Krone ActiveMow R 200 Operating Instructions Manual page 59

Rear mounted mower
Table of Contents

Advertisement

Metric thread screws with fine thread
DV000-001
X
Thread size
X
M12 x 1.5
M14 x 1.5
M16 x 1.5
M18 x 1.5
M20 x 1.5
M24 x 2
M27 x 2
M30 x 1.5
Metric thread screws with countersunk head and hexagon socket
INFORMATION
The table applies only to countersunk screws with hexagon socket and metric thread
tightened via hexagon socket.
DV000-000
X
Thread size
ActiveMow R 200
Original Operating Instructions 150000521_04_en
Strength class
5.6
8.8
Tightening torque (Nm)
88
145
222
368
465
787
1,148
800
Maintenance - General Information
Tightening torques
1
Strength class on screw head
10.9
130
213
327
525
662
1,121
1,635
2,100
1
Strength class on screw head
11
11.2
12.9
152
249
382
614
775
1,312
1,914
2,650
59
