VISION TOUCH WELLNESS
Description of buttons in Button Bar:
BACK:
Inside a menu or level: Go back to previous level or menu.
In a HOME page: Go back to the previous Home page.
Indietro If held for longer than 3 seconds: Go back to HOME 1 page
PARAMETERS: Enter the parameter setting menu
Parametri
ALARMS: Enter the alarm log menu
Red: Alarm triggered
Orange: Alarm over but yet to be acquired
Blue: No Alarm triggered or to be acquired
Allarmi
If the alarm log menu contains only items already acquired (shown in black) a waste bin will
appear inside this button indicating the possibility of cancelling the entire log.
HELP:
manufacturer/installer of the instrument. The data on this page may be modified by a user
who is logged in as an installer.
Help
MANUAL AIR RENEWAL: Activates a manual air renewal or deactivates an automatic or
manual one in progress. (delayed start)
Green: Air renewal active
Ric. aria
Blue: Air renewal not active
MANUAL LIGHT BUTTON: Manually activates/deactivates the light.
Green: Light active
Blue: Light not active
Luce
MANUAL RGB LIGHT BUTTON: Manually activates/deactivates the RGB light.
Green: RGB light active
Blue: RGB light not active
RGB
STANDBY BUTTON: Activates/deactivates the standby status (delayed start)
Green: Standby active (System OFF)
Blue: Standby not active (System ON)
Standby
EXTENDED BUTTON BAR OPENING BUTTON:
Opens or closes the EXTENDED BUTTON BAR that allows access to additional buttons.
USER AND MAINTENANCE MANUAL
Pag. 24
Access the Help page that contains all the
Rel 01-19
information about the
