Chapter 4 — File Management
4-1

Introduction

This chapter will review the file management features of the Spectrum Master and detail the
File menu. The submenus under this menu allow the user to save, recall, copy, and delete files
in internal memory or an external USB flash drive.
4-2

Managing Files

Press the Shift key then the File (7) key on the numeric keypad to list the File menu. Follow
the additional steps below.
When navigating through the File menu, pressing the Esc key will return to the
Note
previous menu.

Save Files

Set the Save Location
Press the Save submenu key then the Change Save Location and select the location to save
files. You can save files to the internal memory or to an external USB flash drive. You can
also create new folders. If an external USB flash drive is connected or disconnected, press
Refresh Directories to update the location tree. Press the Set Location key to store the save
location.
Save Measurement As
The Save Measurement As key is used to quickly save measurements with a specific file
name. The Spectrum Master saves the measurement with the latest file name that was used
to save a measurement and with a number that is automatically incremented and appended
to the end of the file name. For instance, if the last measurement was saved with the name
ACPR, Save Measurement As saves the next measurement as ACPR_#1, ACPR_#2, etc. The
file name used can be changed using the Save dialog box
Save a Measurement
Press the Save Measurement key and enter the name for the measurement file. The file type
will default to measurement and the appropriate extension will be added based on the current
measurement mode.
Save a Setup
Press the Save submenu key, type a name for the setup file, confirm that the file type is Setup
using the Change Type key or the touchscreen and press Enter to save.
Create a Menu Shortcut for a Setup file
Press the Recall submenu key to display saved setup files. Locate the setup file to shortcut
and then press and hold on the file name for a few seconds. Select a location in the shortcut
grid to save the setup file.
Spectrum Master User Guide PN: 10580-00328 Rev. E
(Figure 4-1).
