User Guide
Economy Microwave Spectrum
Analyzer
Model MS2717B, MS2718B, MS2719B
MS2717B Frequency Range 9 kHz to 7.1 GHz
MS2718B Frequency Range 9 kHz to 13 GHz
MS2719B Frequency Range 9 kHz to 20 GHz
Anritsu Company
P/N: 10580-00181
490 Jarvis Drive
Revision: D
Morgan Hill, CA 95037-2809
Printed: October 2008
USA
Copyright 2006, 2008 Anritsu Company
www.valuetronics.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS2717B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MS2717B

Summary of Contents for Anritsu MS2717B

  • Page 1 User Guide Economy Microwave Spectrum Analyzer Model MS2717B, MS2718B, MS2719B MS2717B Frequency Range 9 kHz to 7.1 GHz MS2718B Frequency Range 9 kHz to 13 GHz MS2719B Frequency Range 9 kHz to 20 GHz Anritsu Company P/N: 10580-00181 490 Jarvis Drive...

  • Page 2: Limitation Of Warranty

    Anritsu is not liable for consequential damages. LIMITATION OF WARRANTY The foregoing warranty does not apply to Anritsu connectors that have failed due to normal wear. Also, the warranty does not apply to defects resulting from improper or inadequate maintenance by the Buyer, unauthorized modification or misuse, or operation outside of the environmental specifications of the product.
  • Page 3 This product and its manuals may require an Export License or approval by the government of the product country of origin for re-export from your country. Before you export this product or any of its manuals, please contact Anritsu Company to confirm whether or not these items are export-controlled.
  • Page 4 www.valuetronics.com...
  • Page 5 www.valuetronics.com...
  • Page 6 www.valuetronics.com...

  • Page 7: Safety Symbols

    Some or all of the following five symbols may or may not be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.

  • Page 8: For Safety

    For Safety Warning Always refer to the operation manual when working near locations at which the alert mark, shown on the left, is attached. If the operation, etc., is performed without heeding the advice in the operation manual, there is a risk of personal injury.

  • Page 9: Table Of Contents

    MS2717B Options ........
  • Page 10 Display Overview ............2-8 Rear Panel Connectors .
  • Page 11 MS2717B Preamplifier Operation ........
  • Page 12 5-14 AM/FM/SSB Demodulation ..........5-14 Demodulation Procedure .
  • Page 13 7-10 WCDMA/HSDPA Measurements ..........7-19 Carrier Frequency .
  • Page 14 7-13 Demodulator ............. . 7-32 Zoom Function.
  • Page 15 9-14 Fixed WiMAX Measurements ..........9-18 Adjacent Subcarrier Flatness (Peak).
  • Page 16 10-2 Mobile WiMAX Measurements ..........10-1 Channel Power (RSSI) .
  • Page 17 10-13 Secondary Function Menus ..........10-24 File.
  • Page 18 12-3 CDMA Measurement Setup ..........12-2 Measurement Frequency Setup .
  • Page 19 13-4 EVDO RF Measurements Setup ..........13-4 Channel Spectrum Setup .
  • Page 20 Appendix A — Signal Standards Table of Signal Standards ........... . A-1 Appendix B —...
  • Page 21 Operation Error Messages ........... . B-2 ADC Over Range - Increase Reference Level .
  • Page 22 PMON PLD Fail ............B-8 Overall Status FAILED.

  • Page 23: Chapter 1 - General Information

    A menu option provides for an audible alert when a limit value is exceeded. Anritsu Master Software Tools, a PC-based software program, provides for storing measurement data. Master Software Tools can also convert the Spectrum Analyzer display into several graphic formats.

  • Page 24: Ms271Xb Options And Accessories

    1-3 MS271xB Options and Accessories Chapter 1 —General Information MS271xB Options and Accessories MS2717B Options The following options are available for the MS2717B Spectrum Analyzer. Table 1-2. MS2717B Spectrum Analyzer Options Option Description MS2717B-007 Secure Data Operation Option MS2717B-009 RF and Demodulation Hardware...

  • Page 25: Ms2719B Options

    Chapter 1 —General Information 1-3 MS271xB Options and Accessories Table 1-3. MS2718B Spectrum Analyzer Options (Continued) Option Description MS2718B-045 WCDMA Demodulator (requires Option 009) MS2718B-046 Fixed WiMAX RF Measurements (requires Option 009) MS2718B-047 Fixed WiMAX Demodulation (requires Option 009) MS2718B-060 TD-SCDMA RF Measurements (requires Option 009) MS2718B-061 TD-SCDMA Demodulator (requires Option 009)

  • Page 26: Ms271Xb Supplied Accessories

    1-3 MS271xB Options and Accessories Chapter 1 —General Information MS271xB Supplied Accessories The following standard accessories are supplied with the MS271xB: Table 1-5. MS271xB Supplied Standard Accessories Part Number Description 10580-00181 MS271xB User Guide (this document) 2300-498 Master Software Tools Program CD ROM 3-2000-1498 USB A/5-pin Mini-B Cable, 3 m (10 feet) 2000-1371...
  • Page 27 Anritsu Maintenance Manual, Model MS271xB 2300-517 Phase Noise Measurement Software For a complete list of accessories available for the MS271xB, refer to the MS271xB Spectrum Analyzer Technical Datasheet, Anritsu part number 11410-00417, available online at www.us.anritsu.com. MS271xB User Guide 10580-00181 Rev D www.valuetronics.com...

  • Page 28: Ms271Xb Operation And Maintenance

    The MS271xB loads factory calibration data during start-up, eliminating the need for daily calibration checks. Although the MS271xB does not require daily calibration, Anritsu recommends annual calibration and performance verification by local Anritsu service centers. Anritsu service centers are listed in this chapter. ESD Cautions The MS271xB, like other high performance instruments, is susceptible to ESD damage.

  • Page 29: Replacing The Line Fuse

    Chapter 1 —General Information 1-4 MS271xB Operation and Maintenance Replacing the Line Fuse The MS271xB line fuse value is printed on the rear panel next to the power connector. Before changing the fuse, always remove the power cord from the power outlet. A risk exists of Caution receiving a fatal electric shock if the fuse is replaced with the power cord connected.

  • Page 30: Rack Mount Kit

    Rack Mount Kit The MS271xB Rack Mount Kit (part number MS271xB-001) allows the unit to be mounted to a standard 19-inch equipment rack. Follow the instructions below to install the kit. 1. Turn off the rear panel power switch and disconnect the MS271xB from the power source. 2.

  • Page 31: Chapter 2 - Quick Start Guide

    Chapter 2 — Quick Start Guide Introduction This chapter provides a brief overview of the Anritsu MS271xB Spectrum Analyzer. The intent of this chapter is to provide a starting point for making basic measurements. For more detailed information, refer to Chapter 3, “Key Functions”...

  • Page 32: Instrument Features

    2-2 Instrument Features Chapter 2 —Quick Start Guide 3. Set the instrument to operate by pressing the illuminated On/Off front panel button. Figure 2-2. MS271xB On/Off Button The MS271xB takes about forty-five seconds to complete power up and load the application software. At the completion of this process, the instrument is ready to use.

  • Page 33: Chapter 2 -Quick Start Guide

    MS271xB Overview Figure 2-3 shows model MS2717B with the Tracking Generator option, which includes a type N(f) RF Output connector. In all models without the Tracking Generator option, the type N(f) RF input connector is located on the left side of the instrument (in the same location as shown for the Tracking Generator RF Output type N(f) connector), and the right side of the lower panel is blank.

  • Page 34: Enter Key

    USB Interface - Type A The MS271xB ships with a 2 GB USB Flash device (Anritsu Part Number 2000-1520-R) for trace and setup storage via the USB Type A interface. Data can be stored directly to the USB device by pressing Shift - File (7), then the Directory Management soft key, and pressing the Current Location soft key until USB is underlined.

  • Page 35: Soft Keys

    Chapter 2 —Quick Start Guide 2-3 Soft Key Types Soft Keys These eight gray keys have no labels. They are arranged adjacent to the measurement display screen along the right-hand edge. They are positioned to accompany virtual soft key labels that are displayed to match instrument modes and measurement functions.

  • Page 36: Common Operations

    2-4 Common Operations Chapter 2 —Quick Start Guide Common Operations Parameter Setting Pop-up list boxes or edit boxes are used to provide selection lists and selection editors. Scroll through a list of items or parameters with the arrow keys or the rotary knob. Select numerical values by scrolling with the arrow keys or rotary knob or by entering the digits directly from the number keypad.
  • Page 37 Chapter 2 —Quick Start Guide 2-4 Common Operations Figure 2-6. Text Entry Menu – Upper Case Rotary Knob has scrolled to letter “h” Figure 2-7. Text Entry Menu – Selecting Characters MS271xB User Guide 10580-00181 Rev D www.valuetronics.com...

  • Page 38: Display Overview

    2-5 Display Overview Chapter 2 —Quick Start Guide Display Overview Figure 2-8 illustrates some of the main information areas of the MS271xB Spectrum Analyzer display. For detailed key descriptions, refer to Chapter 3, “Key Functions”. Figure 2-8. Display Overview 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 39: Rear Panel Connectors

    Chapter 2 —Quick Start Guide 2-6 Rear Panel Connectors Rear Panel Connectors Rear Panel Connectors The connectors and indicators located on the rear panel are labeled and shown in Figure 2-9. Figure 2-9. Rear Panel Connectors When supplying power to this equipment, connect the accessory 3-pin power cord to a 3-pin grounded power outlet.

  • Page 40: Lan Connection

    2-6 Rear Panel Connectors Chapter 2 —Quick Start Guide LAN Connection The RJ-45 connector is used to connect the MS271xB to a local area network. Integrated into this connector are two LEDs. The amber LED indicates the presence of LAN voltages and a live LAN connection. The green LED flashes to show that LAN traffic is present.

  • Page 41: More About Dhcp

    Chapter 2 —Quick Start Guide 2-6 Rear Panel Connectors More About DHCP DHCP stands for Dynamic Host Configuration Protocol. It is a protocol that allows a server to dynamically assign IP addresses to devices that are connected to the network. Most networks include a DHCP server to manage IP addresses.

  • Page 42: Example 2

    Windows 2000 IP Configuration Ethernet adapter Local Area Connection: Connection-specific DNS Suffix. : us.anritsu.com IP Address... . : 172.26.202.172 Subnet Mask ... : 255.255.252.0 Default Gateway .

  • Page 43: Ext Trigger

    GPIB Connector (Option 017) Option 17 adds a GPIB interface to the MS2717B, MS2718B, or MS2719B. The Anritsu implementation for GPIB uses a third-party adapter into an internal USB “B” port. The available SCPI commands are unchanged from what has been available over Ethernet.

  • Page 44: Making Spectrum Analyzer Measurements

    2-7 Making Spectrum Analyzer Measurements Chapter 2 —Quick Start Guide Making Spectrum Analyzer Measurements Required Equipment • MS271xB Economy Microwave Spectrum Analyzer • Optionally, an appropriate RF signal generator Making a Measurement To make a measurement, locate and display the signals of interest by selecting the desired frequency, span, and amplitude value, as explained below.

  • Page 45: Selecting A Signal Standard

    Chapter 2 —Quick Start Guide 2-7 Making Spectrum Analyzer Measurements Selecting a Signal Standard Selecting a signal standard sets the center frequency, channel spacing, integration bandwidth, and span for the first channel of the selected standard. For a table listing of the signal standards that are available in the instrument, refer to Appendix A, “Signal Standards”.
  • Page 46 2-7 Making Spectrum Analyzer Measurements Chapter 2 —Quick Start Guide External A TTL signal applied to the External Trigger BNC input connector causes a single sweep to occur. This mode is used in zero span, and triggering occurs on the rising edge of the signal. After the sweep is complete, the resultant trace is displayed until the next trigger signal arrives.

  • Page 47: Chapter 3 - Key Functions

    Chapter 3 — Key Functions Introduction This chapter describes the Spectrum Analyzer keys and how to use them. The major key sections are arranged in alphabetical order with soft key menus (that are under those key selections) listed in the order in which they appear on the instrument, from top to bottom.

  • Page 48: Amplitude Menu

    3-2 Amplitude Menu Chapter 3 —Key Functions Amplitude Menu The Amplitude hard key is located below the display. The Amplitude menu soft keys are shown in Figure 3-1: Amplitude Units Reference Level 10.0 dBm Detection Scale 10 dB/div Peak Auto Atten dBmV Atten Lvl dbuV...
  • Page 49 Chapter 3 —Key Functions 3-2 Amplitude Menu Auto Atten On/Off Input attenuation can be either tied to the reference level (On) or manually selected (Off). When input attenuation is tied to the reference level, attenuation is increased as higher reference levels are selected in order to make sure that the instrument input circuits are not saturated by large signals that are likely to be present when high reference levels are required.
  • Page 50 3-2 Amplitude Menu Chapter 3 —Key Functions Back Returns to the previous menu. 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 51: Bw (Bandwidth) Menu

    Chapter 3 —Key Functions 3-3 BW (Bandwidth) Menu BW (Bandwidth) Menu The BW hard key is located below the display. The BW menu soft keys are: 3 MHz Auto RBW 1 MHz Auto VBW RBW/VBW Span/RBW Figure 3-2. BW Menu Soft Keys The current resolution bandwidth value is displayed by pressing this soft key.

