- Page 1 Original Operating Instructions Document no.: 150000864_01_en Rear Mounted Mower ActiveMow R 360 From machine no.: 976393...
- Page 2 Contact Maschinenfabrik Bernard Krone GmbH & Co. KG Heinrich-Krone-Straße 10 48480 Spelle Germany Telephone switchboard + 49 (0) 59 77/935-0 Telefax switchboard + 49 (0) 59 77/935-339 Telefax spare parts warehouse do- + 49 (0) 59 77/935-239 mestic Telefax spare parts warehouse export + 49 (0) 59 77/935-359 Internet www.landmaschinen.krone.de...
-
Page 3: Table Of Contents
Lubricating greases ........................ 34 Control and Display Elements .................... 35 Hydraulic control units of the tractor .................. 35 Initial Operation........................ 36 Checklist for initial operation ...................... 36 Adapting coupling points...................... 37 Adapting universal shaft ...................... 38 ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 4 Changing blades for the “blade quick fastener” version ............ 72 14.4 Checking/replacing retaining bolts ..................... 73 14.5 Checking/replacing blade carrier .................... 74 14.6 Checking/replacing cutting discs/mower drums................. 74 14.6.1 Checking the wear limit on cutting discs/mower drums ............. 75 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 5 Checking oil level ........................ 76 Maintenance - Lubrication ...................... 78 15.1 Lubricating universal shaft ...................... 78 15.2 Lubrication chart - Machine ....................... 79 Storage............................ 81 Waste disposal......................... 83 Index............................ 84 Declaration of conformity ....................... 89 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 6: Information On This Document
Information on This Document Validity This document is valid for machines of type: ActiveMow R 360 All information, illustrations and technical data in this document correspond to the latest state at the time of publication. We reserve the right to make design changes at any time and without notification of reasons. -
Page 7: Figures
This arrow identifies the result of an action step or sequence of actions. This bullet point identifies an enumeration. If the bullet point is intended, it identifies the second level of the enumeration. Icons in figures The following icons can be used in illustrations: ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 8 CAUTION The signal word CAUTION warns of a hazardous situation which will result in minor to moderate injuries if the warning sign is ignored. Example of a warning sign: ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 9: Conversion Table
Volume flow Litres per minute L/min 0.2642 US gallons per minute Cubic metres m³/h 4.4029 per hour Force Newton 0.2248 Pound force Length Millimetre 0.03937 Inch Metre 3.2808 Foot Power Kilowatt 1.3410 Horsepower ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 10 Kilometres per km/h 0.6215 Miles per hour hour Volumes Litres 0.2642 US gallon US gal. Millilitre 0.0338 US ounce US oz. Cubic centi- cm³ 0.0610 Cubic inch in³ metre Weight Kilogram 2.2046 Pound ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 11 Information on This Document How to use this document This page has been left blank deliberately. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 12: Safety
2.3.1 Importance of operating instructions The operating instructions are an important document and a part of the machine. They are intended for the user and contain information relevant to safety. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 13: Personnel Qualification Of The Operating Personnel
Thus children are particularly at risk. „ Keep children away from the machine. „ Keep children away from consumables. „ Make sure that there are no children in the danger zone, especially when starting and triggering machine movements. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 14: Connecting The Machine
„ All maintenance and setting work must be performed according to the chapters “Maintenance and Setting”. „ Before performing any maintenance and setting work, shut down and safeguard the machine, refer to page 24. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 15: Danger Zones
„ Switch the machine off in shunting and field mode. The safety distance is: For machine in shunting operation and field mode In front of the machine 30 m Behind the machine 5 m Laterally to the machine 3 m ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 16 „ Before working between tractor and machine: Shut down and safeguard the machine, refer page 24. This also applies to short-term control work. „ If the lifting device must be actuated, instruct all persons to keep away from the range of movement of the lifting device. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 17: Ensuring Functionality Of Safety Devices
2.3.12 Personal protective equipment The wearing of personal protective equipment is an important safety measure. Missing or unsuitable personal protective equipment increases health risks and injuries. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 18: Safety Markings On The Machine
