VISION TOUCH WELLNESS
- Digital outputs
"Digital outputs" allows to change the function associated to each digital output of the
connected 100N MASTER3. The modification of an output puts the control unit in "Stand
by". In the event a function is not associated to at least one output, the eventual call from
the control unit will not activate any digital output (only the status icon will be activated to
indicate a call).
Digital output identification
Connection terminals
Modification of the function
Associated function icon
associated to the digital output
USER AND MAINTENANCE MANUAL
Pag. 66
Rel 01-19
