Press the "Activate all" softkey to execute the following steps:
1. Read out the motor data on the electronic rating plate.
2. In comparison to p0300 "Select motor type", check as to whether the configured data match
the configured component.
3. Activate the drive object.
4. Automatically calculate the controller data.
5. Overwrite parameters with the configured data from the Create MyConfig package.
6. Backup the parameters.
This operation can take several minutes. A progress display is shown.
When changing the status from "[0] deactivated" → "[1] activated" the backup of this drive object
is created in the following directory on the CompactFlash card: /user/sinamics/smi/backup. The
data for all drive objects is saved at: /user/sinamics/data
If several drive objects are selected, then you can select different procedures for each of the
individual drive objects:
1. "Only activate" softkey to activate parameters that are already saved to the CompactFlash
card.
2. "CMC data" softkey, to calculate the controller data and to activate the data saved from a
Create MyConfig package to the CompactFlash card.
3. "Last backup" softkey to restore the last data backup of the drive object from the backup file.
4. "Exit" softkey to exit the view of the drive objects.
5. You have the following alternatives after successfully completing the procedure:
– "Cancel" softkey to exit the procedure without restarting the system. As a consequence,
– Press the softkey "Accept" to activate the parameters and to execute a restart the system
Replacing a device
Service & Support Portal: (https://support.industry.siemens.com/cs/de/en/view/99457853)
SIMOTICS Service Manual: Encoder replacement for SIMOTICS S- 1FK7 G2, S-1FG1 and
S-1FT7
CNC Commissioning: NC, PLC, Drive
Commissioning Manual, 12/2019, A5E48312804B AA
the parameters are not yet active.
Reset (po).
Commissioning NC-controlled drives