  • Page 52: File Menu

    Measurements may be saved to the internal memory, to an external Type-1 Compact Flash module, or to a USB Flash Drive. Anritsu recommends saving to external storage if a large number of measurements are to be saved. The Spectrum Analyzer is shipped with a Compact Flash module and a USB Flash Drive.
  • Page 53 Chapter 3 —Key Functions 3-4 File Menu Save Measurement Pressing this soft key initiates a dialog box to name and save measurement data for all three current trace locations: A, B, and C. The saved measurement can be named by using the keypad to select numbers, by using the rotary knob to highlight a number or character, and by pressing the knob to select each letter (or by selecting the soft key for each letter).
  • Page 54 3-4 File Menu Chapter 3 —Key Functions This feature should be used with care. With Save Then Stop set to Off (the default), a large number of measurements can be saved when the Crossing Limit or Sweep Complete soft keys are set to On, making it time-consuming to retrieve saved measurements or to delete unwanted measurements.
  • Page 55 Chapter 3 —Key Functions 3-4 File Menu Press the Shift key and the Trace (5) key to access operations concerning the recalled traces. The recalled traces can be viewed or blanked, cleared completely from memory, or moved into live trace locations to be used for trace math and marker operations.
  • Page 56 3-4 File Menu Chapter 3 —Key Functions Copy to Destination Int USB CF This choice lets you select where measurements and setups in the “current location” will be copied. The “current location” and the “copy to destination” may not be the same. If you change the destination to which the instrument will copy files, then the current location is automatically changed if the current location is the same as the selected copy to destination.

  • Page 57: Freq (Frequency) Menu

    Chapter 3 —Key Functions 3-5 Freq (Frequency) Menu Freq (Frequency) Menu The tuning frequency range for the MS271xB Spectrum Analyzer can be entered in several different ways depending upon what makes the most sense for the user or for the application. The center frequency and span can be specified, the start and stop frequencies can be entered, or a signal standard and channel number can be selected from the built-in list.
  • Page 58 Press the Freq key followed by the Span soft key to access the Span menu. The Span menu is used to set the frequency range over which the instrument will sweep. For the MS2717B, the span can be set from 10 Hz to 7.1 GHz.

  • Page 59: Limit Menu

    Chapter 3 —Key Functions 3-6 Limit Menu Limit Menu To access the functions under the Limit menu, press the Shift key, then the Limit (6) key. The Limit menu soft keys are shown in Figure 3-5. Limit Edit Limit Envelope Frequency Limit Create Envelope...
  • Page 60 3-6 Limit Menu Chapter 3 —Key Functions Two types of limit lines can be specified: lower limit lines and upper limit lines. Limit lines can be used for visual reference only, or for pass/fail criteria by using the limit alarm (refer to “Limit Alarm On Off”...
  • Page 61 Chapter 3 —Key Functions 3-6 Limit Menu Add Vertical In many measurement masks, step changes occur in the value of the limit line. Press this soft key to add two inflection points. The two inflection points share the same frequency and are centered midpoint between adjacent measured points.
  • Page 62 3-6 Limit Menu Chapter 3 —Key Functions Offset from ## dB Press this soft key to set a limit line offset value from Marker 1 amplitude. This feature moves the limit line amplitude and frequency as needed to place the center of the limit line the user-specified number of dB from the position of Marker 1.
  • Page 63 Chapter 3 —Key Functions 3-6 Limit Menu Figure 3-6. Example Limit Envelope, Square Limit Advanced Press this soft key to open the Limit Advanced soft key menu. The advanced limit line section offers several useful functions. In this section, you can create either an absolute limit line (which is based upon the frequencies that are entered for each inflection point) or a relative limit line (which is based upon the delta frequencies between the center frequency and the inflection points).
  • Page 64 3-6 Limit Menu Chapter 3 —Key Functions Limit Mirror On Off Press this soft key to turn the Limit Mirror feature On and Off. Many emission masks are symmetrical. The low frequency side is identical to the upper side. The Limit Mirror feature allows you to create half of the limit line and get the other half built automatically.

  • Page 65: Marker Menu

    Chapter 3 —Key Functions 3-7 Marker Menu Marker Menu Press the Marker function hard key to open the Marker menu. The Spectrum Analyzer is equipped with six markers. Any or all markers can be employed simultaneously. The Marker hard key is located below the display.
  • Page 66 3-7 Marker Menu Chapter 3 —Key Functions Delta On Off If the Delta marker is on, but not active for editing, then pressing this soft key makes the Delta marker active for editing. If the marker is currently active for editing, then pressing the On/Off key causes the Delta marker to be turned off and sets the corresponding reference marker active for editing.
  • Page 67 Chapter 3 —Key Functions 3-7 Marker Menu More Opens the Marker (2/2) submenu that contains additional Marker options. Marker (2/2) Marker Noise This marker option turns the markers into noise markers with units of dBm/Hz. When this option is selected, the detection method is automatically changed to RMS and the displayed value is compensated for the noise bandwidth of resolution bandwidth filter.
  • Page 68 3-7 Marker Menu Chapter 3 —Key Functions Figure 3-8. Markers When using the Up/Down arrows, the active marker moves in steps that are defined by the value that was entered by using the Freq Step soft key. Note When using the Left/Right arrow keys, the active marker moves by one division. 3-22 10580-00181 Rev D MS271xB User Guide...

  • Page 69: Measure Menu

    Chapter 3 —Key Functions 3-8 Measure Menu Measure Menu To access the functions under the Measure menu, press the Shift key, then the Measure (4) key. The Measure menu soft keys are shown in Figure 3-9: Figure 3-9. Measure Menu Soft Keys Measure Menu Field Strength This measurement allows the use of an antenna with known gain characteristics and measures the field...
  • Page 70 3-8 Measure Menu Chapter 3 —Key Functions Back Returns to the previous (Measure) menu. OCC BW Activates the occupied bandwidth menu. Select either % or dBc method of occupied bandwidth measurement. OCC BW Menu Method % Down/dBc Down Select either the % of Power (default) or dB Down measurement method as displayed in the message area.
  • Page 71 Chapter 3 —Key Functions 3-8 Measure Menu ACPR Accesses a menu of Adjacent Channel Power Ratio measurement options: On/Off (ACPR) Begins or ends the ACPR measurement. Main Ch BW Sets the bandwidth of the main channel for ACPR measurement. Use the keypad, the directional arrow keys, or the rotary knob to enter the a specific frequency.

  • Page 72: Mode

    Set the minimum sweep time for the measurement. Back Returns to the previous menu. Tracking Generator (MS2717B with Option 20 only) For information on the Tracking Generator (Option 20) for the MS2717B Economy Microwave Spectrum Analyzer, refer to Chapter 6, “Tracking Generator”.

  • Page 73: 3-10 Preset Menu

    Chapter 3 —Key Functions 3-10 Preset Menu 3-10 Preset Menu To access the functions under the Preset menu, press the Shift key, then the Preset (1) key. The Preset menu soft keys are shown in Figure 3-10: Preset Preset Save Setup Recall Setup...

  • Page 74: Span Menu

    3-11 Span Menu Chapter 3 —Key Functions 3-11 Span Menu The Span menu is used to set the frequency range over which the instrument will sweep. For the MS271xB, the span can be set from 10 Hz to the upper frequency limit. The Span can also be set to zero span for all models. Press the Span function key located below the display to access the Span menu.
  • Page 75 Chapter 3 —Key Functions 3-11 Span Menu Zero Span This soft key sets zero span. In this mode, the display shows amplitude changes at a single frequency. This function is frequently used to allow the easy monitoring of power variations over time. For example, if information about the amplitude of an 802.11a access point signal is needed, then the access point frequency would be set as the center frequency;...

  • Page 76: 3-12 Sweep Menu

    3-12 Sweep Menu Chapter 3 —Key Functions 3-12 Sweep Menu To access the functions under the Sweep menu, press the Shift key, then the Sweep (3) key. The Sweep menu soft keys are shown in Figure 3-12: Figure 3-12. Sweep Menu Soft Keys Sweep Single Continuous This soft key toggles between continuous sweep and single sweep.
  • Page 77 Chapter 3 —Key Functions 3-12 Sweep Menu Detection Several detection methods tailor the performance of the instrument to meet specific measurement requirements. In general, more points are measured across the screen than are displayed as points. The various detection methods are different ways of dealing with selecting which measurement point will be shown at each display point.
  • Page 78 3-12 Sweep Menu Chapter 3 —Key Functions Video This mode is used in zero span to set the power level at which a sweep is initiated. The power level can be set from –130 dBm to +20 dBm. The trigger is based on the measured signal level. If no signal reaches or exceeds the trigger level, then no trace appears on the screen.

  • Page 79: 3-13 System Menu

    Chapter 3 —Key Functions 3-13 System Menu 3-13 System Menu To access the functions under the System menu, press the Shift key, then the System (8) key. The System menu soft keys are: Figure 3-13. System Menu Soft Keys Status Pressing this soft key displays the current system status, including the operating system and firmware versions, temperatures, and other system details.
  • Page 80 Impedance 50 Ohm/75 Ohm/Other Select either 50 ohm, 75 ohm, or other impedance value. Selecting 75 ohm selects the 7.5 dB loss of the Anritsu 12N50-75B adapter. For other adapters, select Other and enter the appropriate loss. Ext Ref Freq Select the frequency of the external reference from the list presented.
  • Page 81 MST. Update OS Via USB This soft key should only be used in conjunction with Anritsu MST to update the instrument operating system using a USB connection. Use this soft key only as instructed by MST.

  • Page 82: 3-14 Trace Menu

    3-14 Trace Menu To access the functions under the Trace menu, press the Shift key and then the Trace (5) key. The Anritsu MS271xB Spectrum Analyzer is capable of displaying up to six traces. Trace A shows live data, Traces B and C can show stored or trace math data, and the Recalled A-C traces allow the user to see three recalled traces without overwriting the three current traces.
  • Page 83 Chapter 3 —Key Functions 3-14 Trace Menu Trace A Ops Menu Normal -> A The trace displays current data for the current sweep Max Hold -> A The trace shows the cumulative maximum value of each display point over many sweeps Min Hold ->...
  • Page 84 3-14 Trace Menu Chapter 3 —Key Functions A - B -> C Subtracts the value of Trace B from Trace A and places the results in Trace C. This function is very useful for observing the changes in values of live Trace A compared to a trace stored in Trace B.
  • Page 85 Chapter 3 —Key Functions 3-14 Trace Menu Recalled B -> B Copies the contents of Trace Recalled B into Trace B. Doing so overwrites the previous contents of Trace B. Recalled C -> B Copies the contents of Trace Recalled C into Trace B. Doing so overwrites the previous contents of Trace B.
  • Page 86 3-14 Trace Menu Chapter 3 —Key Functions 3-40 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 87: Chapter 4 - Measurement Fundamentals 4-1 Introduction

    Chapter 4 — Measurement Fundamentals Introduction Measurement fundamentals include the use of additional Spectrum Analyzer functions beyond frequency, span, amplitude and marker functions. In particular, this section focuses on resolution bandwidth, video bandwidth, sweep, and attenuator functions. Resolution Bandwidth Resolution Bandwidth is determined by the intermediate frequency (IF) filter bandwidth. The Spectrum Analyzer traces the shape of the IF filter as it tunes past a signal.

  • Page 88: Sweep Limitations

    MS2717B Preamplifier Operation The preamplifier in the MS2717B has a gain of approximately 25 dB and generally will lower the noise floor by that amount. When the preamplifier is on, input attenuation can be either 0 dB or 10 dB.

  • Page 89: Preamplifier Measurement Example

    Chapter 4 —Measurement Fundamentals 4-6 Preamplifier Operation Preamplifier Measurement Example In the section below, Figure 4-1 shows a signal with the preamplifier off. Figure 4-2 shows the same signal with the preamplifier on. Notice that when the preamplifier is turned on, the noise floor drops significantly, allowing spectral regrowth components that were lost in the noise without the preamplifier to become easily visible.
  • Page 90 Users of Option 07 must update all versions of Anritsu Master Software Tools to version V2.10 or later in order to take full advantage of the security of Option 07. In earlier versions, use of the Master Note Software Tools feature called “Capture Current Measurement”...

  • Page 91: Bandwidth Settings

    Chapter 4 —Measurement Fundamentals 4-8 Option 89, IF Output (MS2718B and MS2719B only) Option 89, IF Output (MS2718B and MS2719B only) Option 89 provides a 37.8 MHz IF signal out of a BNC female connector. • The IF output signal is present only when the instrument span is set to zero. •...
  • Page 92 4-8 Option 89, IF Output (MS2718B and MS2719B only) Chapter 4 —Measurement Fundamentals 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 93: Chapter 5 - Transmitter Measurements

    • Anritsu MS271xB Spectrum Analyzer • Test Port Extension Cable, Anritsu part number 15NNF50-1.5C • 30 dB, 50 Watt, bi-directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 (required if the power level being measured is > +30 dBm) OBW Measurement Procedure 1.

  • Page 94: Cdma Channel Power Measurement

    Required Equipment • MS271xB Spectrum Analyzer • 30 dB, 50 Watt, Bi-Directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 (required if the power level being measured is > +30 dBm) • Test Port extension cable, Anritsu 15NNF50-1.5C 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 95: Gsm Channel Power Measurement

    This is one of the reasons that spurious measurements are used extensively in GSM applications. Required Equipment • MS271xB Spectrum Analyzer • Test Port extension cable, Anritsu 15NNF50-1.5C MS271xB User Guide 10580-00181 Rev D www.valuetronics.com...
  • Page 96 5-5 GSM Channel Power Measurement Chapter 5 —Transmitter Measurements GSM Channel Power Measurement Procedure 1. Using the test port extension cable, connect the signal source to the RF In test port of the MS271xB. 2. Press the Amplitude key and press the Reference Level soft key to set the reference level to –20 dBm. Adjust the values given in this procedure to match your measurement conditions.

