- Analogue inputs
"Analogue inputs" allows to modify the function associated to each analogue input of the
connected 100N MASTER3. The modification of an input puts the control unit in "Stand
by". In the event of an incorrect association between a probe and a function, the alarm is
signalled (Ec1 Ec3).
÷
Modification of the
function associated to
the analogue input
USER AND MAINTENANCE MANUAL
Pag. 69
Associated
function
description identification
VISION TOUCH WELLNESS
Analogue
input
Rel 01-19
Connection
terminals
