VISION TOUCH WELLNESS
Temperature adjustment dial: Displays all that regards temperature adjustment, in
particular:
•
The temperature set point (can be modified by pressing the dial for 3 seconds).
•
Adjustment probe temperature measurement.
•
The status of the call (Hot / No call).
Temperature value
Bar-graph
Temperature Set-Point
Bar-graph
Temperature
Set Point
Humidity adjustment dial: Displays all that regards humidity adjustment, in particular:
•
The humidity set point (can be modified by pressing the dial for 3 seconds).
•
Adjustment probe humidity measurement.
•
The status of the call (Humidify / No call).
Status of the call:
Humidify Call
No Call
Humidity
Set Point
USER AND MAINTENANCE MANUAL
Pag. 30
Status of call:
Hot Call
No Call
Adjustment probe
temperature
Humidity Set Point
Bar-graph
Humidity value
Bar-graph
Adjustment probe
humidity measurement