  • Page 97: Amps Channel Power Measurement

    • MS271xB Spectrum Analyzer • Test Port extension cable, Anritsu 15NNF50-1.5C • 30 dB, 50 Watt, Bi-Directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 (required if the power level being measured is > +30 dBm) AMPS Channel Power Measurement Procedure 1.
  • Page 98 Required Equipment • MS271xB Spectrum Analyzer • 30 dB, 50 Watt, Bi-Directional, DC - 18 GHz, N(m) - N(f), Attenuator, Anritsu 42N50A-30 (if needed for the power level being measured) • Test Port extension cable, Anritsu 15NNF50-1.5C Adjacent Channel Power Ratio Measurement Procedure 1.

  • Page 99: Gsm Adjacent Channel Power Measurement

    GSM Adjacent Channel Power Measurement Required Equipment • Anritsu MS271xB Spectrum Analyzer • 30 dB, 50 Watt, Bi-Directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 (if required for the power level being measured) • Test Port extension cable, Anritsu 15NNF50-1.5C Procedure 1.

  • Page 100: Amps (Tdma) Adjacent Channel Power Measurement

    AMPS (TDMA) Adjacent Channel Power Measurement Required Equipment • MS271xB Spectrum Analyzer • 30 dB, 50 Watt, Bi-Directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 (if needed for the power level being measured) • Test Port extension cable, Anritsu 15NNF50-1.5C AMPS (TDMA) Adjacent Channel Power Measurement Procedure 1.

  • Page 101: Out-Of-Band Spurious Emission Measurement

    5-10 Out-of-Band Spurious Emission Measurement Required Equipment • MS271xB Spectrum Analyzer • Test Port extension cable, Anritsu 15NNF50-1.5C Out-of-Band Spurious Emission Measurement Procedure 1. Using the test port extension cable, connect the signal source to the RF In test port of the MS271xB.

  • Page 102: In-Band/Out-Of-Channel Measurements

    5-12 In-Band Spurious Measurement Required Equipment • MS271xB Spectrum Analyzer • 30 dB, 50 Watt, Bi-Directional, DC to 18 GHz, N(m)-N(f), Attenuator, Anritsu 42N50A-30 • Test Port extension cable, Anritsu 15NNF50-1.5C Procedure 1. Using the test port extension cable and 30 dB, 50 Watt, Bi-directional attenuator, connect the MS271xB to appropriate transmit test port.
  • Page 103 Chapter 5 —Transmitter Measurements 5-12 In-Band Spurious Measurement A simulated in-band spur at 1.625 MHz from the carrier frequency is shown in Figure 5-3. The carrier is measured by M1. The delta marker on M1 shows the signal at f + 1.625 MHz to be 60.17 dB down from the carrier.

  • Page 104: Field Strength

    Select an antenna from the standard list available in the MS271xB, or use the Antenna Editor feature Note of Anritsu Master Software Tools to define a custom antenna and upload the antenna information to the MS271xB antenna list. 3. Connect the antenna to the MS271xB.
  • Page 105 Chapter 5 —Transmitter Measurements 5-13 Field Strength Power Density to Field Strength An alternate measure of field strength to electric field is power density: ------------- - π where: E = field strength in V/m P = Power density in W/m Power Density at a Point Power density at a point, in the far field, where electric and magnetic fields are related by the impedance of free space:...

  • Page 106: Am/Fm/Ssb Demodulation

    5-14 AM/FM/SSB Demodulation Chapter 5 —Transmitter Measurements 5-14 AM/FM/SSB Demodulation The MS271xB built-in demodulator for AM, narrowband FM, wideband FM and single sideband (selectable USB and LSB) allows a technician to hear an interfering signal to ease identification. The demodulated signal can be heard using either the built-in speaker, or through a monaural cellular headset connected to the 2.5-mm jack on the test panel.
  • Page 107 Chapter 5 —Transmitter Measurements 5-15 Carrier to Interference Ratio Measurement 7. Press the On/Off soft key and follow the on-screen prompts to complete the measurement. Access to the transmitter is required to complete this procedure as the transmitted carrier must be Note turned off for the second portion of the measurement.
  • Page 108 5-15 Carrier to Interference Ratio Measurement Chapter 5 —Transmitter Measurements Figure 5-6. C/I Measurement, Results 5-16 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 109: Menu Structure

    Chapter 6 — Tracking Generator Introduction This chapter provides a description of the optional Tracking Generator (Option 20) for the MS2717B. The Tracking Generator operates over a frequency range of 100 kHz to 7.l GHz, and provides a signal with an output frequency that is the same as the tuning frequency of the Spectrum Analyzer.

  • Page 110: Chapter 6 -Tracking Generator

    6-3 Normalization Chapter 6 —Tracking Generator Tracking Generator Menu Track Gen Off On Turns the output of the tracking generator on and off. The output power turns on at the level set with the Output Power soft key. Output Power Sets the output power from 0 dBm to –40 dBm, in 0.1 dB steps, at the output connector.

  • Page 111: Measurement Example

    Chapter 6 —Tracking Generator 6-4 Tracking Generator Operation Tracking Generator Operation 1. Press the Track Gen Off/On soft key to turn the output of the tracking generator on and off. The output power turns on at the level set with the Output Power soft key. 2.
  • Page 112 6-5 Measurement Example Chapter 6 —Tracking Generator 10. If the dynamic range is not sufficient for the necessary measurements, then reduce the input attenuation and RBW to maximize the dynamic range. It is likely that the scale will have to be changed from 10 dB/division to a higher value to see the stop band of a good filter.
  • Page 113 Chapter 6 —Tracking Generator 6-5 Measurement Example 15. Press the Normalize soft key to set Normalization On. Figure 6-4. Flat Sweep After Normalization 16. After the normalization sweep is finished, reconnect the DUT between the RF Out and RF In connectors. The following figure shows the measurement after normalization.
  • Page 114 6-5 Measurement Example Chapter 6 —Tracking Generator 17. If necessary, press the S21 Scale soft key and change the scale to view the entire measurement. Figure 6-6. S21 Scale Changed to 15 dB/division 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...
  • Page 115 Spectrum Analyzer, connect the power amplifier of the node B equipment to the RF In connector using a coupler or attenuator. The maximum input damage level of the MS2717B RF In port is +43 dBm. The maximum input damage level of the MS2718B or the MS2719B RF In port is +30 dBm.
  • Page 116 7-2 WCDMA/HSDPA Signal Analyzer Mode - Amplitude Menu Chapter 7 —WCDMA/HSDPA Measurements WCDMA/HSDPA Signal Analyzer Mode - Amplitude Menu Amplitude Scale __ __ Power Offset 0.0 dB Auto Range Adjust Range Figure 7-1. WCDMA/HSDPA Amplitude Menu Scale The scale can be set in 1 dB steps from 1 dB per division to 15 dB per division. The value can be changed using the keypad, the rotary knob or the Up/Down arrow keys.
  • Page 117 Chapter 7 —WCDMA/HSDPA Measurements 7-3 File Menu File Menu Figure 7-2. WCDMA/HSDPA File Menu To access the functions under the File menu, press the Shift key, then the File (7) key. MS271xB User Guide 10580-00181 Rev D www.valuetronics.com...
  • Page 118 Measurements may be saved to the internal memory, an external Type-1 Compact Flash module, or a USB Flash Drive. Anritsu recommends saving to external storage if a large number of measurements are to be saved. The Spectrum Analyzer is shipped with a Compact Flash module and a USB Flash Drive.
  • Page 119 Chapter 7 —WCDMA/HSDPA Measurements 7-3 File Menu Recall Opens the Recall options menu. Recall Menu Recall Setup This soft key opens a selection box that allows selection and recall of a previously stored instrument setup in the current storage location. Use the rotary knob or the Up/Down arrow keys to highlight the saved setup, and press Enter, the rotary knob, or the Recall soft key to select.
  • Page 120 7-3 File Menu Chapter 7 —WCDMA/HSDPA Measurements Delete ALL Contents Deletes all measurements, jpg files and setup files of ALL measurement types. Back The Back key returns to the previous menu. Directory Management The Directory Management soft key opens the Directory Management menu. Note that this menu is available under the File, Recall, and Save menus.

  • Page 121: Freq (Frequency) Menu

    Chapter 7 —WCDMA/HSDPA Measurements 7-4 Freq (Frequency) Menu Freq (Frequency) Menu Freq Center Freq 1.000 GHz Signal Standard Channel Set CF Closest Channel Decrement Channel Increment Channel Figure 7-3. WCDMA/HSDPA Freq Menu Center Freq Press the Freq key followed by the Center Freq soft key and enter the desired frequency using the keypad, the arrow keys, or the rotary knob.

  • Page 122: Measurements Menu

    7-5 Measurements Menu Chapter 7 —WCDMA/HSDPA Measurements Measurements Menu Figure 7-4. WCDMA/HSDPA Measurements Menu 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...
  • Page 123 Chapter 7 —WCDMA/HSDPA Measurements 7-5 Measurements Menu Measurements Menu RF Measurement Opens the RF measurement menu. RF Measurement Menu Band Spectrum Displays the spectrum of the selected band. Band Spectrum Menu Ref Level Sets the required reference level. Scale Change the scale. Band Channel Use the cursor to select the required channel and the unit analyzes the selected channel signal.
  • Page 124 7-5 Measurements Menu Chapter 7 —WCDMA/HSDPA Measurements RF Measurement Menu Spectra Emission Mask Displays the received signal and the mask based on received signal strength. Spectral Emission Summary Displays the spectral emission mask in table format and whether the received signal passed in each frequency range.
  • Page 125 Chapter 7 —WCDMA/HSDPA Measurements 7-5 Measurements Menu Demod Menu CDP Table When Code Domain Power Table (CDP Table) is selected, the screen displays a list of all the active OVSF codes in a tabular format. The display show the Spreading Factor, Code Number, Status, EVM, Modulation type, Relative Power in dB, and Absolute Power in dBm for each active OVSF code.
  • Page 126 7-5 Measurements Menu Chapter 7 —WCDMA/HSDPA Measurements Total Time Use the keypad, the Up/Down arrow keys, or the rotary knob to enter the total time to display the changes in code power levels. The maximum total time for Codogram is 72 hours. Single Sweep Time Single sweep time is related to total time.

  • Page 127: Preset Menu

    Chapter 7 —WCDMA/HSDPA Measurements 7-6 Mode Mode To access the functions under the Mode menu, press the Shift key, then the Mode (9) key. Use the directional arrow keys or the rotary knob to highlight the selection and press the Enter key to select. Preset Menu Preset Preset...

  • Page 128: Setup Menu

    7-8 Setup Menu Chapter 7 —WCDMA/HSDPA Measurements Setup Menu Setup (1/2) Setup (2/2) Scrambling Code Threshold Auto Manual Auto Manual Manual Threshold Manual Scrambling Code -30.0 dB Max Spreading Factor Select Reference Frequency S-CCPCH Spread S-CCPCH Code PICH Code More Back -->...
  • Page 129 Chapter 7 —WCDMA/HSDPA Measurements 7-8 Setup Menu S-CCPCH Code Press the S-CCPCH Code (input) soft key to enable and enter the S-CCPCH code. The default value is 3. PICH Code Press the PICH Code (input) soft key to activate Paging Indicator Channel and enter the desired code. The default value is 16.

  • Page 130: System Menu

    7-9 System Menu Chapter 7 —WCDMA/HSDPA Measurements System Menu Options System System Options Select Date Reference Status & Frequency Time Reset Ethernet Self Factory Test Config Defaults Application Language Self Master Test Reset Brightness Update OS Via Ethernet Name Update Back OS Via Application...
  • Page 131 Chapter 7 —WCDMA/HSDPA Measurements 7-9 System Menu Application Options This soft key presents a menu to select application options. Options Menu Select Reference Frequency This soft key opens a dialog box for selecting the Reference Frequency. Use the rotary knob or the Up/Down arrow keys to highlight the Reference Frequency and press Enter to select, or press the Esc key to cancel.
  • Page 132 Press Esc to return to normal operation without resetting. Update OS Via Ethernet This soft key should only be used in conjunction with Anritsu Master Software Tools (MST) to update the instrument operating system using an Ethernet connection. Use this soft key only as instructed by MST.
  • Page 133 Chapter 7 —WCDMA/HSDPA Measurements 7-10 WCDMA/HSDPA Measurements 7-10 WCDMA/HSDPA Measurements Note Use an applicable band pass filter to eliminate out of band signals that can cause mixer saturation. Carrier Frequency Carrier Frequency is the selected transmitter operating center frequency entered by the user or calculated from the signal standard and channel number entered by the user.
  • Page 134 7-10 WCDMA/HSDPA Measurements Chapter 7 —WCDMA/HSDPA Measurements Ec is a measurement of energy. Ec is determined by multiplying CPICH by the chip time. Ec/Io The pilot power compared to the total channel power. Ec/Io is displayed in text only and OTA measurement displays.
  • Page 135 Chapter 7 —WCDMA/HSDPA Measurements 7-10 WCDMA/HSDPA Measurements P-SCH Abs Power P-SCH Abs power is the absolute Primary Sync Channel power displayed in dBm. S-SCH Abs Power S-SCH Abs power is the absolute Secondary Sync Channel Power displayed in dBm. Scrambling Code In the WCDMA specification the scrambling code can be from 0 to 511.

