Information on This Document
1.5
How to use this document
Icon
Warning signs
Warnings of dangers are separated from the remaining text as warning signs and are identified
with a danger sign and signal words.
The warning signs must be read and the measures must be observed in order to prevent
personal injury.
Explanation of danger sign
This is the danger sign that warns of a risk of injury.
Please observe all notes marked with the danger sign in order to avoid injuries or death.
Explanation of signal words
The signal word DANGER warns of a hazardous situation which will result in serious injuries
or death if the warning sign is ignored.
The signal word WARNING warns of a hazardous situation which will result in serious injuries
or death if the warning sign is ignored.
The signal word CAUTION warns of a hazardous situation which will result in minor to
moderate injuries if the warning sign is ignored.
Example of a warning sign:
8
Explanation
Reference sign for part
Dimensions (e. g. also B = width,
H = height, L = length)
Left-hand side of the machine
Direction of travel
Reference line for visible material
Centre line
Tighten screws according to tight-
ening torques table
open
Apply liquid lubricant (e.g. lubricat-
ing oil)
Icon
Explanation
Position of a part (e.g. move from
position I to position II)
Magnification of display detail
Right-hand side of the machine
side
Moving direction
Reference line for covered mater-
ial
Cable routes
Tighten screws with specified
tightening torque
closed
Apply lubricating grease
DANGER
WARNING
CAUTION
Original Operating Instructions 150000521_04_en
ActiveMow R 200
