VISION TOUCH WELLNESS
- Analogue outputs
"Analogue outputs" allows to change the function associated to each analogue output of
the connected 100N MASTER3. The modification of an output puts the control unit in
"Stand by". In the event a function is not associated to at least one output, the eventual call
from the control unit will not activate any analogue output (only the status icon will be
activated to indicate a call).
Connection
Analogue
Associated
Modification of the
terminals
output
function
function associated
identification
description
to the analogue
USER AND MAINTENANCE MANUAL
Pag. 68
Rel 01-19