  • Page 136: Measurement Setup

    7-11 Measurement Setup Chapter 7 —WCDMA/HSDPA Measurements 7-11 Measurement Setup WCDMA/HSDPA Mode UMTS/WCDMA mode supports HSDPA measurements when Option 65, WCDMA/HSDPA Demod, Option 44, WCDMA/HSDPA RF Meas are installed and the name of the mode is labeled as Note WCDMA/HSDPA Signal Analyzer. When Option 45, WCDMA Demod is installed, the mode is labeled as WCDMA Signal Analyzer.

  • Page 137: Scrambling Code Setup

    Chapter 7 —WCDMA/HSDPA Measurements 7-11 Measurement Setup Scrambling Code Setup The Spectrum Analyzer can set up a scrambling code automatically or manually. In Auto mode the unit automatically locks on to the strongest scrambling code in the signal. In Manual mode the desired code is manually entered and the unit looks only for that specific scrambling code.

  • Page 138: S-Ccpch Spreading Factor, S-Ccpch Code And Pich Code Setup

    7-12 WCDMA/HSDPA RF Measurements Chapter 7 —WCDMA/HSDPA Measurements S-CCPCH Spreading Factor, S-CCPCH Code and PICH Code setup In the 3GPP specification, two optional control channels are provided for S-CCPCH and PICH. These codes can have different spreading codes and spreading factors. In the Spectrum Analyzer the S-CCPCH spreading factor and S-CCPCH and PICH codes can be manually entered.
  • Page 139 Chapter 7 —WCDMA/HSDPA Measurements 7-12 WCDMA/HSDPA RF Measurements Band Spectrum Displays the selected band spectrum. The cursor can be moved to select the desired channel using the directional arrow keys or the rotary knob. The Channel Number can also be directly entered using the numerical keypad.

  • Page 140: Channel Spectrum

    7-12 WCDMA/HSDPA RF Measurements Chapter 7 —WCDMA/HSDPA Measurements Channel Spectrum The channel spectrum screen displays the selected channel signal and the following measurements: channel power in dBm and Watts, occupied bandwidth, and peak to average power. When Channel Spectrum is selected, the unit automatically displays the measurements for the selected signal.
  • Page 141 Chapter 7 —WCDMA/HSDPA Measurements 7-12 WCDMA/HSDPA RF Measurements ACLR Measurement Screen ACLR (Adjacent Channel Leakage Ratio) is defined as the ratio of the amount of leakage power in an adjacent channel to the total transmitted power in the main channel and is displayed in table format under the bar graph.
  • Page 142 7-12 WCDMA/HSDPA RF Measurements Chapter 7 —WCDMA/HSDPA Measurements Figure 7-10. ACLR Measurement Example 9. Press the ACLR soft key again and select one main channel and two adjacent channels. Multi-Channel ACLR Procedure 1. Press the Shift key, then the Mode (9) key. 2.

  • Page 143: Spectral Emission Mask

    Chapter 7 —WCDMA/HSDPA Measurements 7-12 WCDMA/HSDPA RF Measurements Figure 7-11. ACLR Multi-channel Measurement Example Spectral Emission Mask The Spectral Emission Mask displays the selected signal and the mask as defined in the 3GPP specification. The mask varies depending upon the input signal. The Spectrum Analyzer also indicates if the signal is within the specified limits by displaying PASSED or FAILED.
  • Page 144 7-12 WCDMA/HSDPA RF Measurements Chapter 7 —WCDMA/HSDPA Measurements 9. Press the Spectral Emission Summary soft key to display the Spectral Emission Summary table. The red dot on the soft key indicates that it is selected. Figure 7-12. Spectral Emission Mask Measurement Example For a Spectral Emission Summary: Figure 7-13.
  • Page 145 Chapter 7 —WCDMA/HSDPA Measurements 7-12 WCDMA/HSDPA RF Measurements RF Summary The RF Summary displays the critical transmitter performance measurements in the table format, without demodulating the WCDMA/HSDPA signal. The parameters displayed in the RF Summary table are Channel Power (in dBm and Watts), Carrier Frequency, Frequency Error, Spectral Emission Pass/Fail criteria, Occupied Bandwidth, Peak to Average Power, and ACLR at –10 MHz, –5 MHz, 5 MHz, and 10 MHz channels.

  • Page 146: Zoom Function

    7-13 Demodulator Chapter 7 —WCDMA/HSDPA Measurements 7-13 Demodulator In the demodulator mode the MS271xB Spectrum Analyzer is connected to the node B equipment and the unit will demodulate the WCDMA signal. The WCDMA/HSDPA demodulator has Code Domain Power (CDP), HSPDA, Codogram and Modulation Summary screens. The WCDMA/HSDPA Demodulator option demodulates both WCDMA and HSDPA signals.
  • Page 147 Chapter 7 —WCDMA/HSDPA Measurements 7-13 Demodulator 13. Press the Threshold soft key to manually set the Threshold level which determines which codes are active. The default value is –30 dB. 14. Press the Measurements function hard key. 15. Press the Demodulator (switching) soft key to activate the demodulator menu. 16.
  • Page 148 7-13 Demodulator Chapter 7 —WCDMA/HSDPA Measurements Code Domain Power Table (CDP Table) The Code Domain Power Table (CDP Table) display includes all active spreading factor (OVSF codes). The table displays every OVSF, Code (Spreading Factor and code number), Status, Symbol EVM, Modulation Type, Relative Power (dB) and Absolute power (dBm) in a table format.
  • Page 149 Chapter 7 —WCDMA/HSDPA Measurements 7-13 Demodulator Activating Markers Procedure 1. Press the Marker function hard key to display the Marker menu. 2. Press the Marker soft key to select the appropriate marker (1-6). The underlined marker number is the currently selected marker. 3.
  • Page 150 7-13 Demodulator Chapter 7 —WCDMA/HSDPA Measurements HSDPA HSDPA displays the spreading factor (OVSF codes) 256 or 512 codes and high speed downlink physical shared channel codes HS-PDSCH. The right or left active codes can be selected using the cursor. The selected code power versus time and constellation are displayed.
  • Page 151 Chapter 7 —WCDMA/HSDPA Measurements 7-13 Demodulator 7. Press the Scrambling Code soft key to select Auto so that the Spectrum Analyzer will automatically detect the scrambling code. 8. Press the Select Reference Frequency soft key to display a list of the available reference frequencies and select the desired reference frequency to get accurate frequency measurements.
  • Page 152 7-13 Demodulator Chapter 7 —WCDMA/HSDPA Measurements WCDMA Summary WCDMA summary displays the critical WCDMA measurements from RF and demodulation measurements. Figure 7-19. WCDMA Summary Measurement Screen Example WCDMA Summary Procedure 1. Press the Shift key, then the Mode (9) key. 2.

  • Page 153: Pass/Fail Mode

    Chapter 7 —WCDMA/HSDPA Measurements 7-14 Pass/Fail Mode 13. Press the Threshold soft key to manually set the Threshold level which determines which codes are active. The default value is –30 dB. 14. Press the Measurements function hard key. 15. Press the WCDMA Summary soft key. 7-14 Pass/Fail Mode The Spectrum Analyzer stores the five test models specified in the 3GPP specification (TS 125.141) for testing base station performance and recalls these models for quick easy measurements.
  • Page 154 7-14 Pass/Fail Mode Chapter 7 —WCDMA/HSDPA Measurements 7-40 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 155: Chapter 8 - High Accuracy Power Meter

    • High Accuracy Power Sensor, PSN50 • USB cable, Type A/Mini-B • 30 dB, 50 W, bi-directional, DC-8.5 GHz, N(m)-N(f), Attenuator For more information on cable accessories, options, and their Anritsu part numbers, refer to Note Section 1-3, “MS271xB Options and Accessories” on page 1-2 Chapter 1, “General...
  • Page 156 8-3 HAPM General Operating Procedure Chapter 8 —High Accuracy Power Meter HAPM General Operating Procedure Turn On the Spectrum Analyzer and the Sensor 1. Connect the USB A/mini-B cable between the High Accuracy Power Sensor and the Spectrum Analyzer. Figure 8-1. High Accuracy Power Meter Setup Example 2.
  • Page 157 Chapter 8 —High Accuracy Power Meter 8-3 HAPM General Operating Procedure 2. For a description of the Zero/Cal and Cal Factor menu soft keys, refer to Section 8-5, “Zero/Cal and Cal Factor Menus” on page 8-7. Figure 8-2. Power Meter Display and Zero/Cal Menu Figure 8-3.

  • Page 158: Displaying Relative Power

    8-3 HAPM General Operating Procedure Chapter 8 —High Accuracy Power Meter Change the Analog Scale Display 1. Press the Amplitude key. The Amplitude menu appears. • For a description of the Amplitude menu soft keys, refer to Section 8-6, “Amplitude and Units Menus”...
  • Page 159 Chapter 8 —High Accuracy Power Meter 8-3 HAPM General Operating Procedure • For a description of the Average menu soft keys, refer to Section 8-7, “Averages Menu” on page 8-9. Figure 8-5. Averages Menu 2. Press the Running Averages key. Use the keypad to enter the desired number of averages. 3.

  • Page 160: Saving The Measurement

    8-4 Menus Chapter 8 —High Accuracy Power Meter 2. Press the Lower Limit soft key. Enter the lower limit value in dBm or in Watts. 3. Press the Upper Limit soft key. Enter the upper limit value in dBm or in Watts. 4.
  • Page 161 Chapter 8 —High Accuracy Power Meter 8-5 Zero/Cal and Cal Factor Menus Zero/Cal and Cal Factor Menus Zero/Cal and Cal Factor Menus are displayed in Figure 8-8. Figure 8-8. Zero/Cal and Cal Factor Soft Key Menus Access the Zero/Cal menu pressing the Zero/Cal hard key at the bottom of the screen. Zero/Cal Menu Zero On Off...
  • Page 162 8-6 Amplitude and Units Menus Chapter 8 —High Accuracy Power Meter Amplitude and Units Menus The Amplitude and Units Menus are displayed in Figure 8-9. Amplitude Units 28.0 dBm Watt -24.0 dBm Enter Offset 0.0 dB Relative Units --> Auto Scale Back Figure 8-9.

  • Page 163: Averages Menu

    Chapter 8 —High Accuracy Power Meter 8-7 Averages Menu Opens the Units submenu Units Menu Selects dBm as the measurement units. If selected, then the circle in upper right corner of the soft key is red. Watt Selects Watts as the measurement units. If selected, then the circle in upper right corner of the soft key is red.

  • Page 164: Limits Menu

    8-8 Limits Menu Chapter 8 —High Accuracy Power Meter Limits Menu The Limits menu is displayed in Figure 8-11. Figure 8-11. Limits Soft Key Menu Access the Limits menu by pressing the Limits hard key at the bottom of the screen. Limit On Off Turns the limits on or off.
  • Page 165 Chapter 9 — Fixed WiMAX Signal Analyzer Introduction Two Fixed WiMAX options are available for the MS271xB: • Fixed WiMAX RF Measurements (Option 46) • Fixed WiMAX Demodulator (Option 47) Connect the instrument to any Fixed WiMAX BTS for accurate RF and demodulator measurements. The MS271xB works for FDD and TDD networks.

  • Page 166: Amplitude Menu

    9-2 Amplitude Menu Chapter 9 —Fixed WiMAX Signal Analyzer Amplitude Menu Amplitude Scale 10 dB/div Power Offset 0.0 dB Auto Range Adjust Range Y Axis Max * (Only in S pectral Flatness and EVM vs. S ymbol/S ub-carrier views) Figure 9-1. Fixed WiMAX Signal Analyzer Mode Amplitude Menu Scale Scale changes the Y-axis scale and can be set from 1 dB/div to 15 dB/div.
  • Page 167 Chapter 9 —Fixed WiMAX Signal Analyzer 9-3 File Menu File Menu To access the functions under the File menu, press the Shift key, then the File (9) key. Figure 9-2. Fixed WiMAX Signal Analyzer Mode File Menu The File menu provides soft key options for Save, Recall, Delete, and Directory Management. MS271xB User Guide 10580-00181 Rev D www.valuetronics.com...
  • Page 168 Measurements may be saved to the internal memory, an external Type-1 Compact Flash module, or a USB Flash Drive. Anritsu recommends saving to external storage if a large number of measurements are to be saved. The Spectrum Analyzer is shipped with a Compact Flash module and a USB Flash Drive.
  • Page 169 Chapter 9 —Fixed WiMAX Signal Analyzer 9-3 File Menu File Menu Recall The Recall menu options are: Recall Setup, Recall Management, and Directory Management. Recall Menu Recall Setup This soft key opens a selection box that allows selection and recall of a previously stored instrument setup in the current storage location.
  • Page 170 9-3 File Menu Chapter 9 —Fixed WiMAX Signal Analyzer File Menu Directory Management Opens the Directory Management menu. Note that this menu is available as a soft key option in the File, Recall, and Save menus. Directory Management Menu Sort Method Name Type Date File lists can be sorted by the name of the file, the type of file (SPA file, STP file, and so forth), or by the date that the file was saved.

  • Page 171: Freq (Frequency) Menu

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-4 Freq (Frequency) Menu Freq (Frequency) Menu Freq Center Freq 2.5 GHz Signal Standard Channel Set CF Closest Channel Decrement Channel Increment Channel Figure 9-3. Fixed WiMAX Signal Analyzer Mode Freq Menu Center Freq The Center Freq soft key is used to set the receiver center frequency to the desired value.

