Chapter 2 - Instrument Overview
2-1

Introduction

This chapter provides a brief overview of the Anritsu Spectrum Master. The intent of this
chapter is to acquaint the user with the instrument. For detailed measurement information,
refer to a specific measurement guide listed in
2-2

Chapter Overview

• "Turning On the Spectrum Master" on page 2-1
• "Front Panel Overview " on page 2-2
• "Display Overview " on page 2-6
• "Test Panel Connector Overview" on page 2-8
• "Symbols and Indicators" on page 2-9
• "Data Entry" on page 2-11
• "Mode Selector Menu" on page 2-12
2-3

Turning On the Spectrum Master

The Anritsu Spectrum Master is capable of approximately three hours of continuous
operation from a fully charged, field-replaceable battery (see
Replacement" on page
(which will also simultaneously charge the battery). This can be achieved with either the
Anritsu AC-DC Adapter or the Automotive Cigarette Lighter Adapter. Both items are
included with the Spectrum Master.
When using the Automotive Cigarette Lighter Adapter, always verify that the
supply is rated for a minimum of 60 Watts @ 12 VDC, and that the socket is clear
Caution
of any dirt or debris. If the adapter plug becomes hot to the touch during operation,
discontinue use immediately.
Spectrum Master User Guide
1-5). The Spectrum Master can also be operated from a 12 Vdc source
PN: 10580-00328 Rev. E
Appendix A, "Measurement
Section 1-14 "Battery
Guides".
2-1
