5-3 System Menu

System Options Menu

Key Sequence: Shift, System (8) > System Options
System Options
Date
&
Time
Language
Display
Name
Volume
Reset
More
Figure 5-3. System Options Menu
5-4
Date and Time: This key brings up a dialog box for setting the current date
and time. Use the submenu keys or the Left/Right arrow keys to select the
field to be modified. Use the keypad, the Up/Down arrow keys or the rotary
knob to select the date and time. Press Enter to accept the changes, or
press the Esc key to return to normal operation without changing anything.
Language: This submenu key brings up a selection box allowing selection
from a list of built-in languages for the Spectrum Master displays. The
languages currently available are English, French, German, Spanish,
Japanese, Chinese, Korean, and Italian. In addition, up to two custom
languages may be loaded into the instrument if they have been defined using
the Master Software Tools. If a mode does not have language translations
available, English is the default language. Press Enter to accept the change,
or press the Esc key to return to normal operation without changing the
setting.
Display: The Display submenu key opens the
on page 5-6 allowing brightness control and the selection of the default color
display, black & white display, night vision display, or a high contrast display.
Name: Opens a dialog box to name the instrument. The unit can be named
using the keypad to select numbers and the touch screen keys to select letter
groups. Use the Shift key to select an upper case letter. Use the Left/Right
directional arrows to move the cursor position. The Back Space key will
remove the last character entered. Press Enter to save the name.
Volume: The current volume setting is displayed on the screen. Use the
keypad, the Up/Down arrow keys or the rotary knob to change the volume
and press the Enter key to accept the change.
Reset: Press this submenu key to open the
More: Press this submenu key to open the
on page 5-5.
PN: 10580-00328 Rev. E
System Operations
"Display Settings Menu"
"Reset Menu" on page
"System Options 2/2 Menu"
Spectrum Master User Guide
5-7.