  • Page 172: Measurements Menu

    9-5 Limit Chapter 9 —Fixed WiMAX Signal Analyzer Limit This function is not implemented in this mode. Measure To access the functions under the Measure menu, press the Shift key, then the Measure (4) key. The Measure key opens the same menus as the Measurements function hard key. Refer to “Measurements Menu”...
  • Page 173 Chapter 9 —Fixed WiMAX Signal Analyzer 9-7 Measurements Menu RF Meas Menu Spectrum This view displays the spectrum of the input signal. The span is automatically adjusted to the next largest available span based on the bandwidth setting. Channel Power (RSSI) in dBm and Occupied bandwidth measurements are displayed as numerical values.
  • Page 174 9-7 Measurements Menu Chapter 9 —Fixed WiMAX Signal Analyzer The numerical results displayed in this view are: • RCE (rms) in dB • RCE (pk) in dB • EVM (rms) in % • EVM (pk) in % • Freq Error in Hz •...

  • Page 175: Chapter 9 -Fixed Wimax Signal Analyzer 9-8 Mode

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-8 Mode When active, this soft key becomes a switching soft key. Press the soft key again to display the Pass Fail Mode menu options. Pass Fail Mode Menu Select Pass/Fail Test Press this (input) soft key to display the list of available Pass/Fail tests. Reset Press this (input) soft key to reset the Pass/Fail test.

  • Page 176: Setup Menu

    9-9 Setup Menu Chapter 9 —Fixed WiMAX Signal Analyzer Setup Menu Setup 1.25 MHz CP Ratio (G) Span 5 MHz DL Frame Length 2.5 ms Ext. Reference Frequency Figure 9-5. Fixed WiMAX Signal Analyzer Mode Setup Menu Press this (input) soft key to select the Bandwidth by using the Up/Down arrow keys or the rotary knob, and then press Enter.

  • Page 177: System Menu

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-10 System Menu 9-10 System Menu To access the functions under the System menu, press the Shift key, then the System (8) key. System Options System Options Date Ext Ref Freq Status & Time Reset Ethernet Self...
  • Page 178 9-10 System Menu Chapter 9 —Fixed WiMAX Signal Analyzer Application Options This soft key presents a menu to select application options. Options Menu Ext Ref Freq Select the frequency of the external reference from the list presented. Back Returns to the previous (System) menu. System Menu System Options This key opens a selection of system option soft keys.
  • Page 179 MST. Update OS Via USB This soft key should only be used in conjunction with Anritsu MST to update the instrument operating system using an USB connection. Use this soft key only as instructed by MST.
  • Page 180 9-11 Preset Menu Chapter 9 —Fixed WiMAX Signal Analyzer 9-11 Preset Menu To access the functions under the Preset menu, press the Shift key, then the Preset (1) key. Preset Preset Save Setup Recall Setup Figure 9-7. Fixed WiMAX Signal Analyzer Mode Preset Menu Preset This soft key resets the instrument to the default starting conditions.

  • Page 181: Sweep Menu

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-12 Sweep Menu 9-12 Sweep Menu To access the functions under the Sweep menu, press the Shift key, then the Sweep (9) key. Sweep Sweep Continuous Single Trigger Sweep Figure 9-8. Fixed WiMAX Signal Analyzer Mode Sweep Menu Sweep Continuous Single Press this (toggle) soft key to alternate between Continuous and Single.
  • Page 182 9-14 Fixed WiMAX Measurements Chapter 9 —Fixed WiMAX Signal Analyzer 9-14 Fixed WiMAX Measurements The following measurements can be made when the MS271xB is set to Fixed WiMAX mode. Adjacent Subcarrier Flatness (Peak) Adjacent Subcarrier Flatness is the absolute difference between the adjacent subcarriers. Base Station ID Each transmitter has a unique ID.

  • Page 183: Measurement Setup

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-15 Measurement Setup 9-15 Measurement Setup Preparation To prepare for Fixed WiMAX measurements, the instrument must be configured for Fixed WiMAX mode, as follows: 1. Press the Shift key, then the Mode (9) key. 2.

  • Page 184: Bandwidth Setup

    9-15 Measurement Setup Chapter 9 —Fixed WiMAX Signal Analyzer Bandwidth Setup The 802.16-2004 standard specifies a bandwidth from 1.25 MHz to 20 MHz. The bandwidth can be manually set from 1.25 MHz to 10 MHz. To set the bandwidth: 1. Press the Setup function hard key. 2.

  • Page 185: Fixed Wimax Rf Measurements

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-16 Fixed WiMAX RF Measurements 9-16 Fixed WiMAX RF Measurements Fixed WiMAX RF Measurements consists of three measurements: Spectrum, Power versus Time, and Adjacent Channel Leakage Ratio (ACPR). The following sections describe how to make Fixed WiMAX RF measurements. Spectrum Screen The Spectrum screen displays the spectrum of the input signal and channel power in dBm and occupied bandwidth measurements.

  • Page 186: Power Versus Time

    9-16 Fixed WiMAX RF Measurements Chapter 9 —Fixed WiMAX Signal Analyzer Power versus Time The Power versus Time view shows the time domain view of a WiMAX 802.16-2004 OFDM signal over approximately one frame. The preamble is always 3 dB higher than the data. The screen also displays Channel Power (RSSI), Data Burst Power, Preamble Power, and Crest Factor.

  • Page 187: Adjacent Channel Power Ratio (Acpr)

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-16 Fixed WiMAX RF Measurements Adjacent Channel Power Ratio (ACPR) The ACPR view shows one main channel and two adjacent channels and displays the power levels for each channel (both absolute and relative). The channel spacing matches the selected bandwidth and the channels are color coded.
  • Page 188 9-16 Fixed WiMAX RF Measurements Chapter 9 —Fixed WiMAX Signal Analyzer RF Summary The RF Summary displays the critical RF transmitter performance measurements in a table format, without demodulating the WiMAX signal. The parameters displayed in the RF summary table are Channel Power in dBm, Data Burst power in dBm, Preamble power in dBm, Occupied Bandwidth, and Crest Factor.

  • Page 189: Fixed Wimax Demodulator

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-17 Fixed WiMAX Demodulator 9-17 Fixed WiMAX Demodulator The MS271xB will demodulate a Fixed WiMAX Signal from a Base Station and can display the results in Constellation, Spectral Flatness, EVM versus Sub Carrier, EVM versus Symbol and Modulation Summary views.
  • Page 190 9-17 Fixed WiMAX Demodulator Chapter 9 —Fixed WiMAX Signal Analyzer 13. Press the Reference Points soft key to switch the reference points On or Off (refer to Figure 9-14 Figure 9-15 below). Figure 9-14. Constellation with Reference Points On Figure 9-15. Constellation with Reference Points Off 9-26 10580-00181 Rev D MS271xB User Guide...

  • Page 191: Spectral Flatness

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-17 Fixed WiMAX Demodulator Spectral Flatness The Spectral Flatness view shows the data collected from the preamble at the channel estimation step. The deviation of the Spectral Flatness from the average over all the carriers is shown in dB. A mask that conforms to the specification is overlaid on the trace.

  • Page 192: Evm Versus Subcarrier

    9-17 Fixed WiMAX Demodulator Chapter 9 —Fixed WiMAX Signal Analyzer 11. Press the Spectral Flatness soft key to activate the measurement. The red dot on the soft key indicates that it is selected. Figure 9-16. Spectral Flatness View EVM versus SubCarrier This view shows the EVM (rms) values versus OFDM sub-carriers.

  • Page 193: Evm Versus Symbol

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-17 Fixed WiMAX Demodulator 8. For the most accurate frequency measurements, press the Ext. Ref. Freq soft key to display a list of the available reference frequencies and select the desired reference frequency and synchronize the instrument to Internal High Accuracy.

  • Page 194: Modulation Summary

    9-17 Fixed WiMAX Demodulator Chapter 9 —Fixed WiMAX Signal Analyzer 5. Press the Channel soft key and use the Up/Down arrow keys, the keypad, or the rotary knob to select a channel number for the selected signal standard and press the Enter key. The center of the channel is tuned to the center of the display.
  • Page 195 Chapter 9 —Fixed WiMAX Signal Analyzer 9-17 Fixed WiMAX Demodulator Modulation Summary Procedure 1. Press the Shift key, then the Mode (9) key. 2. Use the directional arrow keys or the rotary knob to highlight Fixed WiMAX Signal Analyzer and press the Enter key to select.

  • Page 196: Pass/Fail Mode

    9-18 Pass/Fail Mode Chapter 9 —Fixed WiMAX Signal Analyzer 9-18 Pass/Fail Mode The Pass/Fail mode allows selection of a user-defined file that specifies a list of measurements with pass/fail criteria. This mode sequences through the appropriate measurements and indicates a pass or fail state based on the criteria.

  • Page 197: Wimax Summary

    Chapter 9 —Fixed WiMAX Signal Analyzer 9-19 WiMAX Summary 9-19 WiMAX Summary The WiMAX Summary is a summary of critical Fixed WiMAX measurements from the RF and Demodulation measurements. WiMax Summary Procedure 1. Press the Shift key, then the Mode (9) key. 2.
  • Page 198 9-19 WiMAX Summary Chapter 9 —Fixed WiMAX Signal Analyzer 9-34 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 199: Mobile Wimax Measurements

    Chapter 10 — Mobile WiMAX Signal Analyzer 10-1 Introduction Two Mobile WiMAX options are available for the MS271xB for testing WiMAX BTS transmitter performance: • Mobile WiMAX RF Measurements (Option 66) • Mobile WiMAX Demodulator (Option 67) Attach a coupler or attenuator to the RF In 50 ohm connector on the Economy Microwave Spectrum Analyzer to make measurements directly from the WiMAX BTS transmitter.
  • Page 200 10-3 Measurement Setup Chapter 10 —Mobile WiMAX Signal Analyzer Sector ID Three cell sectors may produce signals with identical data but with different preambles. The Sector ID may be 0, 1, or 2. The Sector ID is displayed in several of the Demodulator measurements. Adjacent Subcarrier Flatness (Peak) Adjacent Subcarrier Flatness is the absolute difference between the adjacent subcarriers in the Spectral Flatness measurement.

  • Page 201: Frame Length Setup

    2. If Manual needs to be selected, then press the Load Parameter File soft key to load an .xml file with the DL-MAP parameters defined using the Anritsu IQProducer software. 3. Press the Demod Type soft key repeatedly to cycle through Auto, Man, and FCH.
  • Page 202 10-3 Measurement Setup Chapter 10 —Mobile WiMAX Signal Analyzer External Reference Frequency Setup In order to get the best frequency accuracy measurements, the use of an external reference frequency is important. Attach it to the Economy Microwave Spectrum Analyzer Ext Ref In connector. Most base stations have a reference frequency that is available on a BNC connector.

  • Page 203: Mobile Wimax Rf Measurements

    Chapter 10 —Mobile WiMAX Signal Analyzer 10-4 Mobile WiMAX RF Measurements 10-4 Mobile WiMAX RF Measurements Mobile WiMAX RF Measurements consists of three measurement types: Spectrum, Power versus Time, and Adjacent Channel Power Ratio (ACPR). Setup for RF Measurements 1. Press the Measurements function hard key. 2.
  • Page 204 10-4 Mobile WiMAX RF Measurements Chapter 10 —Mobile WiMAX Signal Analyzer Power Versus Time The Power versus Time view shows the time domain view of a Mobile WiMAX signal over approximately one frame. The screen also displays Channel Power (RSSI), Downlink Burst Power, Uplink Burst Power, and Preamble Power.
  • Page 205 Chapter 10 —Mobile WiMAX Signal Analyzer 10-4 Mobile WiMAX RF Measurements RF Summary The RF Summary measurement displays the critical RF transmitter performance measurements in a table format, without demodulating the WiMAX signal. The parameters that are displayed in the RF Summary table are Channel Power (dBm), Downlink Burst Power (dBm), Uplink Burst Power (dBm), Preamble Power (dBm), and Occupied Bandwidth (Hz).

  • Page 206: Mobile Wimax Demodulator

    10-5 Mobile WiMAX Demodulator Chapter 10 —Mobile WiMAX Signal Analyzer 10-5 Mobile WiMAX Demodulator The Economy Microwave Spectrum Analyzer will demodulate a Mobile WiMAX Signal from a Base Station, and it can display the results in Constellation, Spectral Flatness, EVM versus Sub Carrier, EVM versus Symbol, Modulation Summary, and DL-MAP views.
  • Page 207 Chapter 10 —Mobile WiMAX Signal Analyzer 10-5 Mobile WiMAX Demodulator • Press the Spectral Flatness soft key to select the measurement. Figure 10-6. Spectral Flatness View EVM Versus Sub Carrier This view shows the EVM values versus OFDMA subcarriers. The numerical results that are displayed in this view are: RCE (dB), RCE (dB), EVM...
  • Page 208 10-5 Mobile WiMAX Demodulator Chapter 10 —Mobile WiMAX Signal Analyzer • Press the EVM vs. Symbol soft key to select the measurement. Figure 10-8. EVM versus Symbol Measurement Modulation Summary The Modulation Summary measurement displays the critical Modulation transmitter performance measurements in a table format by demodulating the WiMAX signal.
  • Page 209 Chapter 10 —Mobile WiMAX Signal Analyzer 10-6 Pass/Fail Mode 2. Use the Up/Down and Left/Right arrow keys to close or open subordinate lists within the map. Figure 10-10.DL-MAP Measurement 10-6 Pass/Fail Mode The Pass/Fail mode allows selection of a user-defined file that specifies a list of measurements with pass/fail criteria.
  • Page 210 10-7 WiMAX Summary Chapter 10 —Mobile WiMAX Signal Analyzer 10-7 WiMAX Summary The WiMAX Summary is a summary of critical Mobile WiMAX measurements from the RF and Demodulator measurements. 1. Press the Measurements function hard key. 2. Press the WiMAX Summary soft key. Figure 10-11.

