Enabled a. Enable LAN Failover: The Enable LAN Failover is defaulted to disbaled. Select the checkbox to enable this feature.
  • Page 374 5. System Management User Guide 5.4 BMC Web GUI e. Link Status: The Link Status defaults to Disable. This configures the IPv6 network settings to disabled. Select another option to enable the link status. The user may select the option to enable DHCP or to use a specific IP Address. f.
  • Page 375 5. System Management User Guide 5.4 BMC Web GUI Figure 473: Configuration Menu — VLAN Figure 474: VLAN Settings Step 2 : Enable and configure the VLAN settings by completing the following steps: Figure 475: VLAN Settings — Enabled...

  • Page 376: Bmc Web Gui Firmware

    5.4.6   BMC Web GUI Firmware This section provides information related to updating BMC Web GUI firmware. The firmware update can be acquired from Western Digital support. For more information on how to get the latest version of firmware, see: Downloading Firmware from the Support Portal (page 316).
  • Page 377 5. System Management User Guide 5.4 BMC Web GUI Figure 476: Firmware Upgrade Menu Figure 477: Firmware Update Screen Step 3 : Click Choose File in the BMC Firmware Update section.
  • Page 378 5.4 BMC Web GUI Figure 478: Choose File Step 4 : Navigate to the latest version of firmware that was downloaded from the Western Digital Support site. Step 5 : Select the BMC .bin file that lists the update with the 2Fan - 2CPU option.
  • Page 379 5. System Management User Guide 5.4 BMC Web GUI Step 7 : The BMC will lose connection and the session will expire during the reboot. The BMC must reboot to complete the update. Step 8 : Log back into the BMC Web GUI. Step 9 : From the Menu Bar, select Configuration >...
  • Page 380 RubyPeak-2Fan-2Cpu-si-BMC_FW-Update.bin Step 3 : Once the update file is chosen, place the update file on a server or fileshare that is accessible to the Ultrastar Serv60+8. The Ultrastar Serv60+8 can access servers or fileshares that use the following communications protocls: • HTTP •...
  • Page 381 5. System Management User Guide 5.4 BMC Web GUI curl -k -u USERNAME:PASSWORD -X POST -i -H Content- Type:application/json -d "{\"ImageURI\" : \"http://FILESERVER/RubyPeak-2Fan-2Cpu- si-BMC_FW-Update.bin\", \"Targets\" : [\"/redfish/v1/ UpdateService/SoftwareInventory/BMC\"]}" https://BMC IP Adress/redfish/v1/UpdateService/Actions/ UpdateService.SimpleUpdate The structure of the POST command can be broken down into three components: the base command with required headers, the data object containing the address to the firmware update image, and the Redfish API target that will execute the command.

  • Page 382: Event Logs

    5. System Management User Guide 5.4 BMC Web GUI Notice that the response body returns all of the HTTP headers because the -i modifier was set. This is followed by a JSON formatted response body listing the status of the update and whether it was successful.
  • Page 383 5. System Management User Guide 5.4 BMC Web GUI Figure 485: Event Log Buttons 1. Clear Event Log: When clicked, the Clear Event Log button clears the results that currently appear in the Event Log. 2. Save Event Log: When clicked, the Save Event Log button saves the event log as a zip file containing one in hex and one in plain text Event Log report.
  • Page 384 5. System Management User Guide 5.4 BMC Web GUI Figure 487: Event Log Window Step 2 : Complete the following actions to view event logs: Figure 488: Event Log Filters a. Select an event log category: choose an event b. Severity category: Select the severity of the event type The events will populate in the table based on the selected category values.

  • Page 385: Zoning

    5. System Management User Guide 5.5 Zoning a. Change the Number of entries per page by selecting a value from the drop-down list. b. Navigate through even pages by clicking the forward button. The fast forward button skips to the last page of results. The events will populate in the table based on the selected category values and based on the selected number of entries.
  • Page 386 5.5 Zoning 5.5.1   Predefined Multi-HBA / RAID Zoning Configurations There are three predefined Multi-HBA and Multi-RAID zoning configurations for the Ultrastar Serv60+8 that are enabled at the manufacturer. The Multi-HBA portion of the configuration assists in providing better performance by allowing more than one HBA to connect and manage the system. The Multi-RAID portion of the configuration simply allows the main drive bay to connect to multiple HBAs.
  • Page 387 5. System Management User Guide 5.5 Zoning Tri HBA/RAID Zoning Configuration: The Tri HBA/RAID Zoning Configuration allows up to three redundantly configured HBAs to view a specific zone group of drives. Each host will be able to view up to 20 drives that are mapped to three HBAs.

  • Page 388: Subenclosure Nickname

    5. System Management User Guide 5.6 Subenclosure Nickname Figure 494: Quad HBA/RAID Zoning Configuration 5.6   Subenclosure Nickname 5.6.1   Setting the Subenclosure Nickname This task describes instructions for viewing and setting a subenclosure's nickname using sg_ses commands. • In the following examples, angle brackets surrounding a term (i.e.
  • Page 389 5. System Management User Guide 5.6 Subenclosure Nickname 2. the primary subenclosure is the subenclosure whose enclosure services process provides access to enclosure services information of all the subenclosures; and 3. all other subenclosures are considered secondary subenclosures. Verify Support for the Nickname Feature Step 1 : Verify the subenclosure's support for the nickname feature by using the sg_ses <device>...

