Danger Zones - Krone ActiveMow R 200 Operating Instructions Manual

Danger resulting from damage to the machine
Damage to the machine may impair the operational safety of the machine and cause accidents.
As a result, people may be seriously injured or killed. The following parts of the machine are
particularly important for safety:
• Brakes
• Steering
• Safety Devices
• Connecting devices
• Lighting equipment
• Hydraulics
• Tyres
• Universal shaft
If there are doubts about the operational safety of the machine, for example due to an
unexpected change to the operational behaviour, visible damage or leaking consumables:
„ Shut down and secure the machine,
„ Immediately eliminate potential causes of damage, for example heavy soiling, or tighten
slack screws.
„ In case of damage which may affect operational safety and cannot be repaired according to
these operating instructions: Have damage repaired by a qualified service centre.
Technical limit values
If the technical limit values of the machine are not observed, the machine may be damaged. As
a result, accidents may occur and people may be seriously injured or killed. Observance of the
following technical limit values is particularly important for safety:
• Maximum permissible operating pressure of hydraulics
• Maximum permissible drive speed
• Maximum permissible axle loads of tractor
„ Observe the limits,
2.3.10

Danger zones

If the machine is switched on, its surrounding can present a danger zone.
Avoid entering the danger zone of the machine by observing the minimum safety distance.
If the safety distance is not observed, people may be seriously injured or killed.
„ Do not switch on the drives and engine if the minimum safety distance has not been
observed.
„ If people fail to observe the minimum safety distance, switch off the drives.
„ Switch the machine off in shunting and field mode.
The safety distance is:
For machine in shunting operation and field mode
In front of the machine
Behind the machine
Laterally to the machine
ActiveMow R 200
Original Operating Instructions 150000521_04_en
refer to
refer to page 34.
Basic safety instructions
page 24.
30 m
5 m
3 m
Safety 2
2.3
15
