VISION TOUCH WELLNESS
- Analogue inputs test
The "Analogue inputs test" allows to verify the correct acquisition of the analogue inputs
(probes) of the connected 100N MASTER3. The function associated to each digital output
can be set in "Parameters" => "Configure I/O" => "Analogue inputs".
Acquired
Input description
Input name and
Connection
value
probe type
terminals
USER AND MAINTENANCE MANUAL
Pag. 64
Rel 01-19
