1-14 Battery Replacement
Figure 1-1. Battery Compartment Door
The battery that is supplied with the Spectrum Master may need charging before use. The
battery can be charged while it is installed in the Spectrum Master by using either the
AC-DC Adapter or the DC adapter, or outside the Spectrum Master with the optional
Dual Battery Charger. Refer to
symbols.
Use only Anritsu Company approved batteries, adapters, and chargers with this
Note
instrument.
When using the Automotive Cigarette Lighter Adapter, always verify that the
supply is rated for a minimum of 60 Watts @ 12 VDC, and that the socket is clear
Caution
of any dirt or debris. If the adapter plug becomes hot to the touch during operation,
then discontinue use immediately.
Anritsu Company recommends removing the battery for long-term storage of the
Note
instrument.
1-6
"Battery Symbols" on page 2-9
PN: 10580-00328 Rev. E
General Information
for a description of battery
