Anritsu Spectrum Master MS2711E User Manual page 28

2-4 Front Panel Overview
Press and hold down any key for a few seconds to add a shortcut to this screen.To shortcut
setup files (.stp), open the recall menu and hold down on the file name for several seconds.
Then select the location for the shortcut.
Figure 2-3. Menu Key Screen
User-defined shortcuts will stay in memory until deleted. To delete or move a shortcut button,
press the Menu key then press and hold the shortcut for approximately 3 seconds. The
Customize Button dialog box will open to allow a button to be deleted or moved. Press Esc to
exit the Menu shortcut display.
The Factory Default reset will delete all user created shortcut icons from the Menu
Note
screen. Refer to the
Help for the Menu shortcut screen is available by pressing the icon in the lower-right corner
of the display.
Esc Key
Press this key to cancel any setting that is currently being made.
Enter Key
Press this key to finalize data input or select a highlighted item from a list.
Arrow Keys
The four arrow keys (around the Enter key) are used to scroll up, down, left, or right. The
arrow keys can often be used to change a value or to change a selection from a list. This
function is similar to the function of the rotary knob. The arrow keys are also used to move
markers.
2-4
"Reset Menu" on page 5-7
PN: 10580-00328 Rev. E
Instrument Overview
for additional information.
Spectrum Master User Guide