  • Page 211: Freq (Frequency) Menu

    Chapter 10 —Mobile WiMAX Signal Analyzer 10-8 Freq (Frequency) Menu 10-8 Freq (Frequency) Menu Figure 10-12.Frequency Menu Center Freq, ## Press the Center Freq (input) soft key to set the receiver center frequency to the desired value. Enter the frequency using the keypad, the arrow keys, or the rotary knob. When entering a frequency using the keypad, the soft key labels change to GHz, MHz, kHz, and Hz.

  • Page 212: Amplitude Menu

    10-9 Amplitude Menu Chapter 10 —Mobile WiMAX Signal Analyzer 10-9 Amplitude Menu Figure 10-13.Amplitude Menu Scale, ## Press this (input) soft key to set the scale of the y-axis on the measurement display. Scale can be set from 1 dB/div to 15 dB/div. The default value is 10 dB/div. When EVM is the y-axis value, the units change from dB/div to %/div.

  • Page 213: Setup Menu

    Chapter 10 —Mobile WiMAX Signal Analyzer 10-10 Setup Menu 10-10 Setup Menu Figure 10-14.Setup Menu BW, ## Press this (input) soft key to open the Select Bandwidth list box. Use the Up/Down arrow keys or the rotary knob, and then press the Enter key. The available bandwidths are 5 MHz, 8.75 MHz, and 10 MHz. The default bandwidth is 5 MHz.
  • Page 214 Press this (input) soft key to open the Parameter Files (XML) list box and to select the parameters that are stored in an XML file. This file needs to be generated by using the Anritsu IQProducer software. Ext. Ref. Freq Press this (input) soft key to open the External Reference Frequency list box and select a frequency from the list.

  • Page 215: Measurements Menu

    Chapter 10 —Mobile WiMAX Signal Analyzer 10-11 Measurements Menu 10-11 Measurements Menu Figure 10-15.Measurements Menu The Measurements menu has five soft keys: RF, Demodulator, Pass/Fail Mode, WiMAX Summary, and Save Measurement. Measurements Menu Press the RF soft key to open the RF Meas menu with options of Spectrum, Power versus Time, ACPR, and RF Summary.
  • Page 216 10-11 Measurements Menu Chapter 10 —Mobile WiMAX Signal Analyzer RF Meas Menu Spectrum Press this (select) soft key to set the RF measurement type to Spectrum. This view displays the spectrum of the input signal. The span is automatically adjusted to the next largest available span based on the bandwidth setting.
  • Page 217 Chapter 10 —Mobile WiMAX Signal Analyzer 10-11 Measurements Menu RF Meas Menu Power vs. Time Press the Power vs. Time (select) soft key to use this measurement display. The power versus time view shows the time domain view of a WiMAX 802.16e signal over approximately one frame. The Economy Microwave Spectrum Analyzer automatically tries to synchronize to the downlink preamble without the need for an external trigger.
  • Page 218 10-11 Measurements Menu Chapter 10 —Mobile WiMAX Signal Analyzer Demodulator Menu Constellation Press the Constellation (select) soft key to set the demodulation to Constellation view. The constellation view shows the constellation of the demodulated data symbols over one frame. The constellations are color coded as follows: QPSK is shown in purple 16QAM is shown in green...
  • Page 219 Chapter 10 —Mobile WiMAX Signal Analyzer 10-11 Measurements Menu Modulation Summary Press this (select) soft key to display a summary of all of the modulation-related numerical measurement results. The following measurements are displayed: • RCE (rms) • RCE (pk) • EVM (rms) •...
  • Page 220 10-11 Measurements Menu Chapter 10 —Mobile WiMAX Signal Analyzer Measurements Menu WiMAX Summary Press this (select) soft key to display a summary of all of the WiMAX related numerical measurement results. Refer to Figure 10-15, “Measurements Menu” on page 10-17. These measurements include the following: •...

  • Page 221: Marker Menu

    Chapter 10 —Mobile WiMAX Signal Analyzer 10-12 Marker Menu 10-12 Marker Menu Figure 10-18.Marker Menu This feature is available only when the Power vs. Time measurement is activated. This function hard key opens the Marker menu. Using Markers in Power versus Time Measurements Six regular line markers and six delta markers are available.

  • Page 222: Secondary Function Menus

    10-13 Secondary Function Menus Chapter 10 —Mobile WiMAX Signal Analyzer 10-13 Secondary Function Menus Pressing the Shift key and a number key selects the menu function that is printed in blue characters above the number key. Refer to “Shift Key” on page 2-4 Chapter 2, “Quick Start Guide”.
  • Page 223 Chapter 11 — GSM, GPRS, & EDGE Signal Analyzer 11-1 Introduction Global Systems for Mobile (GSM) communication is a globally accepted standard for digital cellular communication. GSM uses a combination of Frequency Division Multiple Access (FDMA) and Time Division Multiple Access (TDMA). Within each band are approximately one hundred available carrier frequencies on 200 kHz spacing (FDMA), and each carrier is broken up into time-slots so as to support eight separate conversations (TDMA).

  • Page 224: Getting Started

    11-2 Getting Started Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer This chapter describes the MS271xB Economy Microwave Spectrum Analyzer keys in GSM/GPRS/EDGE Signal Analyzer mode. The major sections are arranged in alphabetical order with soft key menus listed in the order they appear from top to bottom.

  • Page 225: Gsm/Gprs/Edge Rf Measurements

    Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-4 GSM/GPRS/EDGE RF Measurements 11-4 GSM/GPRS/EDGE RF Measurements GSM RF measurements consist of Spectrum, Power versus Time (frame), Power versus Time (slot), Summary and Demodulator. To make GSM/GPRS/EDGE measurements, connect the unit to the base station following the instructions below.
  • Page 226 11-4 GSM/GPRS/EDGE RF Measurements Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer Figure 11-1. GSM Single Channel Measurement Example Figure 11-2. GSM Multi-channel Measurement Example 11-4 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...
  • Page 227 Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-4 GSM/GPRS/EDGE RF Measurements To display Power versus Time (Frame) press the Power versus Time (Frame) soft key to activate the Power versus Time (Frame) measurement. The red dot on the soft key indicates that it is selected. Figure 11-3.
  • Page 228 11-4 GSM/GPRS/EDGE RF Measurements Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer To display Power versus Time (Slot) press the Power versus Time (Slot) soft key to activate the Power versus Time (Slot) measurement. The mask is according to the 3GPP TS 05.05 specification. The MS271xB displays the first slot information.
  • Page 229 Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-5 Demodulator 11-5 Demodulator This measurement demodulates the GSM/GPRS/EDGE signal and displays the vector with Phase Error, EVM, Origin Offset, C/I, Modulation Type and Magnitude Error (as applicable). To demodulate the GSM/EDGE signal: 1.
  • Page 230 11-5 Demodulator Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer Figure 11-8. EDGE Demodulator Measurement Example To display the GSM/EDGE Summary screen, press the GSM/EDGE Summary soft key. The red dot on the soft key indicates that it is selected. Figure 11-9.
  • Page 231 Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-5 Demodulator Figure 11-10. EDGE Summary Screen Example MS271xB User Guide 10580-00181 Rev D 11-9 www.valuetronics.com...

  • Page 232: Gsm/Gprs/Edge Mode Pass/Fail

    11-6 GSM/GPRS/EDGE Mode Pass/Fail Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-6 GSM/GPRS/EDGE Mode Pass/Fail The Economy Microwave Spectrum Analyzer can store test sets for testing base station performance and can recall these test sets for quick, easy measurements. These test sets are for reference only and can be edited using Master Software Tools.
  • Page 233 Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-6 GSM/GPRS/EDGE Mode Pass/Fail Figure 11-12. Pass/Fail Mode Test Results Example Refer to the Master Software Tools documentation for information on creating a custom pass/fail test set. MS271xB User Guide 10580-00181 Rev D 11-11 www.valuetronics.com...

  • Page 234: Measurement Results

    11-7 Measurement Results Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-7 Measurement Results Average Burst Power The average burst power over 10 measured burst power values. This average is restarted when a new frequency is selected. Channel Power Channel power measures the average power in a GSM/EDGE frame in the frequency specified. Out of specification power indicates system faults.

  • Page 235: Gsm/Gprs/Edge Menus

    Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-8 GSM/GPRS/EDGE Menus Mag Err (rms) The RMS of the magnitude error between the received signal and an ideal reconstructed reference signal of the first active slot in %. 11-8 GSM/GPRS/EDGE Menus Amplitude Menu The Amplitude function hard key opens the following soft key menu keys: Amplitude...

  • Page 236: Freq (Frequency) Menu

    11-8 GSM/GPRS/EDGE Menus Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer Freq (Frequency) Menu The Freq function hard key opens the following soft key menu: Freq Center Freq 1.000 GHz Signal Standard Channel Set CF To Closest Channel Decrement Channel Increment Channel Figure 11-14.

  • Page 237: Setup Menu

    Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-8 GSM/GPRS/EDGE Menus Setup Menu The Setup function hard key opens the following soft key menu: Setup GSM/EDGE Select Auto GSM EDGE Ext Ref Freq Figure 11-15. GSM/GPRS/EDGE Mode Setup Menu GSM/EDGE Select Auto GSM EDGE Pressing this (toggle) soft key alternates among Auto, GSM and EDGE.

  • Page 238: Measurements Menu

    11-8 GSM/GPRS/EDGE Menus Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer Measurements Menu The Measurements function hard key opens the following soft key menu: Measurements Spectrum Channel Spectrum Spectrum --> Power vs. Multi Time Channel (Frame) Spectrum Power vs. Time (Slot) Demodulator Pass/Fail...
  • Page 239 Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-8 GSM/GPRS/EDGE Menus Freq Cursor Select Freq Cursor to place the cursor at a specific frequency. Use the rotary knob or the Up/Down arrow keys to select the frequency. Press the Enter key to select. Measurements Menu Power Vs Time (Frame) Displays approximately eight and a half slots of the GSM/EDGE signal frame starting from the first...
  • Page 240 11-8 GSM/GPRS/EDGE Menus Chapter 11 —GSM, GPRS, & EDGE Signal Analyzer 11-18 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...
  • Page 241 Chapter 12 — CDMA Signal Analyzer 12-1 Introduction The Economy Microwave Spectrum Analyzer MS271xB offers two CDMA options: • Option 42, CDMA RF measurements • Option 43, cdmaOne and CDMA2000 1xRTT demodulator The Economy Microwave Spectrum Analyzer can measure CDMA signals by directly connecting the Economy Microwave Spectrum Analyzer to the base station.
  • Page 242 12-3 CDMA Measurement Setup Chapter 12 —CDMA Signal Analyzer 12-3 CDMA Measurement Setup The Economy Microwave Spectrum Analyzer can measure CDMA performance by connecting the base station directly to the Economy Microwave Spectrum Analyzer. To connect the base station to the Economy Microwave Spectrum Analyzer, connect the power amplifier of the base station to the RF In port of the Economy Microwave Spectrum Analyzer by using a coupler or attenuator.

  • Page 243: Power Offset Setup (For Compensating External Loss)

    Chapter 12 —CDMA Signal Analyzer 12-3 CDMA Measurement Setup 4. Press the Channel soft key and use the Up/Down arrow keys, the keypad, or the rotary knob to select a channel number for the selected signal standard. The center of the channel is tuned to the center of the screen.

  • Page 244: Pn Select Setup

    12-3 CDMA Measurement Setup Chapter 12 —CDMA Signal Analyzer PN Select Setup The Economy Microwave Spectrum Analyzer needs a timing reference in order to determine PN Offset and timing errors. This reference comes from the base station when it is connected to the Economy Microwave Spectrum Analyzer.

  • Page 245: Walsh Codes Setup

    Chapter 12 —CDMA Signal Analyzer 12-3 CDMA Measurement Setup Walsh Codes Setup Walsh Codes setup is used to select whether cdmaOne (Walsh Codes 64) or CDMA2000 1xRTT (Walsh Codes 128) is required for the measurements. When the 128 codes option is selected, the upper CDP (Code Domain Power) graph displays the CDP in bit-reversed order.

  • Page 246: Channel Spectrum Setup

    12-4 CDMA RF Measurement Setup Chapter 12 —CDMA Signal Analyzer 12-4 CDMA RF Measurement Setup To make CDMA RF measurements, connect the Economy Microwave Spectrum Analyzer to the base station and follow these setup instructions: 1. Press the Shift key, then the Mode (9) key. 2.

  • Page 247: Acpr Setup

    Chapter 12 —CDMA Signal Analyzer 12-4 CDMA RF Measurement Setup Figure 12-6. RF Measurement, Spurious Emission ACPR Setup ACPR (Adjacent Channel Power Ratio) is defined as the ratio of the amount of leakage power in an adjacent channel to the total transmitted power in the main channel and is displayed in table format under the bar graph.

