Instrument Overview
Shift Key
Pressing the Shift key and then a number key executes the function that is indicated in blue
text above the number key. When the Shift key is active, its icon is displayed at the top-right
of the measurement display area by the battery charge indicator.
Figure 2-4. Shift Key Icon
Number Keypad
The Number keypad has two functions: The primary function is number entry. The secondary
function of the number keypad is to list various menus. See
on page 2-5.
Rotary Knob
Turning the rotary knob changes numerical values, scrolls through selectable items from a
list, and moves markers. Values or items may be within a dialog box or an edit window.

Touch Screen Keys

Main Menu Touch Screen Keys
These five main menu keys are horizontally arranged along the lower edge of the touch
screen. The main menu key functions change to match specific instrument Mode settings.
The main menu keys generate function-specific submenus. The various measurement modes
are selected by pressing the Shift key and then the Mode (9) key. Descriptions of the various
measurement modes can be found in the applicable Measurement Guides listed in
Appendix A, "Measurement
Available measurement modes are based on model and options purchased. Refer
Note
to Table 1-1
Submenu Touch Screen Keys
These submenu keys are arranged along the right-hand edge of the touch screen. The
submenu labels change as instrument measurement settings change. The current submenu
title is shown at the top of the submenu key block.

Keypad Menu Keys (1 to 9)

Pressing the Shift key and then a number key selects the menu function that is printed in
blue characters above the number key. See
Not all Secondary Function Menus are active in various measurement modes. If any one of
these menus is available in a specific instrument mode of operation, then it can be called from
the number keypad. It may also be available from a main menu key or a submenu key.
The Preset Menu (1) and System Menu (8) are described in
The Sweep Menu (3), Measure Menu (4), Trace Menu (5), and Limit Menu (6) vary depending
on measurement mode, see the Measurement Guides listed in
The File Menu (7) is described in
described in "Mode Selector Menu" on page
Spectrum Master User Guide
Guides".
for additional information.
Figure 2-1 on page
Chapter 4, "File
2-12.
PN: 10580-00328 Rev. E
2-4 Front Panel Overview
"Keypad Menu Keys (1 to 9)"
2-2.
Chapter 5, "System Operations
Appendix A
Management". The Mode Menu (9) is
".
for information.
2-5
