VISION TOUCH WELLNESS
The "Test centre" allows to verify the proper operation of the inputs/outputs of the 100N
MASTER3 connected to the VISION TOUCH WELLNESS. One can also verify the
operation of the touchscreen sensors.
The "Test centre" function is reserved to expert users.
Pego S.r.l. disclaims any liability for damage to the system
The "Test centre" menu can be accessed from the main Configuration page ("Parameters"
Button). The display of this item can be set in the "Password" sub-menu => "Configure
user level menu" and by selecting the "Test centre" item (installer login required).
Test center
Test digital outputs
Test digital inputs
Test analogue outputs
Test analogue inputs
Touch coordinates
Verify touch sensors
USER AND MAINTENANCE MANUAL
Pag. 60
Test center
due to improper use of this function.
8.3.17
Rel 01-19
