4-4 File Menu

Save Menu

Key Sequence: File > Save
Save
Setup
Measurement
JPEG
Limit Lines
kml
Change
Quick
Name
Change
Save
Location
Figure 4-7. Save Menu
4-8
The top keys in the Save menu will display the available save options based
on the current measurement mode. Options include:
Setup: Setup files contain basic instrument information,
measurement mode setup details, measurement marker data, and
limit data. File extension: .stp
Measurement: Contains the measurement data and opens up with
Master Software Tools. File extension: Varies based on measurement.
Jpeg: Jpeg files contain a screen capture of the display. File
extension: .jpg
Limit Lines: Contains limit line data details. File extension: .lim
kml: Saves measurement and location data that can be viewed in
Google Earth. File extension: .kml
Change Quick Name: Press this submenu key to change the Quick Names
at the bottom of the touch screen keyboard
Name to edit and press Enter. Type the new Quick Name and press Enter
again. The new Quick Name will display on the button below the keyboard.
Change Save Location: Press this submenu key to open the
"Save Location Menu".
PN: 10580-00328 Rev. E
File Management
(Figure 4-1). Select the Quick