Hitched and mounted machines change the handling characteristics of the tractor. The handling characteristics depend for instance on operating state and ground. If changed handling characteristics are not considered, the driver may cause accidents. „ Observe measures for driving on road and field,refer to page 50. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 19: Parking The Machine Safely
Consumables which do not comply with the requirements of the manufacturer may impair the operational safety of the machine and cause accidents. „ Use only consumables which comply with the requirements of the manufacturer. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 20: Dangers Arising From Environment
„ Warn persons: Do not approach the machine. Electrical voltage on the ground may lead to severe electric shocks. „ Wait for help from professional rescue teams. The overhead line must be switched off. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 21: Sources Of Danger On The Machine
If hot liquids are drained, people may burn and/or scald themselves. „ When draining hot consumables, wear personal protective equipment. „ Before performing any repair, maintenance or cleaning work, allow liquids and machine parts to cool off, if necessary. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 22: Dangers In Connection With Certain Activities: Working On The Machine
„ Only perform work which is described in this operating instructions. Prior to any work, stop and safeguard the machine, refer to page 24. „ All other maintenance and repair work must only be performed by qualified specialist workshop. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 23: Behaviour In Dangerous Situations And In Case Of Accidents
Frame or supporting components • Running gear „ Before carrying out welding work on the machine, obtain consent by KRONE customer service and, if required, identify alternatives. „ Before performing welding work on the machine, park the machine safely and disconnect it from the tractor. -
Page 24: Safety Routines
„ Bricks and hollow blocks are not suitable for safely supporting the machine and machine parts. Therefore they must not be used. „ Car jacks are also not suitable for safely supporting the machine and machine parts. They must not be used, as well. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 25: Carrying Out Oil Level Check And Oil And Filter Element Changes Safely
Safety labels on the machine Every safety label is provided with an order number and can be ordered directly from the authorised KRONE dealer. Immediately replace missing, damaged and unrecognisable safety labels. When attaching safety labels, the contact surface on the machine must be clean and free of dirt, oil and grease to ensure optimum adhesion of the labels. - Page 26 Safety Safety labels on the machine Position and meaning of safety labels KM000-413 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 27 Danger due to crushing or shearing Risk of injury due to crushing or shearing points on moving machine parts. „ While parts are moving, never reach into areas where there is a risk of being crushed. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 28 „ To avoid that functions are triggered by mistake, the regulating valves of the tractor must be in neutral position and locked during road transport journeys. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 29: Safety Equipment
Support jack • The support jack is designed for the stability of the machine when it is not connected to the tractor, refer to page 44. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 30: Machine Description
Impact damage protection system Relief spring(s) cutterbar Cutterbar Lifting eye Locking for relief spring(s) Mower gearbox Stop cock Intermediate universal shaft Universally-jointed drive shaft Support jack Spare blade drawer Main gearbox Blade key ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 31: Labelling
If the impact damage protection system does not engage automatically when reversing, the machine may be damaged. „ Relieve the relief spring(s) and reverse until the impact damage protection system engages, Adjusting the relief spring(s). ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 32 Machine Description Pole protection mechanism KMG000-032 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 33: Technical Data
NOTICE Complying with change intervals for biooils To ensure high life expectancy of the machine, it is absolutely necessary to comply with change intervals for biooils due to the ageing of the oils. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 34: Oils
Lubricating grease to DIN 51818 of NLGI class 2, Li soap with EP additives Lubricate the manual lubrication point until grease escapes at the bearing position. After lubricating, remove the grease escaping from the bearing position. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 35: Control And Display Elements
Raises the mower from the working position to the transport position. Single-acting control unit (1+) Float position Lowers the mower from the headland position to the working position. (1+) Raises the mower from the working position to the headland position. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 36: Initial Operation
ü The universal shaft length has been checked and adjusted, refer to page 38. ü The blades have been inserted, refer to page 70. ü The hydraulic system has been vented. ü The friction clutch has been vented, refer to page 62. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 37: Adapting Coupling Points
