1-10 Spectrum Master Specifications
The internal memory is large enough to store approximately 2,000 traces or setups.
Measurements and setups can also be stored in a USB flash drive or transferred to a PC using
the included USB cable.
Not all USB drives are compatible with the instrument. Many drives come with a
second partition that contains proprietary firmware. This partition must be
Note
removed. Only one partition is allowed. Refer to the individual manufacturer for
instructions on how to remove it. Some drives can be made to work by reformatting
them using the FAT32 format.
A complete suite of computer software applications are available for download:
http://www.anritsu.com/en-US/Services-Support/Handheld-Tools-Tool-Box.aspx
Master Software Tools (MST), a PC based software program, can be used to create reports,
view and organize data, analyze historical data, add markers and limit lines, rename traces
and trace analysis. Please see
Master Software Tools Users Guide for additional information. A PDF file of the User Guide
is available on the MST CD-ROM provided with the Spectrum Master.
1-10 Spectrum Master Specifications
Refer to the Spectrum Master Technical Data Sheet for general specifications, detailed
measurement specifications for all available measurement modes, ordering information,
power sensors, and available accessories. The data sheet is included with the instrument and
also available on the Anritsu web site: http://www.anritsu.com.
1-11
Preventive Maintenance
Spectrum Master preventive maintenance consists of cleaning the unit and inspecting and
cleaning the RF connectors on the instrument and all accessories. Clean the Spectrum Master
with a soft, lint-free cloth dampened with water or water and a mild cleaning solution.
Caution
To avoid damaging the display or case, do not use solvents or abrasive cleaners.
Clean the RF connectors and center pins with a cotton swab dampened with denatured alcohol.
Visually inspect the connectors. The fingers of the N(f) connectors and the pins of the N(m)
connectors should be unbroken and uniform in appearance. If you are unsure whether the
connectors are undamaged, gauge the connectors to confirm that the dimensions are correct.
Visually inspect the test port cable(s). The test port cable should be uniform in appearance,
and not stretched, kinked, dented, or broken.
1-12 Calibration and Verification
Anritsu recommends an annual calibration and performance verification of the
Spectrum Master by a local Anritsu service center. The Spectrum Master is self-calibrating
and there are no field-adjustable components. Contact information for Anritsu Service
Centers is available at:
1-4
Chapter 7
for a brief overview of Master Software Tools and the
http://www.anritsu.com/Contact.asp
PN: 10580-00328 Rev. E
General Information
Spectrum Master User Guide