  • Page 248: Cdp Setup

    12-5 CDMA Demodulator Measurements Setup Chapter 12 —CDMA Signal Analyzer 12-5 CDMA Demodulator Measurements Setup CDMA demodulator measurements are selected by pressing the Measurements hard key. CDMA demodulator measurements include Code Domain Power (CDP), CDP table, and modulation summary. To demodulate cdmaOne and CDMA2000 1xRTT signals, connect the Economy Microwave Spectrum Analyzer to the base station following the setup instructions.

  • Page 249: Cdp Table View Setup

    Chapter 12 —CDMA Signal Analyzer 12-5 CDMA Demodulator Measurements Setup Figure 12-8. Demodulator Menu with CDP Measurement CDP Table View Setup The CDP table view displays all of the active codes in a tabular format. Figure 12-9. CDP Table From the Demodulator measurement menu, use the following procedure for CDP Table view: 1.

  • Page 250: Pass Fail Setup

    12-6 Pass Fail Setup Chapter 12 —CDMA Signal Analyzer 12-6 Pass Fail Setup The Economy Microwave Spectrum Analyzer stores user-defined Pass Fail criteria for testing base station performance and recalls these models for quick, easy measurements. After selection of a test file, the Economy Microwave Spectrum Analyzer displays test results in tabular format with clear PASS or FAIL indications that include minimum/maximum threshold.
  • Page 251 Chapter 12 —CDMA Signal Analyzer 12-7 CDMA Measurement Descriptions 12-7 CDMA Measurement Descriptions Code Division Multiple Access (CDMA) is used in spread spectrum systems to achieve multiple access. The frequency spectrum of a signal is spread by using a code that is not correlated with the data signal. This code is unique to each recipient.
  • Page 252 12-7 CDMA Measurement Descriptions Chapter 12 —CDMA Signal Analyzer Carrier Feedthrough Carrier Feedthrough measures the amount of unmodulated signal that is leaking through the transmitter. Frequency Error Frequency error is the difference between the received center frequency and the specified center frequency. This is only as accurate as the frequency reference that is used and is typically only useful with a good quality external frequency reference.

  • Page 253: Amplitude Menu

    Chapter 12 —CDMA Signal Analyzer 12-8 Amplitude Menu 12-8 Amplitude Menu Amplitude Scale / div ## dB / div Power Offset ## dB Auto Range Adjust Range Figure 12-11. CDMA Amplitude Menu Scale/div Press this (input) soft key to set the scale in 1 dB steps from 1 dB per division to 15 dB per division. The value can be changed using the keypad, the rotary knob, or the Up/Down arrow keys.

  • Page 254: Freq (Frequency) Menu

    12-10 Freq (Frequency) Menu Chapter 12 —CDMA Signal Analyzer 12-10 Freq (Frequency) Menu Figure 12-12.CDMA Frequency Menu Center Freq Press the Freq key followed by the Center Freq (input) soft key and enter the desired frequency using the keypad, the arrow keys, or the rotary knob. If entering a frequency by using the keypad, then the soft key labels change to GHz, MHz, kHz, and Hz.
  • Page 255 Chapter 12 —CDMA Signal Analyzer 12-11 Limit Menu Increment Channel Press this (input) soft key to increase the channel number. Channel number is incremented by one channel or by a step size. Depending upon the signal standard and upon the selected channel, pressing this soft key increments the channel number by a standard step size.

  • Page 256: Measurements Menu

    12-13 Measurements Menu Chapter 12 —CDMA Signal Analyzer 12-13 Measurements Menu Figure 12-14.CDMA Measurements Menu The CDMA Measurements menu provides links to the RF, Demodulator, Pass Fail, CDMA Summary, and Save Measurement soft keys and functions. Measurements Menu Pressing this soft key opens the RF Measurement soft key menu. 12-16 10580-00181 Rev D MS271xB User Guide...
  • Page 257 Chapter 12 —CDMA Signal Analyzer 12-13 Measurements Menu RF Measurement Menu Channel Spectrum Pressing this soft key displays the channel spectrum of the input signal (2.5 MHz span). The screen also displays numeric values of Channel Power in dBm and watts, Peak to Average power in dB, and Occupied Bandwidth (Occ BW).
  • Page 258 12-13 Measurements Menu Chapter 12 —CDMA Signal Analyzer When Code Domain Power (CDP) is selected, the screen displays all of the selected Walsh Codes and the selected Walsh Codes zoom codes in a graphical format. Depending upon the Walsh Code set parameter, this display includes either 64 Walsh Codes or 128 Walsh Codes.

  • Page 259: Mode Menu

    Chapter 12 —CDMA Signal Analyzer 12-14 Mode Menu Measurements Menu Pass Fail The first press of this (select) soft key puts the Economy Microwave Spectrum Analyzer into Pass Fail Mode and sets the soft key as a switching soft key. The next press of the (switching) soft key opens the Pass Fail Mode soft key menu.

  • Page 260: Setup Menu

    12-16 Setup Menu Chapter 12 —CDMA Signal Analyzer 12-16 Setup Menu Setup PN Setup PN Trigger PN Setup No Trig --> Walsh Codes PN Search Type Auto Manual Meas Speed Manual PN Offset Fast Norm Slow Ext Trig Polarity Rising Falling Ext.
  • Page 261 Chapter 12 —CDMA Signal Analyzer 12-17 Sweep Menu Manual PN Offset Press this soft key to manually set the PN offset. Use the arrow keys, rotary knob, or numeric keypad to choose an offset, then press the rotary knob or the Enter key to select the value. Editing this value automatically changes the PN Search Type to Manual.
  • Page 262 12-18 System Menu Chapter 12 —CDMA Signal Analyzer 12-18 System Menu Figure 12-16.CDMA System Menu For the soft key descriptions of the System menu, refer to section “System Menu” on page 3-33. 12-22 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...
  • Page 263 Chapter 13 — EVDO Signal Analyzer 13-1 Introduction The MS271xB Economy Microwave Spectrum Analyzer offers two EVDO options: • Option 62, EVDO RF measurements • Option 63, EVDO Demodulator, Rev. A compatible CDMA2000 1xEVDO has a chip rate of 1.2288 MHz, the same as cdmaOne and CDMA2000 1xRTT. Each chip lasts for a duration of 0.8138 microseconds.
  • Page 264 13-3 EVDO Measurement Setup Chapter 13 —EVDO Signal Analyzer 13-3 EVDO Measurement Setup The Economy Microwave Spectrum Analyzer can measure EVDO performance by connecting the base station directly to the Economy Microwave Spectrum Analyzer. Setting up the Measurement Frequency The measurement frequency can be set by entering the center frequency or by selecting the applicable signal standard and channel, which allows the Economy Microwave Spectrum Analyzer to automatically set the frequency.

  • Page 265: Mac Codes Setup

    Chapter 13 —EVDO Signal Analyzer 13-3 EVDO Measurement Setup Ext: The Economy Microwave Spectrum Analyzer uses an external even-second time mark as the timing reference. The time mark is usually available at the base station on a BNC connector labeled “ESTM” or “PP2S”.
  • Page 266 13-4 EVDO RF Measurements Setup Chapter 13 —EVDO Signal Analyzer 13-4 EVDO RF Measurements Setup To make EVDO RF measurements, connect the Economy Microwave Spectrum Analyzer to the base station following the setup instructions. 1. Press the Shift key, then the Mode (9) key. 2.
  • Page 267 Chapter 13 —EVDO Signal Analyzer 13-4 EVDO RF Measurements Setup Power versus Time Setup From the RF Measurement menu, press Power vs. Time to display the active measurement Figure 13-2. EVDO Power Versus Time Measurement Display ACPR Setup ACPR (Adjacent Channel Power Ratio) is defined as the ratio of the amount of leakage power in an adjacent channel to the total transmitted power in the main channel and is displayed in table format under the bar graph.
  • Page 268 13-4 EVDO RF Measurements Setup Chapter 13 —EVDO Signal Analyzer Spurious Emission Setup The Spurious Emission test examines emissions at frequencies that are outside of the assigned EVDO channel. Spurious emission should be measured at the base station RF Output port by using a direct cable connection. Figure 13-4.

  • Page 269: Cdp Mac Setup

    Chapter 13 —EVDO Signal Analyzer 13-5 EVDO Demodulator Measurements Setup 13-5 EVDO Demodulator Measurements Setup EVDO demodulator measurements include, CDP MAC, CDP Data, MAC CDP table, and Modulation Summary. To demodulate EVDO signals, connect the Economy Microwave Spectrum Analyzer to the base station by using the following setup instructions: 1.

  • Page 270: Marker Setup (Activating Markers)

    13-5 EVDO Demodulator Measurements Setup Chapter 13 —EVDO Signal Analyzer From the Demodulator menu, use the following procedure for CDP MAC measurements: 1. Press the CDP MAC soft key to display MAC codes. 2. Press the CDP MAC soft key again to display the CDP MAC soft key menu. 3.

  • Page 271: Mac Cdp Table Setup

    Chapter 13 —EVDO Signal Analyzer 13-5 EVDO Demodulator Measurements Setup MAC CDP Table Setup The MAC CDP Table View displays all of the active codes in a tabular format. Figure 13-7. EVDO MAC CDP Table Measurement Display From the Demodulator menu, use the following procedure to enter MAC CDP Table View: Press the MAC CDP Table soft key to display the Code Domain Power table view.
  • Page 272 13-6 Pass Fail Setup Chapter 13 —EVDO Signal Analyzer 13-6 Pass Fail Setup The Economy Microwave Spectrum Analyzer stores user-defined pass fail criteria test models for testing base station performance and recalls these models for quick, easy measurements. After selection of a test model, the Economy Microwave Spectrum Analyzer displays test results in tabular format with clear PASS or FAIL indications that include minimum/maximum threshold.
  • Page 273 Chapter 13 —EVDO Signal Analyzer 13-7 EVDO Summary Setup 13-7 EVDO Summary Setup EVDO summary displays EVDO critical RF and demodulator measurements in tabular format. Figure 13-10.EVDO Summary Measurement Display From the Measurements menu, press the EVDO Summary soft key to display the measurements in tabular format.
  • Page 274 13-8 EVDO Measurement Descriptions Chapter 13 —EVDO Signal Analyzer 13-8 EVDO Measurement Descriptions Active Data Power Active Data Power is the average power of the Data Channel portion of the active EVDO slot that is captured. When the slot is active, the data power should be very similar to the MAC & Pilot power (less than 2.5 dB difference).
  • Page 275 Chapter 13 —EVDO Signal Analyzer 13-8 EVDO Measurement Descriptions PN Offset Each EVDO base station is identified by a unique PN Offset in its pilot signal. This is similar to CDMA. Power versus Time Graph This view shows the time domain view of an EVDO half-slot. The Slot Type selection in the Setup menu determines the priorities regarding which slot is displayed.
  • Page 276 13-9 EVDO Menus Chapter 13 —EVDO Signal Analyzer 13-9 EVDO Menus Amplitude Menu Refer to Section 12-8 “Amplitude Menu” on page 12-13 Chapter 12, “CDMA Signal Analyzer”. File Menu Refer to Section 12-9 “File Menu” on page 12-13. Frequency Menu Refer to Section 12-10 “Freq (Frequency) Menu”...

  • Page 277: Measurements Menu

    Chapter 13 —EVDO Signal Analyzer 13-10 Measurements Menu 13-10 Measurements Menu Also refer to the similar CDMA Measurements menu in Section 12-13 “Measurements Menu” on page 12-16 Chapter 12, “CDMA Signal Analyzer”. Figure 13-11. EVDO Measurements Menu The EVDO Measurements menu provides soft keys for RF Measurement, Demodulator, Pass Fail, EVDO Summary, and Save Measurement.
  • Page 278 13-10 Measurements Menu Chapter 13 —EVDO Signal Analyzer Measurements Menu RF Measurement Pressing this (switching) soft key opens the RF Measurement soft key menu. EVDO includes the Power vs. Time soft key and the Spurious Emission soft key. The menu functions are similar to CDMA (refer to Chapter 12, “CDMA Signal Analyzer”,...
  • Page 279 Chapter 13 —EVDO Signal Analyzer 13-10 Measurements Menu After the CDP MAC soft key has become the active function, the soft key becomes a switching soft key. Press this key again to open the CDP menu. Only the functions that differ from those in the CDMA menu (“Measurements Menu”...
  • Page 280 13-10 Measurements Menu Chapter 13 —EVDO Signal Analyzer Demodulator Menu MAC CDP Table Press this (select) soft key to show the power of the codes in a tabular format. The table displays the following 4 columns: • Code number • Status: RA, Active, Pilot, Page, Sync, All Traffic (Color Coded rows) •...
  • Page 281 Chapter 13 —EVDO Signal Analyzer 13-11 Mode Menu 13-11 Mode Menu To access the functions under the Mode menu, press the Shift key, then the Mode (9) key. Use the directional arrow keys or the rotary knob to highlight the selection and press the Enter key to select. The list of modes that appears in this menu will vary depending upon the options that are installed and activated in your instrument.
  • Page 282 13-16 Trace Menu Chapter 13 —EVDO Signal Analyzer 13-20 10580-00181 Rev D MS271xB User Guide www.valuetronics.com...

  • Page 283: Mode Selection

    Chapter 14 —TD-SCDMA Signal Analyzer 14-1 Introduction Chapter 14 — TD-SCDMA Signal Analyzer 14-1 Introduction The TD-SCDMA Signal Analyzer offers two options: RF Measurements and Demodulator measurements. Three display types are provided for RF Measurements: Channel Spectrum display, Power versus Time display, or the RF Summary table.

