File Management
4-4

File Menu

Key Sequence: File
File
Save Measurement As
FileName.spa
Save
Measurement
Save
Save
On
Event
Recall
Measurement
Recall Recall
Copy
Delete
Figure 4-6. File Menu
Spectrum Master User Guide
Save Measurement As: This key will save the current setup with a user
defined file name. The default file name is changed using the Save
submenu. To change the default file name, type in a new file with the touch
screen keyboard and press Enter. After a few seconds the screen with return
to File menu. Press the Save Measurement As key again and the new file
name will be used. Measurement files names have a .spa extension.
Save Measurement: Press this submenu key to display the
on page 4-8 and the touch screen keyboard. Measurements can be saved to
internal memory or to a USB flash drive. The saved measurement can be
named by using touch screen keyboard. By default, measurements are
saved in a directory named /user to internal memory. The save destination is
set with the "Save Location Menu" on page
Save: Press this submenu key to display the
the touch screen keyboard. Measurements can be saved to internal memory
or to a USB flash drive. The saved setup, measurement or JPEG file can be
named by using touch screen keyboard. By default, measurements are
saved in a directory named /user to internal memory. The save destination is
set with the "Save Location Menu" on page
Save on Event (Spectrum Analyzer mode only): Press this submenu key to
display the "Save On Event Menu" on page
Recall Measurement: Press this submenu key to display the
on page 4-11. This menu is for recalling measurements from internal memory
or a USB flash drive.
Recall: Press this submenu key to display the
This menu is for recalling measurement or setup data from internal memory
or a USB flash drive.
Copy: Press this submenu key to display the
This submenu is for copying files or folders from internal memory or a USB
flash drive.
Delete: Press this submenu key to display the
and a selection box that shows the setup and measurement names, the type
and the date and time that the information was saved. Use the rotary knob or
the Up/Down arrow keys to highlight the file that is to be deleted and press
the Delete submenu key, then Enter. Press the Esc key to cancel the
operation. Note that deleted files can not be recovered.
PN: 10580-00328 Rev. E
4-4 File Menu
"Save Menu"
4-9.
"Save Menu" on page 4-8
4-9.
4-10.
"Recall Menu"
"Recall Menu" on page
"Copy Menu" on page
"Delete Menu" on page 4-13
and
4-11.
4-12.
4-7
