13 Maintenance - Gearbox
13.2 Main gearbox
Changing oil
ü A suitable container is available for escaping oil.
„ Unscrew the locking screw of the inspection hole (1) and the locking screw of the filling hole
(3).
„ Unscrew the drain plug (2) and drain the oil.
„ Mount the drain plug (2), Anziehdrehmoment
„ Top up new oil via the filling hole (3) up to the inspection hole (1).
„ Mount the locking screw of the inspection hole (1) and the locking screw of the filling hole
(3), Anziehdrehmoment
66
refer to
refer to page 60.
Original Operating Instructions 150000521_04_en
page 60.