  • Page 284: General Setup

    14-2 TD-SCDMA Measurements General Setups Chapter 14 —TD-SCDMA Signal Analyzer Amplitude Setup Scale, Reference Level, and Units Set up the amplitude parameters: 1. Press the Amplitude function hard key. 2. Press the Scale/div soft key. The value on the face of the virtual soft key turns red, which indicates that it is ready to be edited.

  • Page 285: Measurement Setup

    Chapter 14 —TD-SCDMA Signal Analyzer 14-3 TD-SCDMA RF Measurements 14-3 TD-SCDMA RF Measurements The following parameters are measured in the RF Measurement mode. Channel Power Channel power measures the average time domain power within the 1.6 MHz channel bandwidth and is expressed in dBm.
  • Page 286 14-3 TD-SCDMA RF Measurements Chapter 14 —TD-SCDMA Signal Analyzer Channel Spectrum Figure 14-1. Channel Spectrum Measurement 1. Press the Setup function hard key. 2. Press the Advanced Settings soft key. a. Press the Number of Carriers soft key. The current value on the face of the virtual soft key turns red and is ready to be edited.
  • Page 287 Chapter 14 —TD-SCDMA Signal Analyzer 14-3 TD-SCDMA RF Measurements c. Press the Back soft key to return to the Setup menu. d. Press the Uplink Switch Point soft key. The current value on the face of the virtual soft key turns red and is ready to be edited.
  • Page 288 14-3 TD-SCDMA RF Measurements Chapter 14 —TD-SCDMA Signal Analyzer Figure 14-3. Power versus Time: Slot Measurement RF Summary The RF Summary displays the critical RF transmitter performance measurements in a table format, without demodulating the TD-SCDMA signal. The parameters that are displayed in the RF summary table are Channel Power (dBm), Channel Power (RRC) (dBm), Occupied Bandwidth (Hz), DwPTS Power (dBm), UpPTS Power (dBm), On/Off Ratio (dB), Slot PAR (dB), Left Channel Power (dBm), Right Channel Power (dBm), Left Channel Occupied Bandwidth, and Right Channel Occupied Bandwidth.
  • Page 289 Chapter 14 —TD-SCDMA Signal Analyzer 14-4 TD-SCDMA Demodulator 4. In the RF Measurement menu, press the RF Summary soft key to view the primary RF measurements in a table. 14-4 TD-SCDMA Demodulator Figure 14-4. Demodulator Measurement – CDP Data The following parameters are measured in the Demodulator option. Slot Power The power measured in the selected slot, excluding the gap.
  • Page 290 14-4 TD-SCDMA Demodulator Chapter 14 —TD-SCDMA Signal Analyzer Peak CDE The peak of the Code Domain Error (CDE) is the remnant power in the code domain after the useful signal is extracted. Scrambling Codes The display format is Scrambling Code # (relative power in dB). A measure of the relative powers of the 4 scrambling codes (relative to Slot Power) that correspond to the detected SYNC-DL code.
  • Page 291 Chapter 14 —TD-SCDMA Signal Analyzer 14-4 TD-SCDMA Demodulator 5. Press the Back soft key to return to Demodulator menu. 6. Press the Back soft key again to return to the Measurements menu. Modulation Summary The Modulation Summary displays the critical Modulation transmitter performance measurements in a table format by demodulating the TD-SCDMA signal that is displayed in the Modulation Summary table: Slot Power, EVM, Peak EVM, Freq Error, Freq Error PPM, Tau, Noise Floor, Carrier Feed Through, and Peak CDE.
  • Page 292 14-5 TD-SCDMA Pass/Fail Measurements Chapter 14 —TD-SCDMA Signal Analyzer 14-5 TD-SCDMA Pass/Fail Measurements The following is an example of a Pass/Fail measurement. Measurement Setup 1. Follow the procedures described in section “TD-SCDMA Measurements General Setups” on page 14-1. 2. Press the Measurements hard key. 3.
  • Page 293 Chapter 14 —TD-SCDMA Signal Analyzer 14-7 Freq (Frequency) Menu 14-7 Freq (Frequency) Menu Figure 14-6. Freq Menu Press the Freq function hard key to display the Freq soft key menu. Center Freq Press this (input) soft key to set the receiver center frequency to the desired value. Enter the frequency (2.7 GHz is the maximum value that can be entered) by using the keypad, the arrow keys, or the rotary knob.
  • Page 294 14-8 Amplitude Menu Chapter 14 —TD-SCDMA Signal Analyzer 14-8 Amplitude Menu Figure 14-7. Amplitude Menu Press the Amplitude function hard key to display the Amplitude soft key menu. Scale/div Press this (input) soft key to change the scale of the y-axis in the measurement display. This setting applies to the Channel Spectrum, and CDP Data views only.
  • Page 295 Chapter 14 —TD-SCDMA Signal Analyzer 14-9 Setup Menu 14-9 Setup Menu Figure 14-8. Setup Menu Press the Setup function hard key to display the Setup soft key menu. Setup Menu Slot Selection Press this soft key to open the Slot Selection list box. Use the arrow keys or the rotary knob to highlight Auto or one of the six slots.
  • Page 296 14-9 Setup Menu Chapter 14 —TD-SCDMA Signal Analyzer Slot Selection Menu Auto Automatically looks for an active downlink slot. Auto in the Slot Selection window and the Auto soft key have the same function. The Auto soft key allows for a slightly quicker selection of the Auto function.
  • Page 297 Chapter 14 —TD-SCDMA Signal Analyzer 14-9 Setup Menu Setup Menu Scrambling Midamble Code Press this (input) soft key to open the Scrambling/Midamble Code list box. Use the Up/Down arrow keys or the rotary knob to highlight Auto or 0 through 127 and press Enter. If Auto is selected, the active Scrambling/Midamble code is displayed.
  • Page 298 14-10 Measurements Menu Chapter 14 —TD-SCDMA Signal Analyzer Back Press this soft key to return to the Setup menu. 14-10 Measurements Menu Figure 14-10.Measurements Menu Measurements Menu RF Measurements Press this (switching) soft key to display the RF Measurement soft key menu. RF Measurement Menu Channel Spectrum Press this soft key to displays the spectrum of the input signal.
  • Page 299 Chapter 14 —TD-SCDMA Signal Analyzer 14-10 Measurements Menu Power vs. Time Press this (select) soft key once to place the measurement display in power versus time view. When active, this soft key becomes a switching soft key. Press this (switching) soft key to open the Power vs.
  • Page 300 14-10 Measurements Menu Chapter 14 —TD-SCDMA Signal Analyzer RF Measurement Menu RF Summary Press this (select) soft key to display the following RF measurements in table format: • Channel Power • Channel Power (RRC) • Occ BW • DwPTS Pwr •...
  • Page 301 Chapter 14 —TD-SCDMA Signal Analyzer 14-10 Measurements Menu Demodulator Menu Modulation Summary Press this (select) soft key to view the performance of the transmitter demodulated TD-SCDMA signal in table format. The following parameters are displayed in the table: • Slot Power (dBm) •...
  • Page 302 14-10 Measurements Menu Chapter 14 —TD-SCDMA Signal Analyzer Measurements Menu TD-SCDMA Summary Press this (select) soft key to display a table of the TD-SCDMA measurements. The following measurement values are displayed in the table: • Channel Power • Occ BW •...

  • Page 303: Appendix A Signal Standards

    Appendix A Signal Standards Table of Signal Standards This appendix provides a list of the signal standards included in the MS271xB Economy Microwave Spectrum Analyzer. The standards that are displayed depend upon the operating mode selected. Table A-1. Table of Signal Standards Center Span Standard...
  • Page 304 A-1 Table of Signal Standards Appendix ASignal Standards Table A-1. Table of Signal Standards (Continued) Center Span Standard (MHz) (MHz) Valid Channels cdma2000 Signal Standards cdma2000 Class 0, Korea Cellular - Uplink 1-799, 990-1023 cdma2000 Class 0, Korea Cellular - Downlink 1-799, 990-1023 cdma2000 Class 0, N.A.
  • Page 305 Appendix ASignal Standards A-1 Table of Signal Standards Table A-1. Table of Signal Standards (Continued) Center Span Standard (MHz) (MHz) Valid Channels N-AMPS Signal Standards N-AMPS / IS-88L - Uplink 1-799, 990-1023 N-AMPS / IS-88L - Downlink 1-799, 990-1023 N-AMPS / IS-88M - Uplink 1-799, 990-1023 N-AMPS / IS-88M - Downlink 1-799, 990-1023...
  • Page 306 A-1 Table of Signal Standards Appendix ASignal Standards Table A-1. Table of Signal Standards (Continued) Center Span Standard (MHz) (MHz) Valid Channels SMR Signal Standards SMR 800 - 12.5 kHz - Uplink 1-1199 SMR 800 - 12.5 kHz - Downlink 1-1199 SMR 800 - 25 kHz - Uplink 1-600...

  • Page 307: Self Test Or Application Self Test Error Messages

    This chapter provides a list of information and error messages that could be displayed on the MS271xB Economy Microwave Spectrum Analyzer. If any error condition persists, then contact your local Anritsu Service Center. Available error message types are described in the following sections: •...

  • Page 308: Operation Error Messages

    “MS271xB Optional Accessories” on page 1-4) for a list available band pass filters from Anritsu. Out of band frequencies can often be detected by increasing the SPAN to maximum in peak detect mode of operation. Another resolution may be to Reset to factory defaults with either Factory Defaults, ESC+ON, or MASTER RESET, System+ON.
  • Page 309 Caution return the unit to a fully Factory Default condition. If the error persists, contact your Anritsu Service Center. Trace not saved. Please wait for complete sweep and try again. Attempted to save a measurement trace before the sweep had completed at least once. Wait for at least one complete sweep and try to save again.
  • Page 310 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. EEPROM TEST: UNKNOWN ERROR Hardware communications between modules has failed. Insure that the temperature is within acceptable limits.
  • Page 311 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. UNKNOWN ERROR In SPA Hardware communications between modules has failed. Insure that the that temperature is within acceptable limits.
  • Page 312 Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Lock failed during initialization One or more of the Phase Lock Loops failed to achieve lock status during startup. Insure that the temperature is within acceptable limits.
  • Page 313 Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Copy failed. Please check External Card Attempt to copy user saved data to external the Compact Flash Card has failed. Do not attempt to remove or power down the unit before the copy has completed.
  • Page 314 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Fatal Error Usually caused by a failure to communicate with one section or another. Sometimes resolved by restarting the unit or by Factory Defaults, ESC+ON, resetting of the unit.

  • Page 315: Fixed Wimax Messages

    Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and Caution return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Fatal error EEPROM failed Hardware communications between modules has failed. Insure that the temperature is within acceptable limits.

  • Page 316: Mobile Wimax Messages

    B-6 Mobile WiMAX Messages Appendix BError Messages Lock Failure xx When a lock failure is detected from any of the internal LOs, this message is displayed. The xx is usually an error code in hex that can be interpreted by a service center to obtain more information on which LO had the failure.
  • Page 317 Appendix BError Messages B-7 WCDMA/HSDPA and GSM/GPRS/EDGE Messages Lock Failure xx When a lock failure is detected from any of the internal local oscillators (LOs), this message is displayed. The xx is usually an error code in hex that can be interpreted by a service center to obtain more information on which LO had the failure.

  • Page 318: Warning Messages

    B-8 CDMA and EVDO Messages Appendix BError Messages Notifications 1. RF Over Power 2. ADC over range A. If Auto Range is ON - ADC over range: Decrease input power. B. If Auto Range is Off and if Atten = 65, then ADC over range: Decrease input power. C.
  • Page 319 Index Symbols Active Channel Threshold Level, defined WCDMA⁄HSDPA ......7-21 +⁄- (Code) key ......2-4 Active Data Power, Defined for EVDO .
  • Page 320 Center frequency CDMA .......12-2 C/I (Carrier to Interference Ratio) Selecting a signal standard ....2-15 C/I (dB), GSM, GPRS, EDGE .
  • Page 321 Enter key ....... .2-6 Entering text, example .....2-6 Data Modulation, EVDO .
  • Page 322 EVDO ACLR ........7-24 Active Activity ..... . 13-12 Fixed WiMAX, main topic .
  • Page 323 Half slot, EVDO ......13-1 Key Menus Hard Keys Trace A Ops ......3-36 Amplitude .
  • Page 324 Mask ........7-29 Power offset ..... . .13-2 Master reset Power vs time .
  • Page 325 Menus ....... . . 3-36 Trace B Ops ......3-36 ACPR .
  • Page 326 IP address ....2-10, 2-11, 3-34 20 Tracking Generator, MS2717B only ..6-1 Ipconfig tool ......2-12 40 GSM⁄GPRS⁄EDGE RF Measurements .
  • Page 327 Peak (P-CCPCH) ......7-19 CD Error (Peak Code Domain Error) ..7-20 Primary Sync Channel (P-SCH) .
  • Page 328 Software release notification ....2-1 Defined for CDMA ....12-12 Software Tools Defined for EVDO .
  • Page 329 Text entry ......2-6, 2-7 Units, linear ......2-14 Threshold Up⁄Down arrow keys .
  • Page 330 WiMAX summary Mobile WiMAX measurement ..10-12 Zoom ........7-32 Wireless hot spots .
  • Page 331 www.valuetronics.com...
  • Page 332 Anritsu Company 490 Jarvis Drive Printed on Recycled Paper with Vegetable Soybean Oil Ink Morgan Hill, CA 95037-2809 www.valuetronics.com http://www.anritsu.com/...

This manual is also suitable for:

Ms2718bMs2719b