„ Pull out the shorter lower link pin (3), turn it by 180° and insert it from the inside. „ Pull out the longer lower link pin (1) outwards up to the next borehole. „ Secure both lower link pins (1, 3) with the cylinder screws (2). ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 38: Adapting Universal Shaft
(shift length) of the profile tubes and guard tubes of at least 200 mm in any operating position. For further information see the operating instructions of the universal shaft manufacturer. „ Check the overlap of profile tubes and guard tubes. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 39: Start-Up
Even with a fitted rear-mounted device, the front axle of the tractor must always be loaded with a minimum 20% tare weight of the tractor. „ Make sure before starting to move that these requirements have been met. KMG000-012 ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 40: Connecting Hydraulic Hoses
Risk of injury by failure to take account of the danger zone of the universal shaft If the danger zone of the universal shaft is ignored, persons can be seriously hurt or killed. „ To avoid accidents, observe the danger zone of the universal shaft, refer to page 16. ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 41 ü The machine is shut down and safeguarded, refer to page 24. „ Slide universal shaft (1) on PTO shaft end of tractor and secure it. „ Secure universal shaft guard by means of supporting chain (2) against turning. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 42: Operation
„ Connect the guard cloths of the front guard and the side guard using the turnlock fasteners. 8.1.1 Folding up the front guard To enhance accessibility, e.g. for maintenance and repair work, the front guard can be folded ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 43: Fold Down The Front Guard
„ Pull the spring cotter pin (3) and pull the locking (2) off the bolt. „ Fold down the front guard (1), place the locking (2) onto the bolt and secure it with the spring cotter pin (3). „ Close the turnlock fasteners (4). ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 44: Side Guard
„ Secure the guard cloths using the turnlock fasteners (2). Operating support jack INFORMATION In order to increase the base of the support jack when the ground is soft, use a suitable support. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 45: Moving Support Jack Into Transport Position
„ Insert the locking pin (2) into the lower borehole and secure it with the linch pin (3). „ Lower the machine via the rear hydraulics until the machine is resting on the support jack (1, 4). „ Shut down and safeguard the machine, refer to page 24. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 46: Mounting Support Jack
ü The mower is in the transport position, refer to page 48. „ Raise the machine via the rear hydraulics so that the additional support jacks (1, 2) can be dismounted. „ Dismount the support jacks (1, 2). ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 47: Locking/Releasing Stop Cock
„ To lower the mower, move the single-acting control unit (1+) to the float position. „ Release the operating cable (2). Headland positions ü The locking (1) is folded down and the operating cable (2) is not tensioned. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 48: Mowing
„ Check the ground pressure while mowing, refer to page 55. „ To ensure a clean cutting pattern, adjust the driving and cutting speeds to the prevailing conditions (soil condition, state of the crop, height, density). ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 49 (refer to page 55) and reverse until the impact damage protection system engages. Then tension the relief spring(s) again,refer to page 55. INFORMATION Leave the control units in the float position while mowing. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 50: Driving And Transport
Even with a fitted rear-mounted device, the front axle of the tractor must always be loaded with a minimum 20% tare weight of the tractor. „ Make sure before starting to move that these requirements have been met. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 51: Preparing Machine For Road Travel
„ Lower the machine via the rear linkage enough to ensure that the maximum transport height of 4 m is not exceeded. „ Ensure adequate ground clearance. Switching off the machine KMG000-019 ü The machine is in the working position or transport position. ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 52 „ Detach the top link. „ Unlock the lower link hooks of the tractor. „ Continue to lower the rear linkage until the lower link pins are free. „ Drive the tractor away carefully. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 53: Settings
ü The machine is shut down and safeguarded, refer to page 24. „ To set the working height, raise or lower the lower link 10.2 Setting the cutting height KMG000-035 The cutting height is adjusted via the top link (1). ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 54: Checking/Setting Locking Of Side Guards
„ Move the machine to the transport position. ð If the side guard folds down, the side guard is correctly adjusted. ð If the side guard does not fold down, the lock must be adjusted. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 55: Increasing/Reducing Ground Pressure
