File Management

Save Location Menu

Key Sequence: File > Save > Change Save Location
Save Location
Sort By
Name Type Date
Sort Order
Asc Desc
Create
Folder
Set
Location
Refresh
Directories
Figure 4-8. Save Location Menu
Figure 4-9. Select Save Location Dialog Box
Spectrum Master User Guide
This menu and dialog box is used to create folders and select where the
Spectrum Master will save the current file. Select folders or drives with the
Up/Down keys, the rotary knob or the touch screen.
Note: Only folders (not files) are visible in the Save Location dialog box. To
view files, use the "Recall Menu" on page
Sort By: Press this submenu key to sort the folders by Name, Type, or Date.
Sort Order: Displays the folder names in ascending or descending order.
Create Folder: This key will create a new folder in the highlighted location
or folder. The create directory dialog box will display for naming the folder.
Set Location: This key will set the current location for saving files and return
to the "Save Menu" on page
Refresh Directories: Press this key to update the display.
