Feature Overview
Capturing or Retrieving Traces
MST can capture the current screen and associated data from the test instrument to the
Master Software Tools Graphic Display Editor window. Saved files on the test instrument can
also be retrieved, displayed, and edited with Master Software Tools.
• Download saved measurements from the instrument memory to a PC for storage and
analysis.
• Capture live traces to view and save on a PC.
• Upload saved measurements from a PC to the instrument.
• Compare multiple traces using drag, drop, and trace overlay features
(only Spectrum Analyzer measurements).
• Modify instrument's Cable list, Antenna list, and Signal Standard list.
• Trace Math functions.
• Convert DAT files from Anritsu Handheld Software Tools into Anritsu Master Software
Tools file formats
Editing Graphs
MST can be used to change the scale, limit lines, and markers in a measurement through the
Edit Graph button in the workspace toolbar, or through the Context Menus.
• Add, delete, and modify Limit Lines and Markers
• Add, delete, and modify Titles and Subtitles. Add Operator and Site location
data.
• Create trace reports and export .csv files for post-processing.
• Export measurements as a graphic file (.jpg format).
Figure 7-2.
Imported Graph with an Added Limit Line and an Added Delta Marker
7-2
PN: 10580-00328 Rev. E
Master Software Tools
Spectrum Master User Guide
