2-5 Display Overview

LED Indicators

Power LED
The Power LED is located to the left of the On/Off key. The LED is solid green when the unit
is on and slowly blinks when the unit is off but has external power.
Charge LED
The Charge LED is located to the right of the On/Off key. The LED slowly blinks when the
battery is charging and is solid green when the battery is fully charged.
2-5

Display Overview

Figure 2-5
illustrates some of the key information areas of the Spectrum Master in Spectrum
Analyzer mode. For detailed information, refer to the Measurement Guides listed in
Appendix A, "Measurement
Measurement
Settings
(Touch Screen
Shortcuts)
Figure 2-5.
Spectrum Analyzer Display
Many of measurement settings are used as touch screen shortcuts. Use the touch
Note
screen to select a measurement setting to edit.
2-6
Guides".
GPS Icon
Date/Time
GPS Location
PN: 10580-00328 Rev. E
Save
Battery
Charge
Main Menu
Touch Screen Keys
Instrument Overview
Measurement
Mode
Submenu
Touch Screen
Keys
Marker Table
Spectrum Master User Guide