(1) when the machine is in the working position. „ Swivel the locking (2) upwards. Æ The relief spring is or the relief springs are relieved, even if the machine is lowered to the working position. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 56: Setting The Relief Spring For The Carrying Bar
ü The machine is shut down and safeguarded, refer to page 24. „ To reduce the ground pressure, turn the spindle (2) in direction +. „ To increase the ground pressure, turn the spindle (2) to the direction -. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 57: Maintenance - General Information
Main gearbox refer to page 66 Cutterbar refer to page 76 Components Changing/replacing blades refer to page 70 Check/replace cutting discs/mower drums refer to page 74 Check/replace retaining bolt (blade screw con- refer to page 73 nection) ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 58: Maintenance - Every 10 Hours, But At Least Once A Day
Maintenance - Every 200 hours Changing oil Input gearbox refer to page 65 Main gearbox refer to page 66 11.1.6 Maintenance - Every 6 years Components Have the hydraulic hoses replaced by your KRONE service partner ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 59: Tightening Torques
The table does not apply to countersunk screws with hexagon socket in case the countersunk screw is tightened via hexagon socket. DV000-001 Thread size Strength class on screw head Strength class 10.9 12.9 Tightening torque (Nm) 1,050 1,220 1,100 1,550 1,800 1,450 2,100 2,450 ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 60 Metric thread screws with countersunk head and hexagon socket INFORMATION The table applies only to countersunk screws with hexagon socket and metric thread tightened via hexagon socket. DV000-000 Thread size Strength class on screw head ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 61 Maximum tightening torque (Nm) (±10 %) M10x1 M12 x 1.5 G1/4“ M14 x 1.5 M16 x 1.5 45 M18 x 1.5 50 M20 x 1.5 G1/2“ M22X1.5 M24x1.5 G3/4“ M33x2 G1“ M42x1.5 G1 1/4“ ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 62: Deviating Tightening Torques
„ Never intervene in the overload protection. „ Only use KRONE original spare parts. The friction clutch protects the tractor and the machine from damage. The friction clutch must be vented at the beginning of the storage period. The friction clutch is designed with a permanently adjusted turning torque M . -
Page 63: Checking Guard Cloths
„ Carry out a visual inspection of the guard cloth (1) to ensure that there are no cracks and damage. Æ The machine can be used when there are no cracks or damages. Æ Replace guard cloths in case of cracks or damage. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 64: Maintenance - Hydraulic System
Storing and disposing of oils and used oil filters If oil and used oil filters are not stored and disposed of properly, the environment may be damaged. „ Store or dispose of used oil and oil filters according to statutory provisions. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 65: Maintenance - Gearbox
„ Refill with fresh oil up to the inspection hole (1) via the filling hole (3). „ Screw on the locking screw of the inspection hole (1) and the locking screw of the filling hole (3), tightening torque refer to page 61. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 66: Main Gearbox
„ Refill with fresh oil up to the inspection hole (1) via the filling hole (3). „ Screw on the locking screw of the inspection hole (1) and the locking screw of the filling hole (3), tightening torque refer to page 61. ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 67 „ Top up new oil via the filling hole (3) up to the inspection hole (1). „ Mount the locking screw of the inspection hole (1) and the locking screw of the filling hole (3), Anziehdrehmoment refer to page 61. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 68: Maintenance - Cutterbar
(a, b). • The nuts (2) with left-handed thread (LH) have distinctive grooves (a) on the bevel. • The pinion shafts (4) with left-handed thread (LH) have a distinctive groove (b) on the face. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 69: Replacing The Shear Bolt At The Rotary Hub
„ Use the special key (10) included with delivery to unscrew the nut (2). „ Dismount the hub (1). „ Remove the damaged shear pins (3). „ Check the nut and hub for damage. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 70: Check/Change Blades
Maintenance - Cutterbar 14.3 Check/change blades INFO: Replace damaged components with KRONE original spare parts. „ Fill the space above the bearing with grease (c). „ Position the hub on the pinion shaft. INFO: Note the position of the shear pins. The slots of the shear pins (3) must be mounted facing each other horizontally, see detail (I). -
Page 71: Changing Blades For The "Blade Screw Connection" Version
ü The area around blades, cutting discs and mower drums is cleaned. „ Dismount damaged or worn blade. „ Check mounting parts of blade, refer to page 73. Also replace worn or damaged mounting parts. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 72: Changing Blades For The "Blade Quick Fastener" Version
„ Guide the blade (2) onto the retaining bolt (5) and in a controlled manner release the force of your hand on the blade key (1). „ Repeat the process for all blades „ Fold down the front guard. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 73: Checking/Replacing Retaining Bolts