  • Page 390: Partially Populated Enclosures

    5.7   Partially Populated Enclosures 5.7.1   Partial Population Configurations The Ultrastar Serv60+8 supports partially-populated configurations that allow a user to increase the size of storage based on their needs. There are specific requirements that must be followed to ensure that the enclosure functions properly during operation.
  • Page 391 5. System Management User Guide 5.7 Partially Populated Enclosures The enclosure supports a minimum of 24 SAS or SATA HDDs for a partially-populated enclosure. The center SSD channel supports a minimum configuration of no SSDs with a maximum of eight SSDs. The SSDs must be populated from the drive slots closest to the rear of the enclosure first, starting with drive slot 67 and work backward.
  • Page 392 5. System Management User Guide 5.7 Partially Populated Enclosures Note: When installing SSDs for this configuration, the preinstalled HDDs will have to be moved one entire row to the next vacant row near the front of the enclosure. Figure 496: Minimum HDD and Minimum SSD Partial Population Minimum HDD and Maximum SSD Partial Population: The enclosure supports a minimum of 24 HDDs and one SSD in the drive bay and a configuration of no SSDs in the center channel for a partially populated enclosure.

  • Page 393: Installing Drives

    5. System Management User Guide 5.7 Partially Populated Enclosures Figure 497: Minimum HDD and Maximum SSD Partial Population 5.7.2   Installing Drives This section provides steps on how to install drives into the enclosure. The enclosure is shipped with a minimum of 24 HDDs and may require HDDs to be moved to other drives slots if SSDs are being installed.
  • Page 394 5. System Management User Guide 5.7 Partially Populated Enclosures Figure 498: Chassis Handle Operation Step 2 : Locate the area that the new drives will be installed into. When adding SSDs, the drives slots may already contain a drive. The drive will have to be removed and relocated before installing the HDD.
  • Page 395 5. System Management User Guide 5.7 Partially Populated Enclosures c. Align the drive with the empty slot that will receive it. Lower it into the slot, making sure it stays level and does not snag. Figure 500: Installing a Drive Assembly d.
  • Page 396 5. System Management User Guide 5.7 Partially Populated Enclosures Figure 501: Drive Layout Step 6 : Push the enclosure back into the rack to ensure proper cooling.

  • Page 397: Chapter 6. Safety

    Western Digital Safety The following chapter provides safety and regulatory information for the Ultrastar Serv60+8. In This Chapter: - Electrostatic Discharge......389 - Optimizing Location........389 - Power Connections........389 - Power Cords..........389 - Rackmountable Systems......390 - Safety and Service........390...

  • Page 398: Electrostatic Discharge

    6.1   Electrostatic Discharge CAUTION Electrostatic discharge can harm delicate components inside Western Digital products. Electrostatic discharge (ESD) is a discharge of stored static electricity that can damage equipment and impair electrical circuitry. It occurs when electronic components are improperly handled and can result in complete or intermittent failures.

  • Page 399: Rackmountable Systems

    6.5   Rackmountable Systems CAUTION Always install rack rails and storage enclosure according to Ultrastar Serv60+8 product documentation. Follow all cautions, warnings, labels, and instructions provided within the rackmount instructions. Reliable grounding of rack-mounted equipment should be maintained.

  • Page 400: Safety Warnings And Cautions

    6. Safety User Guide 6.7 Safety Warnings and Cautions The power supply in this product contains no user-serviceable parts. Do not open the power supply. Hazardous voltage, current and energy levels are present inside the power supply. Return to manufacturer for servicing.

  • Page 401: Chapter 7. Disclaimers

    Learn about the Regulatory, Safety, and Electromagnetic standards for which this product is compliant. The following chapter describes the Regulatory Statement of Compliance, Safety Compliance, and Electromagnetic Compatibility Agency Requirements for the Ultrastar Serv60+8. In This Chapter: - Restricted Access Location.......393 - Safety Compliance........393 - Electromagnetic Compatibility (EMC) Class A Compliance..........393...

  • Page 402: Restricted Access Location

    7.1 Restricted Access Location 7.1   Restricted Access Location The Ultrastar Serv60+8 is intended for installation in a server room or computer room where at least one of the following conditions apply: • access can only be gained by service persons or by users who have been instructed about the restrictions applied to the location and about any precautions that shall be taken and/or •...

  • Page 403: Country Certifications

    7. Disclaimers User Guide 7.4 Country Certifications • EN 61000-4-3 Radiated Immunity • EN 61000-4-4 EFT • EN 61000-4-5 Surge • EN 61000-4-6 RF Common Mode • EN 61000-4-8 Power Frequency Magnetic Field • EN 61000-4-11 Voltage Dips and Interruptions 7.4  ...

  • Page 404: Chapter 8. Regulatory Statements

    Statements The following chapter provides regulatory statements for the Ultrastar Serv60+8, H4060-S . Western Digital Storage Enclosures are marked to indicate compliance to various country and regional standards. Note: Potential equipment damage: Operation of this equipment with cables that are not properly...

  • Page 405: Europe (Ce Declaration Of Conformity)

    Any modifications made to this device that are not approved by Western Digital may void the authority granted to the user by the FCC to operate equipment.
  • Page 406 8. Regulatory Statements User Guide 8.5 Taiwan Warning Label Statement, Class A ITE English translation: This is a Class A product. In a domestic environment, this product may cause radio interference, in which case, the user may be required to take adequate measures.

Table of Contents
