Master Software Tools
7-4

Installing MST

MST is provided on the CD-ROM included with the instrument. Insert the CD-ROM into a PC
to run the installer. Follow the instruction on the screen. MST is also available as a download
from http://www.anritsu.com.
7-5

Connecting to the Instrument

Use the USB cable supplied with the test instrument to make the connection.
1. Connect the USB cable to the USB-A port on the computer and to the USB mini-B port
on the test instrument.
2. Turn on the test instrument. Run the Master Software Tools program.
3. Pull down the Connection menu and click on Connect – USB. This establishes
communication to the test instrument.
7-6

Updating Spectrum Master Firmware

Refer to "Updating the Spectrum Master Firmware" on page
Spectrum Master User Guide PN: 10580-00328 Rev. E
7-4 Installing MST
5-9.
