File Management

Recall Menu

Key Sequence: File > Recall
Recall
Sort By
Name Type Date
Sort Order
Asc Desc
File Type
ALL
Refresh
Directories
Figure 4-11. Recall Menu
Spectrum Master User Guide
This menu and dialog box is used to navigate folders and select files to
recall to the Spectrum Master. Select folders or files with the Up/Down
keys, the rotary knob, or the touch screen.
Sort By: Press this submenu key to sort file and folders by the file name,
by the type of file, or by the date that the file or folder was saved.
Sort Order: Displays the folder or file in ascending or descending order
based on the selection in the Sort By key.
File Type: Press this submenu key to select what type of file is viewed. The
options are the ALL, Measurement, or Setup. The file type can be changed
with the Up/Down keys, the rotary knob, or the touch screen. Press Enter
to make the selection.
Setup: Setup files contain basic instrument information,
measurement mode setup details, measurement marker data, and
limit data.
Measurement: Measurement files contain all of the information in
the setup files and the measurement data.
Limit Lines (.lim): The Limit line file contains limit line data details.
ALL: Displays all file types.
Refresh Directories: Press this key to update the display.
