14
Maintenance - Cutterbar
14.7

Checking/replacing linings on cutterbar

14.6.1

Checking the wear limit on cutting discs/mower drums

Abrasion on cutting discs/mower drums
Due to abrasion limits on the cutting discs/mower drums, the blades or parts may loosen
because of high rotating speed. Thus there is a risk of serious injuries or death.
The wear limit for abrasion limits (2) on the cutting discs/mower drums is reached when the
material thickness is less than 3 mm.
„ The cutting discs/mower drums must be replaced at the latest when the material
thickness is below the minimum material thickness of 3 mm.
„ The cutting discs/mower drums must only be replaced by KRONE original spare parts.
KM000-043
14.7
Checking/replacing linings on cutterbar
NOTICE
Impact stops are checked irregularly
The impact stops are subject to natural wear and must be inspected daily for wear and
replaced if required. If there is no inspection, the machine may be damaged.
„ Adjust the welding current and the welding material to the cutterbar material and to the
impact stop. If required, carry out a test weld.
76
WARNING
Original Operating Instructions 150000521_04_en
ActiveMow R 200
