System Operations
5-3

System Menu

Key Sequence: Shift, System (8)
System
Status
Self
Test
Application
Self
Test
GPS
Calibrate
Touch
Screen
Application
Options
System
Options
Figure 5-2.

System Menu

Note
Press Shift then 0 to open the Calibrate Touch Screen display. Press Enter to start
the calibration or Esc to cancel.
Spectrum Master User Guide
Status: Pressing this submenu key displays the current system status,
including the operating system and firmware versions, temperatures and
other details such as current battery information. Press Esc or Enter to
return to normal operation.
Self Test: This key initiates a series of diagnostic tests that check the
components of the instrument. A display will list the individual tests with a
pass or fail indication. Press Esc or Enter to return to normal operation.
Application Self Test: This key initiates a series of diagnostic tests related
to the performance of the instrument for specific applications. A display will
list the individual tests with a pass or fail indication. Press Esc or Enter to
return to normal operation.
GPS: Opens the "GPS Menu" on page
Calibrate Touch Screen: Start the touch screen calibration. Run the
calibration procedure when instrument is not responding to your screen taps
as expected.
Application Options: This submenu key presents a menu to select
application options. This will vary depending upon the measurement mode.
System Options: This key opens the
Calibrate Touch Screen Shortcut
PN: 10580-00328 Rev. E
5-3 System Menu
6-4.
"System Options Menu" on page 5-4.