„ The retaining bolts must be replaced at the latest when the material thickness at the thinnest point is below 14 mm. Blade screw connection design Blade quick fastener design KM000-039 / KM000-040 ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 74: Checking/Replacing Blade Carrier
„ The cutting discs/mower drums must be checked for damage at least once a day or after contact with foreign objects. „ If cutting discs/mower drums are deformed, the dimension X=48 mm must not be exceeded. „ The cutting discs/mower drums must only be replaced by KRONE original spare parts. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 75: Checking The Wear Limit On Cutting Discs/Mower Drums
„ The cutting discs/mower drums must be replaced at the latest when the material thickness is below the minimum material thickness of 3 mm. „ The cutting discs/mower drums must only be replaced by KRONE original spare parts. KM000-043 14.7... -
Page 76: Checking Oil Level
Checking oil level INFORMATION There is no need to change the oil on the cutterbar. Before checking the oil level on the cutterbar, the cutterbar must be aligned levelly by means of a spirit level. ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 77 If the oil does not reach the inspection hole (1): „ Top up new oil via the inspection hole (1) up to the inspection hole (1). „ Mount the locking screw of the inspection hole (1),refer to page 61. ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 78: Maintenance - Lubrication
ü The machine is shut down and safeguarded, refer to page 24. „ Observe operating instructions of the universal shaft manufacturer. „ Lubricate the universal shaft with multi-purpose grease at the intervals indicated in the figure. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 79: Lubrication Chart - Machine
Type of lubrication Lubricant Comment Grease Multi-purpose grease „ Apply two strokes of lubricating grease from the grease gun per grease nipple. „ Remove excess lubricating grease at the grease nipple. KM000-423 Every 20 operating hours ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 80 Maintenance - Lubrication 15.2 Lubrication chart - Machine KM000-432 Every 100 operating hours ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 81: Storage
„ Touch up damaged paint and preserve all uncoated areas thoroughly with rust protection agent. „ Check all moving components for smooth running. If necessary remove, clean, grease and remount. „ If parts need to be replaced, use KRONE original spare parts only. ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 82 Write down all repair jobs which must be performed by the next harvest and arrange for them to be done with sufficient lead time. Your KRONE dealer is better able to perform maintenance service and any required repairs outside of harvest season.
-
Page 83: Waste Disposal
All synthetic materials must be brought to a recycling centre for synthetic materials. Rubber • Rubber parts (hoses, tyres, …) must be brought to a rubber recycling centre. Electronic scrap • All electronic parts must be brought to a disposal point for electronic scrap. ActiveMow R 360 Original Operating Instructions 150000864_01_en... -
Page 84: Index
Connecting the machine to the tractor ....39 Consumables ..........19, 33 Contact ..............2 Contact data of your dealer ........2 Control and Display Elements ......35 Conversion table ..........9 Cross references ..........6 ActiveMow R 360 Original Operating Instructions 150000864_01_en... - Page 85 Initial Operation ..........36 Input gearbox ............. 65 Installing universal shaft ........40 Intended use............12 Ensuring functionality of safety devices ..... 17 Environmental protection and disposal ....20 Jobs on the machine .......... 14 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 86 Mounting support jack ........46 Moving support jack into support position ..45 Moving support jack into transport position ..45 Mowing ............... 48 Noise may damage your health......21 Notes with information and recommendations ..9 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 87 Tensioning relief springs ........56 Rotary hub ............68 Term “machine” ............ 7 Tightening torques..........59 Unattended parking ..........19 Unsuitable consumables ........19 Validity ..............6 Venting the friction clutch ........62 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
- Page 88 Index Warning signs............8 Warnings of property damage/environmental damage ..............9 Waste disposal ........... 83 ActiveMow R 360 Original Operating Instructions 150000864_01_en...
-
Page 89: Declaration Of Conformity
Declaration of conformity Declaration of conformity EC Declaration of Conformity Maschinenfabrik Krone Beteiligungs-GmbH Heinrich-Krone-Straße 10, D-48480 Spelle hereby declare, as manufacturer of the product named below, under our sole responsibility, that the Machine: Rear Mounted Mower Type: ActiveMow R 360 to which this declaration refers is in compliance with the following relevant provisions: •... - Page 90 Maschinenfabrik Bernard Krone GmbH & Co. KG * Heinrich-Krone-Straße 10 D-48480 Spelle * Postfach 11 63 D-48478 Spelle ' +49 (0) 59 77 / 935-0 6 +49 (0) 59 77 / 935-339 ü www.landmaschinen.krone.de...
