NOTICE
Mixing types of oil
If types of oil are mixed, the machine could be damaged.
Never mix different types of oil.
Before changing the type of oil, consult customer service. Never use engine oil.
Bio-degradable lubricants on request
4.1.1
Oils
Designation
Input gearbox
Main gearbox
Cutterbar
The filling quantities of the gearboxes are guide values. The correct values result from oil
change/oil level check,
4.1.2
Lubricating greases
Designation
Manual lubrication points
1
Lubricate the manual lubrication point until grease escapes at the bearing position. After
lubricating, remove the grease escaping from the bearing position.
ActiveMow R 200
Original Operating Instructions 150000521_04_en
Filling quantity
0.5 l
0.3 l
4.0 l
refer to
page 64.
Filling quantity
1
As required
Technical data
Specification
SAE 90
SAE 90
SAE 90
Specification
Lubricating grease to DIN
51818 of NLGI class 2, Li
soap with EP additives
4
Consumables
4.1
Initial filling ex works
Wiolin ML 4 SAE 90
Wiolin ML 4 SAE 90
Wiolin ML 4 SAE 90
35
